Thank you for purchasing our receiver
For proper use of this receiver, please read this manual thoroughly.
Keep this manual in a safe place for future reference.
WARNING
Do not use any batteries other than size AA Alkaline or manganese batteries. Using different batteries could
l
cause fire, electric shock or failure.
Do not place consumed batteries in a fire. They could explode, causing fire or burns.
l
Do not install or remove batteries while your hands are wet. This could cause electric shock.
l
In the event that smoke is emitted, a strange odor or noise is generated, or similar abnormality occurs, it could
l
cause fire, electric shock or breakdown. Consult your dealer immediately for the necessary instructions or
repair needed.
Do not attempt to repair the receiver yourself. Doing so may lead to serious damage or physical injury.
l
Do not attempt to disassemble or modify this product in any way. This could lead to fire, electric shock or
l
breakdown.
CAUTION
Do not use this product for anything other than a receiver.
l
When not in use, keep it out of the reach of infants and small children.
l
During extended trips or other times when this product is not in use for long periods, take the batteries out.
l
Keep the batteries stored in a safe place and out of the reach of infants and small children.
Discontinue use of this product if it has a negative influence on TV, electronic device, therapeutic devices and
l
or other equipment.
Always be aware of antenna location to avoid personal injury.
l
When conducting routine maintenance, be sure to disconnect the power for additional safety.
l
Do not place this product in locations with extreme temperature, high humidity or excessive dust. Do not keep
l
it in an automobile. It could lead to fire, electric shock or breakdown.
NOTICE
Unauthorized use of the contents of radio communications or divulging its contents to other parties is prohibited by
law.
INTRODUCTION
AX400 / AE 500 H First Edition
Owner's Manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Albrecht AE 500 H First Edition
Summary of Contents for Albrecht AE 500 H First Edition
- Page 1 AX400 / AE 500 H First Edition Owner’s Manual Thank you for purchasing our receiver For proper use of this receiver, please read this manual thoroughly. Keep this manual in a safe place for future reference. WARNING Do not use any batteries other than size AA Alkaline or manganese batteries. Using different batteries could cause fire, electric shock or failure.
-
Page 2: Basic Operations
Never disassemble the receiver. Never touch the receiver’s core. It is adjusted for optimum performance. Avoid hot places and locations exposed to direct sunlight. Avoid extremely cold places. Avoid exposing the receiver to excessive vibrations and dusty places. Applicable batteries are either AA-size manganese or alkaline batteries. Never use any other batteries. This receiver require 2.2 to 3.5 volts DC. - Page 3 by the POWER key. Please take out the batteries and replace them! Adjusting the Volume To increase the volume, turn the VOL knob clockwise. (Illust. 8) To decrease the volume, turn the VOL knob counterclockwise. (Illust. 7) CAUTION Set the volume to an acceptable loudness level. Be sure to decrease the volume level before switching from built-in speaker to earphones.
-
Page 4: Preset Mode
(Illust. 13-2) Hold down FUNC key and press POWER key. (A high pitched beep is emitted). Release the keys and confirm if the original state is displayed in the display. (Illust. 13-3) Resetting the All Settings (All Reset) With following procedure, your receiver is set at factory’s original setting. Use this function only when it is necessary such event as CPU is locked up. - Page 5 Pressing this key while the FUNC key is pressed activates the light. 2 MODE Key Enters numeric „2“. Pressing this key while the FUNC key is pressed changes the reception Mode from AM to FM or to FM Wide. 3 SEARCH Key Enters numeric „3“.
- Page 6 Confirm the display. If M is displayed, press CLEAR PROGRAM key. (When ‘M’ is displayed, you are in the Channel Memory Mode. ) Use rotary selector to change the frequency up or down to confirm you are in FREQ Mode. Changing the Frequency There are three methods for changing the frequency, 1) using rotary elector, 2) using the 5 key or ENT key while the FUNC key is pressed, and 3) using the numeric keys.
- Page 7 How to Recall the Channel Memory [1] The frequencies that have previously been programmed into channel memories can be recalled by using following method. Using the selector Hold down FUNC key and press 7 FREQ/CH key to set to the channel memory mode. (Illust.
- Page 8 4. To complete this procedure, press CLEAR PROGRAM key. Note: All the contents of channel memories are cleared during All Reset procedure even when this function is activated. This function does not apply to protect Search Pass Channel Memories. Erasing Channel Memories by Block at a Time Channel Memory can be cleared by blocks.
- Page 9 Search and Scan Function Search and Scan Function In the Expanded Mode, in order to search for the desired frequencies, Search and Scan functions are provided. A Dual Watch function is also provided where a specific frequency can be received alternately with a frequency stored in channel memory.
- Page 10 Using a One Touch Search In this mode, you are able to set upper and lower limits of frequencies to be searched between. The 10 sets frequencies (20 frequencies) are already preprogrammed in 20 Search Band Channel Memories Set the unit to the FREQ Mode by pressing CLEAR PROGRAM key. Hold down FUNC key and press 3 SEARCH key.
- Page 11 Erasing the Search Band Channel Memory The frequencies entered in Search Band Channel Memory can be erased. 1. Set the unit to the Channel Memory Mode by pressing 7 FREQ./CH while FUNC is pressed until ‘M’ appears on the display. 2.
- Page 12 appears on the display. 2. Hold down FUNC key and press 7 FREQ/CH key once again. 3. Select the channel memory address to be erased by using the selector or numeric keys. (Illust. 33-1) 4. Hold down FUNC key and press 9 L/OUT key. ( „CLr“ is displayed.) (Illust.
- Page 13 Scanning A Block of Channels (Block Scan) You can scan through only specified block of channels. One block consists of 100 channel memory addresses. (‘34) Hold down FUNC key and press 8 SCAN key. (All channel scan starts.) Enter the block number to be scanned using the numeric key. (Illust.
- Page 14 TO USE YOUR RECEIVER MORE EFFECTIVELY In order to use your receiver more effectively, the unit enables you to change various settings. All these functions are programmed in SET mode initiated by pressing FUNC and 0 SET key simultaneously. Changing the Frequency Step When the frequency is changed either manually or by searching, it increases or descreses in accordance with the frequency step assigned or specified.
- Page 15 To complete the setting, press CLEAR PROGRAM key. Changing Light Operation The light stays on for 5 seconds after the Light key is released. The Light operation can be changed so that it remains on until the Light key is pressed again. Hold down FUNC key and press 0 SET Key.
- Page 16 To activate the programmed SET MODE, simply hold down FUNC key and press 4 MY key. The value of the settings are changed by repeating the action. When Reset or All Reset are performed, the contents of this key return to the memorized frequency step.
-
Page 17: Troubleshooting
Changing the Frequency to MHz Digit (Fast Step) In order to change the frequency rapidly, this receiver is equipped with FAST STEP function. This is activated by turning the rotary selector while FUNC key is pressed. Initially at the factory, a digit of 1MHz is set for this mode therefore the frequencies change at the digit of 1MHz by activating FAST STEP. - Page 18 The channel memory is not stored. There are no vacant channel Memory addresses. Does not scan/ search. Squelch is off. Not able to scan Channel Memories The frequencies are not stored or only one frequency is stored. Specifications General Frequency range 0.500MHz - 1299.999MHz Speaker impedance 8 ohms...
