EPSON
P
RODUCT
Date:
11/8/04
PSB #:
PSB.2004.03.001C
Reference:
PSB.2004.03.001A
EPSON Stylus Color 3000, Stylus Pro 4000, 5000, 5500, 7000 Series, 7600 Series, 9000 Series, 9600 Series,
Product(s):
10000 Series, and 10600 Series
Subject:
Maximum Printable Area Limits for the EPSON Professional Graphic Printer line.
This bulletin was created to inform you of the maximum custom page sizes allowable for EPSON Professional Graphic products.
The tables below show the maximum page sizes allowable for the EPSON Professional Graphics printer line (Desktop and Large
Format). Although this document is meant as a guideline for the maximum page size allowable for each printer, it does not include
printable area (margin) information. Please refer to your user guide for additional information regarding the printable area (margins)
for your particular printer. There are 3 aspects that effect how long of a page your printer can output. Those 3 items are:
1. Operating System.
2. Driver Specification.
3. Software application(s) being used.
Maximum custom page size allowable per operating system (for Epson standard driver):
Stylus
Color 3000
44 in.
Macintosh
OS
44 in.
Macintosh
OS
X*
Win 9x/Me
44 in.
44 in.
Win NT
4.0/2000/XP
Print jobs being sent through the Epson standard print driver should be in the RGB format in order for color management to be
utilized properly.
*
Macintosh OS X allows you to create any paper size regardless of printer driver's limitations. Exceeding these limitations will result in your image being
cropped and printed at 8.5 x 11.
S
B
UPPORT
Stylus
Stylus
Stylus
Pro
Pro
Pro 5500
4000
5000
44 in.
44 in.
44 in.
44 in.
N/A
44 in.
44 in.
44 in.
44 in.
44 in.
44 in.
44 in.
ULLETIN
Originator: RB, CH, JD, SA
Authorization:
Total Pages: 19
Stylus
Stylus
Stylus
Pro 7000
Pro 7500
Pro 7600
90.5 in.
90.5 in.
90.5 in.
N/A
N/A
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
1
Stylus
Stylus
Stylus
Pro 9000
Pro 9500
Pro 9600
90.5 in.
90.5 in.
90.5 in.
N/A
N/A
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
90.5 in.
Stylus Pro
10000 Series
90.5 in.
90.5 in.
90.5 in.
90.5 in.

Advertisement

   Also See for Epson Stylus Pro 9500 - Print Engine

   Related Manuals for Epson Stylus Pro 9500 - Print Engine

   Summary of Contents for Epson Stylus Pro 9500 - Print Engine

  • Page 1

    Win NT 4.0/2000/XP Print jobs being sent through the Epson standard print driver should be in the RGB format in order for color management to be utilized properly. Macintosh OS X allows you to create any paper size regardless of printer driver’s limitations. Exceeding these limitations will result in your image being...

  • Page 2

    NOTE1 NOTE 1 ColorBurst RIP Print jobs being sent through the Epson PostScript driver can be either RGB or CMYK format. Settings in the RIP will determine how color management is used. Maximum page size allowable from software applications: Stylus...

  • Page 3

    All Epson large format printers use 360dpi as the input resolution (this is the resolution data is rasterized at), therefore when printing from Photoshop, the maximum page length you will be able to output to any Epson large format printer using the standard Epson print driver would be 83.33 inches (30,000 pixels / 360dpi). As for the Epson desktop products, they rasterize data at 720dpi, therefore the maximum page length obtainable with the standard print driver would be 41.67 inches (30,000 pixels / 720dpi).

  • Page 4

    For Windows Users, if you encounter partial/incomeplete prints while having Finest Detail enabled, please disable this setting. It is recommended for low resolution text and line art to sharpen their edges. For photos, this may create a massive print file that is too large for the printer driver to process correctly. The following examples show how to setup banner printing from Adobe Illustrator 8.x/9.x and CorelDRAW 9 from the PC platform.

  • Page 5

    Adobe Illustrator CS: In this example, we are creating a banner, which is 227 inches (Illustrators max. page setup). NOTE: Mac O/S 10.3.3 system is used in this example. Windows versions of this application should be very similar in functionality. Please refer to your software documentation for additional assistance. In this example, a “20 inches wide X 180 inches high”...

