- Page 1 8 output USB Audio Interface User’s Guide...
- Page 2 ESI - Copyright © 2008 Revision 1, July 2008 www.esi-audio.com...
-
Page 3: Table Of Contents
GIGAPORT HD INDEX 1. Introduction..........................4 1.1 Features................................4 2. Installation ............................ 5 2.1 System Recommendation............................. 5 2.2 Hardware Installation............................5 2.3 Driver Installation ..............................5 3. Control Panel..........................9 4. Setting in Applications....................... 10 4.1 Windows Multimedia setup ..........................10 4.2 Cubase LE 4............................... -
Page 4: Introduction
GIGAPORT HD 1. Introduction Congratulations on your purchase of the ESI GIGAPORT HD. GIGAPORT HD is a USB audio interface, that provides 8 analog output channels and two independent high quality stereo headphone outputs. It is very easy to use, small and powerful. With our excellent driver support GIGAPORT HD works perfect with all current recording and sequencer applications. -
Page 5: Installation
GIGAPORT HD 2. Installation 2.1 System Recommendation GIGAPORT HD is not simply a standard digital audio interface card, but a high-resolution device capable of advanced processing of audio content. Even though GIGAPORT HD is built to have low-CPU resource dependability, system specifications play a key part in the GIGAPORT HDs performance. - Page 6 GIGAPORT HD used for DVD playback or more simple DJ applications that don’t require ASIO. Under Mac OS X this could be applications like Garageband. Please note that our special driver is also required if you are using higher sample rates than 44.1kHz. Installation under Windows XP Unplug the device before you start the installer if it is already connected.
- Page 7 You can now finally click Next on the ESI GIGAPORT HD Audio Driver Setup dialog. The installation is now finished. To confirm this, please check if the ESI icon is displayed in the taskbar notification area as shown below. Sometimes a reboot is required.
- Page 8 You can now finally click Next on the ESI GIGAPORT HD Audio Driver Setup dialog. The installation is now finished. To confirm this, please check if the ESI icon is displayed in the taskbar notification area as shown below. Sometimes a reboot is required.
-
Page 9: Control Panel
This chapter describes the GIGAPORT HD Control Panel under Windows. Under Mac OS X no special Control Panel is required. To open the control panel double click on the ESI icon in the task notification area. The following dialog will appear: The Output section controls the playback volume of each playback signal from your audio applications. -
Page 10: Setting In Applications
GIGAPORT HD Latency setting With the Latency menu entry under Config, you can change the latency of the driver of GIGAPORT HD. Depending on the typical application (e.g. for playback of software synthesizers) a smaller latency is an advantage. At the same time, the best latency setting indirectly depends on the performance of your system. - Page 11 GIGAPORT HD Make sure to select ESI GIGAPORT ASIO as ASIO Driver entry. Note that the Control Panel button has no effect. Confirm your changes by clicking OK. Now its time to select the output channels. From the Devices menu, select VST Connection. The VST Connections window appears.
-
Page 12: Specifications
GIGAPORT HD 5. Specifications 1. Interface - USB spec version 1.1 - USB audio class spec version 1.0 - fully compatible to USB 2.0 host controllers 2. Output Type - analog 8 channel output (RCA jack) - 2 headphone outputs (3.5mm mini jack for a mixed output signal and an independent 2 channel playback) 3. -
Page 13: General Information
If necessary, consult an experienced radio/television technician for additional suggestions. Correspondence For technical support inquiries, contact your nearest dealer, local distributor or ESI support online at www.esi-audio.com. Disclaimer All features and specifications subject to change without notice.
