4. CONFIGURATOR
Overview
• Introduction
• Configurator window
• Create a new configuration
• Add device to a configuration via scanning
• Add device to a configuration
• Reconnect a device
• Edit projector properties
• Configuration preview
• Configuration properties
• Preview layout properties
• General Settings
4.1 Introduction
Overview
The configurator makes it possible to create configurations and to change the settings of each device
separately.
Start up
To start up the configurator, just click on the configurator icon (
on Modules and select Configurator.
Image 4-1
Configurator start up
4.2 Configurator window
Overview
The configurator window allows to create new configurations and to manage the projectors inside a con-
figuration.
R59770449 DC TOOLSET 15/12/2009
4. Configurator
) on the navigation button bar or click