  • Page 6

    3. Click on File, Print, click Setup, under Tiling click on the drop down arrow, select Tile Full 4. Pages and click the Printer button. 5. When the printer setup window comes up, select your printer name and set the Roll Paper Options to: Roll Paper Banner Roll Paper Banner –...

  • Page 7

    7. Then click on Print. This will bring you back to the Print window. 8. This time click on Page Setup, you see the following screen, just click on Continue (If you don’t want to see the window again, place a check mark on Don’t Show Again box).

  • Page 8

    9. When Page Setup is open, click on the down arrow for Custom Paper Size. NOTE: When creating the custom page size, divide the banner size by a value that will make it less than the printer maximum custom page size (90.5 inches). In this example we take (180/2 = 90), therefore the custom page size created would be 20x90 (inches).

  • Page 9

    11. Under Paper Size, click on the drop down arrow and select the custom paper size you created (i.e. 20 X 180) orientation is set to portrait mode. Then click OK. 12. In the Print windows the preview pane will show 2 grids or pages. This indicates that a full image is tiled.

  • Page 10

    13. Click on General, then click the square on Reverse Order. 4. Click on Print.

  • Page 11

    NOTE 1: When enabled, the first page will be printed first, instead of the last page first. Or Change the orientation to “Reverse”, then you don’t have to check the “Reverse Order”. NOTE 2: Always select the custom page size last, if not, it will default to other paper sizes. NOTE 3: Before printing a large document, make sure you have enough ink to prevent getting an Ink Out message, causing the print job to stop and not completing the entire print.

  • Page 12

    Adobe Illustrator 8.x/9.x: In this example, we are creating a banner, which is 227 inches (Illustrators max. page setup). 1. Launch Illustrator and open or place your file in the page layout. Click on File, then Document Setup. The following screen appears. 3.

  • Page 13

    5. Click on the Paper Tab. The following appears. 6. Set the Paper Source to Roll Paper (Banner) and also enable Save Roll Paper. 7. When creating the custom page size, divide the banner size by a value that will make it less than the printer maximum custom page size.

  • Page 14

    8. After setting the custom page size and other driver settings (media type, resolution, etc.), click OK. This will bring you back to the document setup. Now double-click the “Page” tool. 9. The page should now show the following. 10. At this point you can and resize the image to fit within the printable area and print.

  • Page 15

    CorelDRAW: In this example, a banner is created at 227 inches. 1. Launch CorelDRAW and open or place an image in your page layout. 2. Adjust the page size and image for the document as shown in the following image. 3.

  • Page 16

    4. Click on the Paper Tab. The following appears. 5. Set the Paper Source to Roll Paper (Banner) and also enable Save Roll Paper.

  • Page 17

    6. When creating the custom page size, divide the banner size by a value that will make it less than the printer maximum custom page size. In this example we take (227/3 = 75.7), therefore the custom page size created would be 44x75.7 inches.

  • Page 18

    8. At this point, click File then Print. CorelDRAW will then run a pre-flight check and will show the following window.

  • Page 19

    9. Click on the Layout Tab and enable Print Tiled Pages and set any additional parameters as you see fit. 10. At this point you could check other tab settings (if necessary) and click Print Preview (recommended) if you want to see how the file will be printed or Print to output the file to your printer.

  • Page 20

    This bulletin was created to inform you how to Install and or Remove the Epson Stylus Pro 7600 and Stylus Pro 9600 inkjet printer driver on a Macintosh OS X system. If this is a fist time Epson Stylus Pro 7600 or Stylus Pro 9600 inkjet OS X printer driver installation you will only need to follow the driver installation steps.

  • Page 21

    Prior to starting the installation it is recommended you copy the installation package (example: SPro7600_16b.pkg) to your hard drive. This will save you time should you wish to reinstall the driver in the future. EPSON Professional Graphics Group Page 2.

  • Page 22

    The installer requires your Macintosh password for Authentication. Enter your Password and click OK. The Installer Introduction screen will be displayed, click CONTINUE. Read the License Agreement and click CONTINUE. You are asked to Agree or Disagree to the License Agreement click AGREE to continue the installation. EPSON Professional Graphics Group Page 3.

