Summary of Contents for Behringer C-2
-
Page 1: User Manual
User Manual A50-26313-00002... -
Page 2: Safety Precautions
C-2 through deffective phantom power. Before activating phantom power, mute your playback system and connect the C-2 to the microphone input of your mixing con- sole. After activating phantom power, the C-2 requires several seconds to stabilize itself. - Page 3 Low cut-filter and signal level attenuation (−10 dB) The C-2 studio microphones feature a switchable low-cut filter that lets you eliminate low-frequency disturbances such as subsonic noise. Set the switch to its middle position to activate the low-cut filter.
-
Page 4: Microphone Installation
Audio connection Use a balanced XLR microphone cable with the following pin assignment: pin 1 = shielding; pin 2 = +; pin 3 = -. Since your C-2 features gold-plated contact points throughout, we recommend that you use only microphone cables with gold-plated connectors. - Page 5 All trademarks (except BEHRINGER, the BEHRINGER logo, JUST LISTEN and C-2) mentioned belong to their respective owners, and such use neither constitutes a claim of the trademarks by BEHRINGER nor affiliation of the trademark owners with BEHRINGER.
