Specifications - Behringer STUDIO CONDENSER MICROPHONES C-2 User Manual

23
STUDIO CONDENSER MICROPHONES C-2 User Manual

9. Specifications

Transducer type
Operating principle
Polar pattern
Connector
Open circuit sensitivity (@ 1 kHz)
Frequency response
level attenuation
Low-cut filter
Max. SPL (≤ 1% THD @ 1 kHz)
Equivalent noise level (IEC 651)
Signal-to-noise ratio
Nominal impedance
Load impedance
Mains Voltage/Fuse
Supply voltage
Supply current
Physical/Weight
Dimensions
Weight
condenser, 16 mm (0.63'')
pressure gradient
cardioid
gold-plated balanced XLR connector
−41 dBV (0 dBV = 1 V/Pa)
20 Hz to 20 kHz
−10 dB, switchable
6 dB/oct. @ 120 Hz (switchable)
140 dB (0 dB), 150 dB (−10 dB)
19 dBA
75 dB
75 Ω
> 1 kΩ
+48 V
3 mA
0 shaft: 0.8" / 20 mm
length: 3.7" / length: 94 mm
approx. 0.2 lbs / 0.09 kg