  • Page 23

    The Printer Driver will now be installed, a progress window is displayed during the installation. 10. When the Printer Driver installation has completed the following window is displayed, click RESTART to Finish the installation. EPSON Professional Graphics Group Page 4.

  • Page 24

    You have Two ways to Add a printer. You can use the Add button or you can select Add Printer from the Printers drop down menu, click Add. On the Add printer window you first need to select the Epson Interface Connection the printer is attached with: Only choose an...

  • Page 25

    After you choose the Epson Interface Connection, the Print Center automatically searches the connection for printers. When the search completes: Select your printer from the list by clicking on it. Next select your Page Setup. Roll Paper is the default. If your work flow will include several of the choices they can be added individually, or to save time you can add all the choices by selecting All.

  • Page 26

    To make the printer the Default printer highlight the printer then go to the Printers Menu and select Make Default or click the Make Default button. The Default printer will be highlighted in the Printer List: EPSON Professional Graphics Group Page 7...

  • Page 27

    10. To view the Job Status of a printer double click on it in the Printer List to display its information and status: EPSON Professional Graphics Group Page 8...

  • Page 28

    Then from the new Printer List window select your printer and click OK. From the Epson Printer Utility you can Check the Status of Ink-Paper-and the printer itself, perform print head Nozzle Checks, Clean the print head, or perform Print Head Alignments.

  • Page 29

    Before installing a New Driver you must first properly remove the existing Driver and all of its components. Open the Epson Driver from any application and select print. Remove all user created “Presets” that were created for the printer you are removing. From the Presets drop down menu select the Preset (example: MYPRESET) then select Delete..

  • Page 30

    In the next steps you will be dragging Files or Folders to the Trash. OS X requires you to have proper “Ownership & Permissions” to the Epson folder on your OS X hard drive. Highlight the Epson folder then GoTo File, Get Info and select “Ownership &...

  • Page 31

    4.1.2 Drag the printers Preferences to the TRASH. The second option is to drag the entire Epson folder to the Trash. Dragging the entire Epson folder to the Trash Deletes ALL Epson Printers. From the Receipts folder Drag the Printers Package information to the TRASH.

  • Page 32: Installation Instructions

    This bulletin provides instructions for installing and configuring a Mac OS X Client with your existing EPSON hardware or software RIP. If your EPSON Professional Wide Format printer was bundled with one of the RIP packages listed below, or if you had purchased the RIP as an option, then you can configure a Mac OS X Client with OS Version 10.2 and above for PostScript printing...

  • Page 33

    AppleTalk 2. Click on the button. Then select from the top sub-menu and your AppleTalk zone if applicable. Print Center 3. The should scan the network and find all your devices. Select your printer Printer Model Other from the list and click on the sub-menu.

  • Page 34

    IP Printing Installation: Print Center Applications - Open the , which can be found on your HDD under Utilities IP Printing 2. Click on the button and select from the sub-menu. Printer’s Address 3. Enter the IP Address of the Postscript Server under .

  • Page 35

    4. Navigate to the location of your PPD file. After selecting the PPD file it should reflect the Printer Model name of the printer under the section. Click on the button. 5. The Print Center should now show the Queue that you typed along with the IP address. 6.

  • Page 36

    This phenomenon is present to varying degree in all forms of pigmented ink printing and it is not possible to totally eliminate it. Unlike the EPSON Stylus Pro 5500 and the EPSON Stylus Pro 10000, which have hardware features designed to reduce Metamerism, the earlier model EPSON Stylus Photo 2000P, Stylus Pro 7500 and Stylus Pro 9500 do not have this same capability.

  • Page 37

    EPSON Stylus Pro 9500 http://support.epson.com/hardware/printer/inkjet/pro95_/index.html Operating System Driver File Name Windows NT 4.0 Epson10019.exe Windows 95/98/Me Epson10018.exe Windows 2000 Epson10017.exe Macintosh 8.51-9.22 Epson10021.sea.hqx...

  • Page 38

    44 in. 44 in. 44 in. 590.5 in. 590.5 in. 90.5 in. 590.5 in. 590.5 in. Print jobs being sent through the Epson standard print driver should be in the RGB format in order for color management to be utilized properly.

