Onboard LAN
The onboard LAN controller provides either of the following features:
•
Supports PCI Express
•
Integrated 10/100/1000 transceiver
•
Wake-on-LAN and remote wake-up support
•
Integrated 10/100 transceiver
•
Wake-on-LAN and remote wake-up support
•
Fully complies with IEEE802.3, IEEE802.3u
Expansion Options
The motherboard comes with the following expansion options:
•
One 32-bit PCI v2.3 compliant slot
•
One IDE connector that supports two IDE devices
•
Two 7-pin SATA connectors
The motherboard supports UDMA bus mastering with transfer rates of 100/66/33
Mb/s.
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
•
Two PS/2 ports for mouse and keyboard
•
One LPT port
•
One serial port
•
One VGA port
•
Four USB ports
•
One LAN port
•
Audio jacks for microphone, line-in and line-out
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
•
Power management
•
Wake-up alarms
•
CPU parameters
•
CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
1. Some hardware specifications and software items are subject to change
without prior notice.
2. Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50
3. To achieve better performance and air flow, we suggest that you use
a system fan on this motherboard.
Introducing the Motherboard
TM
1.1
°
C.
3
