Your buffer/polisher has been engineered and manufactured to our high standard for dependability, ease of operation, and
operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
6 in. BUFFER / POLISHER
DOUBLE INSULATED
RB60
Advertisement
Table of Contents
Related Manuals for Ryobi RB60K
Summary of Contents for Ryobi RB60K
- Page 1 OPERATOR’S MANUAL 6 in. BUFFER / POLISHER DOUBLE INSULATED RB60 Your buffer/polisher has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
-
Page 2: Table Of Contents
The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power ®... -
Page 3: General Safety Rules
GENERAL SAFETY RULES Avoid accidental starting. Be sure switch is off WARNING: before plugging in. Carrying tools with your finger on the switch or plugging in tools that have the switch on Read and understand all instructions. Failure to follow invites accidents. -
Page 4: Specific Safety Rules
GENERAL SAFETY RULES SERVICE When servicing a tool, use only identical replacement parts. Follow instructions in the Maintenance section Tool service must be performed only by qualified of this manual. Use of unauthorized parts or failure to repair personnel. Service or maintenance performed by follow Maintenance Instructions may create a risk of unqualified personnel may result in a risk of injury. -
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) -
Page 6: Symbols
If you do not understand ing, use only identical replacement parts. the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage. -
Page 7: Electrical
ELECTRICAL DOUBLE INSULATION EXTENSION CORDS Double insulation is a concept in safety in electric power When using a power tool at a considerable distance from tools, which eliminates the need for the usual three- a power source, be sure to use an extension cord that has wire grounded power cord. -
Page 8: Features
FEATURES PRODUCT SPECIFICATIONS Orbits per Minute ............................4,800 r/min. (RPM) Orbit Diameter ................................0.4 in. Motion ................................Random Orbital Power Cord ..................................6 ft. Input ............................. 120 V, 60 Hz, AC only, 0.5 Amps MOTOR CORD HOUSING AIR VENT ON/OFF SWITCH FOAM PAD APPLICATION BONNET Fig. -
Page 9: Assembly
FEATURES KNOW YOUR BUFFER / POLISHER CORD See Figure 1. The buffer/polisher has a 6 ft. power cord. The safe use of this product requires an understanding of FOAM PAD the information on the tool and in this operator’s manual as well as a knowledge of the project you are attempting. -
Page 10: Operation
OPERATION WARNING: Do not allow familiarity with tools to make you care- less. Remember that a careless fraction of a second is sufficient to inflict serious injury. WARNING: ON/OFF Always wear safety goggles or safety glasses with side SWITCH shields when operating power tools. Failure to do so could result in objects being thrown into your eyes resulting in possible serious injury. - Page 11 OPERATION WARNING: The drawstring must be tucked securely inside the bon- net before turning the buffer/polisher on. Failure to do so could result in the drawstring being caught between the motor housing and orbiting pad, increasing the risk of serious personal injury. APPLY POLISH TO THE APPLICATION BONNET Most polishes are either in paste or liquid form.
-
Page 12: Maintenance
OPERATION CHANGE TO BUFFING/POLISHING BONNET See Figure 7. Remove the application bonnet by loosening the drawstring and slipping the bonnet off the pad. Replace with buffing/ polishing bonnet, attaching it the same way as the applica- tion bonnet. Buff the surface in the same order as it was polished, starting with large flat surfaces and ending with hard-to reach areas. -
Page 13: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution Wax does not go on evenly. Too much wax on the bonnet. Remove a portion of the wax and retry. Polishing seems difficult. Bonnet may be worn. Replace bonnet. Polisher does not turn on. Bad connection to receptacle. Check to make sure plug is properly seated in outlet. - Page 14 When ordering repair parts, always give the following information: RB60 • MODEL NUMBER • SERIAL NUMBER Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-525-2579 983000-244 www.ryobitools.com...
