ECS 945GCD-I230 Manual page 11

Table of Motherboard Components
LABEL
System cooling fan connector
1. SYS_FAN
Clear CMOS jumper
2. CLR_CMOS
240-pin DDR2 SDRAM slot
3. DDR2
4. PWR_FAN Power cooling fan connector
Standard 24-pin ATX power connector
5. ATX1
Front panel switch/LED header
6. F_PANEL
Primary IDE connector
7. IDE
Serial ATA connectors
8. SATA1~2
9. SPK Internal speaker header
32-bit add-on card slot
10. PCI
Front panel USB Power Select jumper
11. USBPWR_F
Front panel audio header
12. F_AUDIO
SPDIF out header
13. SPDIFO
14. F_USB1~2 Front panel USB headers
15. USBPWR_R Rear USB/PS2 Power Select jumper
This concludes Chapter 1. The next chapter explains how to install the motherboard.
Introducing the Motherboard
COMPONENTS
5
