- Page 1 Avaya SG5, SG5X, and SG200 Security Gateway Hardware Installation Guide 670-100-102 Issue 2 March 2004...
- Page 2 Your company's “telecommunications equipment” includes Warranty both this Avaya product and any other voice/data/video Avaya Inc. provides a limited warranty on this product. Refer equipment that could be accessed via this Avaya product to your sales agreement to establish the terms of the limited (that is, “networked equipment”).
- Page 3 15 of the FCC Rules. These limits are designed to provide Standards Compliance reasonable protection against harmful interference when the Avaya Inc. is not responsible for any radio or television equipment is operated in a commercial environment. This interference caused by unauthorized modifications of this...
- Page 4 U.S. Export Administration Act and its associated regulations, and may be subject to export or All Avaya media servers and media gateways are compliant import regulations in other countries. Customer agrees to with FCC Part 68, but many have been registered with the comply strictly with all such regulations and acknowledges FCC before the SDoC process was available.
-
Page 5: Table Of Contents
Table of Content About this book Contacting technical support ......... 7 Documentation . - Page 6 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Appendix A Specifications Physical specifications..........29 Environmental specifications .
-
Page 7: About This Book
About this book Avaya SG5, SG5X, and SG200 is the new name for Avaya VSU5, VSU5X, and VSU 500 Security Gateways. Our documentation reflects these new names as of June, 2003. This guide describes the Avaya SG5, the SG5X, and the SG200 Security Gateways and how to install and preconfigure these devices. -
Page 8: Documentation
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Documentation The security gateway documentation includes both the Hardware Installation Guide and the Security Gateway Configuration Guide for VPNos. You can down load these guides from http://support.avaya.com. Navigate to Product Documentation, VPN and Security. -
Page 9: Introduction 9
Like other platforms in the Avaya VPN family, the security gateway adds encryption, authentication, and key management to public network data links to ensure privacy and integrity of corporate data, and to enable the efficient and secure operation of VPNs. -
Page 10: Security
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Figure 1 SG200 security gateway Security The VSU provides data stream privacy by employing cryptographic algorithms and keys powerful enough for the most sensitive business communications. It supports DES and 3DES encryption, as well as the IKE key management standards. -
Page 11: Plug-And-Play Installation
Provisions are also made to access the web-based interface remotely over the Internet if desired. Where central management of your VPN is required, the optional Avaya VPNmanager network management application (available separately) steps network managers through the setup process and allows them to configure a VPN in minutes. -
Page 12: Hardware Components
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Hardware components Figure 2 displays the back panel components on each of the security gateways. Figure 2 Back panel components Public Port Reset Switch Private Port Ethernet Ports DC Power... -
Page 13: Available Ports
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Available ports The SG5 includes two 10/100BASE-T Ethernet ports that includes a public and private interface port. The SG5X includes one 10/100BASE-T Ethernet port on the public interface, and 7 10/100BASE-T Ethernet ports on the private interface. - Page 14 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide 14 Introduction March 2004...
-
Page 15: Installing The Security Gateway 15
Chapter 2 Installing the security gateway General requirements This section describes the requirements your site must meet for safe installation and operation of your system. Ensure that you are properly prepared before beginning installation. Environmental requirements The security gateway is intended for use in a normal home office environment. -
Page 16: Power Considerations
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Power considerations Be sure that the power where the security gateway will be used is “clean” power (free of spikes and noise). Install a power conditioner if necessary. WARNING: This product relies on the building’s installation for short- circuit (overcurrent) protection. -
Page 17: Installing The Security Gateway
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Installing the security gateway Figure 3 shows a typical network using the SG5 security gateway. Figure 3 Typical SG5 installation March 2004 Installing the security gateway 17... - Page 18 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Figure 4 shows a typical network using the SG5X security gateway. Figure 4 Typical SG5X installation SG5X 18 Installing the security gateway March 2004...
- Page 19 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Figure 5 shows a typical network using the SG200 security gateway. Figure 5 Typical SG200 installation SG200 March 2004 Installing the security gateway 19...
- Page 20 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Figure 6 Security gateway rear panel connectors Connect Cable between the Connect Cable between the SG5/5X SG5/5X Private Port and Hub or Workstation Public Port and the DSL/Cable Modem Connect Cable between the...
- Page 21 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide The public port provides an Ethernet interface to the public network (through a DSL or cable modem), while the private port(s) connect to your local network, (typically through a hub in the case of the SG5).
- Page 22 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide 22 Installing the security gateway March 2004...
-
Page 23: Setting Up The Security Gateway For Configuration
Chapter 3 Setting up the security gateway for configuration This chapter describes how to set up the security gateway addressing and remote connectivity capabilities in preparation for remote configuration using the VPNmanager software. This preliminary configuration is performed using a browser on your workstation connected to the security gateway’s Private Port. -
Page 24: Service Provider Provisioning
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Service provider provisioning Your Connection Type Before you begin, you will need to determine if your existing installation uses static IP addresses, dynamic addressing (DHCP), or PPPoE from your service provider. Typically, DSL connections use PPPoE and cable modems use DHCP. -
Page 25: Connecting To The Private Port Of The Security Gateway
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Connecting to the private port of the security gateway From the workstation’s control panel, select your TCP/IP network component for your Ethernet controller. In the IP Address window select “enable the setting” to “Obtain an IP address automatically” . - Page 26 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide To connect to the security gateway From a workstation on the private side of the security gateway, open your browser and type into the location field one of the following: •...
- Page 27 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Figure 9 Quick setup dialog In the IP Configuration area, select one of the following IP Config Modes. • Static Addressing. If you are going to use static addressing on the public port, click the Static Addressing radio button and enter your IP address, network mask, and default route information.
- Page 28 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide In the Centralized Management area, if VPNmanager is used, enter the Super User name superuser and Password enter password. Superuser and password are the default Super User name and Password for Centralized Management. If the Super User and...
-
Page 29: Appendix A Specifications
Appendix A Specifications This appendix provides physical, environmental and electrical specifications for the security gateway, as well as standards compliance information. Physical specifications Table 3 Physical specifications Parameter SG5X SG200 Dimensions 6.0" W x 5.0" D x 1.5" H 7.75" W x 6.5" D x 1.9" H 7.75"... -
Page 30: Environmental Specifications
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Environmental specifications Table 4 Environmental specifications Operating Parameter Specification Temperature 32-104 F, 0-40 C Relative Humidity 5-90%, non-condensing Altitude 0-12,000 feet, 0-3,660 meters Electrical specifications Table 5 Electrical specifications Parameter... -
Page 31: Compliance Specifications
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Compliance specifications Table 6 Compliance specifications Parameter Specification Safety CSA, CE, CB SCHEME, EN, C-Tick Mark Certification EMI/RFI FCC Part 15, Class B, EN55022 Class B EN50082-1 VCCI BSMI Standards IEEE 802.3, Ethernet... -
Page 32: Additional Features
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Additional features Table 7 Additional features Parameter Specification Encryption DES and 3DES encryption. DES uses a 56-bit key; 3DES uses three 56-bit independent keys for an effective key length of 168 bits. -
Page 33: Index
Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide Index authentication specification LAN connections log out Login CE marks compliance specifications configuring network zones table by security gateway static addressing,DHCP,PPPoE connections Password Ethernet LAN phone support router physical specification... - Page 34 Avaya SG5, SG5X, & SG200 Security Gateway Hardware Installation Guide specifications authentication compliance electrical encryption environmental key management physical software upgrades standards electromagnetic compatibility System Requirements technical support triple DES world wide web support zones network type of 34 Index...
