Table of Motherboard Components
LABEL
1. MCH_FAN Northbridge cooling fan connector
2. DIMM1 240-pin DDR2 SDRAM slots
3. ATX1 Standard 24-pin ATX power connector
4. IDE Primary IDE connector
5. PANEL1 Front panel switch/LED header
6. SATA1~2 Serial ATA connectors
7. BIOS_WP BIOS flash protect jumper
8. CLR_CMOS1 Clear CMOS jumper
9. PCI1 32-bit add-on card slot
10. USB2~3 Front panel USB headers
11. F_AUDIO1 Front panel audio header
12. TPM TPM module header
System cooling fan connector
13. SYS_FAN
This concludes Chapter 1. The next chapter explains how to install the motherboard.
