NOX1010/NOX606
NOX404/NOX303
NOX202
Premium phono and XENYX mic
preamps for superior detail and
ultimate punch
5 dual line and USB inputs,
3 phono/line plus 2 mic/line inputs
VCA-controlled faders with selectable
fader start for utmost reliability and
noise-free performance
Sophisticated headphone monitoring
and cueing section with split
cue function
Extensive XLR Master, Record and
Booth outputs
Common Features:
45-mm infinium "Contact-Free"
optical crossfader with adjustable
tension and fader curve for years of
use
Built-in USB interface for recording
and playback of any digital music file.
Works with your PC or
Mac computer—no setup or
drivers required
"Planet Earth" power supply for
maximum flexibility (100 - 240 V~),
noise-free audio, superior transient
response plus low power
consumption for energy saving
High-quality components and
exceptionally rugged construction
ensure long life
Conceived and designed by
BEHRINGER Germany
NOX202 Front Panel
Microphone input
NOX202 Rear Panel
IEC
POWER USB
socket socket
POWER
switch
MAIN MAIN Left
RECORD and Right
OUTPUTS OUTPUTS
(RCA) (1/4")
MAIN
AMP
OUTPUTS
(RCA)
Page 5 of 20
Headphones jack
PHONO PHONO
ground INPUTs
terminal (RCA)
PHONO/ LINE
INPUTs
LINE
source (RCA)
switch
