Unit Load Rating Of System Modules - AT&T MERLIN LEGEND Release 2.0 Pocket Reference Manual

Power Supply Unit Load Requirements
(continued)

Unit Load Rating of System Modules

Module
Unit Load
0 0 8
008 MLX
008 OPT
012 T/R
100D (DS1)
400 GS/LS/TTR
400 (LS)*
4 0 0 E M
* This is a MERLIN II loop-start-only module that can be used
in the MERLIN LEGEND Communications System.
Module
12.0
408 GS/LS
13.5
408 GS/LS-MLX
8.0
408 (LS)
8.4
800 GS/LS
0.0
800 (LS)*
0.0
800 DID
0 . 0
Processor
8.0
Unit Load
12.0
12.0
12.0
0 . 0
0.0
8.0
0.0
51
