DP-101P+ Print Server User's Manual
LPT Flash Pattern
steady long flashes
One long, two short flashes
One long, three short flashes
One long, four short flashes
One long, five short flashes
One long, six short flashes
One long, seven short flashes
One long, eight short flashes
One long, nine short flashes
steady short flashes
One long, eleven short flashes
In the event of a Firmware Reload Required error at startup,
proceed according to instructions given in the PS Admin User's
Guide ("PS Admin Administration" section, under the heading
"Upgrading the Print Server's Internal Firmware").
In the event that any of the other listed error conditions is
encountered on startup, contact your dealer for correction of the
fault.

Operational Test

The PS Admin software includes a Print Test function for
confirmation of connections and functions. That operational test
can be performed after you have completed installation of the PS
Admin software, and the PS Admin procedures for configuring the
DP-101P+. See instructions given in the PS Admin User's Guide
("Getting Started Setting up Your Print Server" section, under the
heading "Testing your Print Server").
12
continuous on
Error Type
Firmware Reload Required
DRAM Error
Timer INT Error
Flash Protected
Flash ID Error
Flash Erase / Program Error
LAN Controller Error
LAN Memory Error
Parallel Controller Error
LPT Error
EEPROM Error
LAN I/O Base error
