Behringer NOX1010 Manual page 6

NOX1010/NOX606
NOX404/NOX303
NOX202
NOX303 Top Panel
FX ON button
activates
digital effects
processor
FX CUE
button
sends effect
to cue
section for
preview
FREQUENCY
knob adjusts
effect's
frequency or
time-based
parameter
INTENSITY
fader adjusts
effect's mix
or resonance
parameter
CUE button
allows source
monitoring
without
inclusion in
master output
MIC EQ
knobs adjust
channel
equalization
MIC GAIN
knob controls
sensitivity of
mic input
MIC ON
button
CHANNEL VU GAIN knob
METER displays controls FX DISPLAY
input source channel input indicates
signal level sensitivity selected effect
CFR KILL CHANNEL CROSSFADER
buttons FADER fades
remove controls between
BASS, MID volume of sources
and TREBLE channel in assigned to
frequencies overall mix either side
from A or B
crossfader mix
FX SELECT knob TAP button
scrolls through allows effect's
INPUT SELECT available tempo
switch selects effects, pressing parameter to
channel audio knob confirms be entered
source selection manually
XFADE (A OFF
B) switch sends
channel to
either side of
crossfader, OFF
position bypasses
crossfader and is
heard in main mix
Page 6 of 20
FX ASSIGN
knob
determines
which sources
are affected by
effect
MASTER VU
METER displays
master output
and/or cue
signal level
CHANNEL EQ
knobs boost/
cut high,
mid and low
frequencies
MASTER knob
controls RCA
MAIN and
BALANCED
OUTPUT level
BOOTH knob
controls
RCA BOOTH
OUTPUTS level
CUE MIX knob
allows gradual
blend between
cue and program
signal
SPLIT/BLEND (CUE)
button allows
combining cue and
program sources
or splitting into left
(cue) and right (main)
CUE GAIN
knob
adjusts cue
volume
