Proceed to the TQ100 terminal setup procedure below:
Press the 'Power On' button
Press 'Menu'
Using the 'Scroll Down' button, highlight the –Setup-, and then press 'OK'
Scroll and highlight –Communication-, then press 'OK'
Press 'OK' again and using the 0 thru 9 buttons on the keypad, enter the –
Device ID- number (must be a value from 1 to 10), then press 'OK'
NOTE: The factory default is set to 1. If you plan to use only one terminal,
leave it at 1. If you will have more than one terminal, each will need a
unique ID number.
Scroll and highlight –Baud rate-, press 'OK' then use buttons to change the
number if required, then press 'OK' again.
NOTE: The factory default is set to 38400 which may not be correct for your
computer. This number must be the same as the value you determined in the
process you performed immediately above.
Scroll and highlight –RS485-
If you are configuring for RS232 this value should be set to 'NO'
If you are configuring for RS485 this value should be set to 'YES'
Press 'OK', then press a scroll button to change it to 'YES', or 'NO',
based on your configuration, then press 'OK' .
Scroll and highlight –Ethernet-. If it reads 'NO', no action is required. If is
reads 'YES' , press 'OK', then press a scroll button to change it to 'NO', then
press 'OK' .
Now press 'ESC'. If the terminal displays the 'Save?' message, press 'OK' .
Then press 'ESC' several times until the terminal displays the 'Welcome'
message screen.
NOTE: It is a good idea to record the following values for use during step 2:
Before proceeding to the next step "Power-off" your PC.
Now CONNECT the TQ100 Terminal to your PC based on the type of
network connection you will be using. Now, "Power-on' your PC.
timeQplus BIOMETRIC™ Installation Guide
Device ID ___________________
Baud Rate ___________________