  • Page 39

    44 in. See NOTE Professional Print jobs being sent through the Epson PostScript driver can be either RGB or CMYK format. Settings in the RIP will determine how color management is used. Maximum page size allowable from software applications: Stylus...

  • Page 40

    360dpi as the input resolution (this is the resolution data is rasterized at), therefore when printing from Photoshop, the maximum page length you will be able to output to any Epson large format printer using the standard print driver would be 83.33 inches (30,000 pixels / 360dpi). As for the Epson desktop products, they rasterize data at 720dpi, therefore the maximum page length obtainable with the standard print driver would be 41.67...

  • Page 41

    Adobe Illustrator 8.01: In this example, we are creating a banner, which is 227 inches (Illustrators max. page setup). 1. Launch Illustrator and open or place your file in the page layout. 2. Click on File, then Document Setup. The following screen appears. 3.

  • Page 42

    5. Click on the Paper Tab. The following appears. 6. Set the Paper Source to Roll Paper (Banner) and also enable Save Roll Paper.

  • Page 43

    7. When creating the custom page size, divide the banner size by a value that will make it less than the printer maximum custom page size (not necessary for OS/Drivers that support 590.5 inches). In this example we take (227/3 = 75.7), therefore the custom page size created would be 44x75.7 inches. The reason for this is to save media.

  • Page 44

    8. After setting the custom page size and other driver settings (media type, resolution, etc.), click OK. This will bring you back to the document setup. The page should now show the following. 9. At this point you can and resize the image to fit within the printable area and print.

  • Page 45

    CorelDRAW 9: In this example, we are creating a banner, which is 227 inches. 1. Launch CorelDRAW and open or place an image in your page layout. 2. Adjust the page size and image for the document as shown in the following image. 3.

  • Page 46

    4. Click on the Paper Tab. The following appears. 5. Set the Paper Source to Roll Paper (Banner) and also enable Save Roll Paper.

  • Page 47

    6. When creating the custom page size, divide the banner size by a value that will make it less than the printer maximum custom page size (not necessary for OS/Drivers that support 590.5 inches, unless the document is beyond that size ). In this example we take (227/3 = 75.7), therefore the custom page size created would be 44x75.7 inches.

  • Page 48

    8. At this point, click File then Print. CorelDRAW will then run a pre-flight check and will show the following window.

  • Page 49

    9. Click on the Layout Tab and enable Print Tiled Pages and set any additional parameters as you see fit. 10. At this point you could check other tab settings (if necessary) and click Print Preview (recommended) if you want to see how the file will be printed or Print to output the file to your printer.

  • Page 50

    RIP Station 5100 Series III. Description of Change: The initial release of the EPSON Fiery RIP Station 5100 Series III was limited on the media list it supported. This update provides those additional medias and profiles for use with the RIP Station 5100 Series III.

  • Page 51

    Downloading the Output profiles: 1) Open "Profile Manager". Refer to the RIP Station 5100 Series III “Color Guide” for details on using ColorWise ProTools. 2) Click "Browse", and select Profile Folder [Color (PC) or ColorSync (Mac)]. If the view in Profile Manager is set for description, you will see several descriptions listed on the left hand side of the screen.

  • Page 52

    Media and Print mode settings: Media: Print Mode: Patch Used (Y/N) Photo Glossy Paper Reserve2 Photo Semigloss Paper Reserve2 Premium Luster Photo Paper Reserve2 Smooth Fine Art Paper Reserve2 Texture Fine Art Paper Reserve2 Canvas Reserve2 ReserveMedia1 Reserve1 Adhesive Vinyl Synthetic Paper Tyvek Brillion Synthetic Paper...

  • Page 53

    Instructions for USB and Parallel Connection At the EPSON Printer Utility Setup screen highlight your printer then click OK. Next, you will see the progress bar followed by the Windows Logo verification screen. Click on Continue Anyway option to continue.

  • Page 54

    As instructed at following EPSON Printer Utility Setup screen Power ON your printer. Your printer will be detected automatically. Select Install the software automatically (Recommended) option then click NEXT to continue at the Found New Hardware Wizard screen. Your will be prompted with Windows Logo verification screen again, Click on Continue Anyway option to proceed to the next step.

  • Page 55

    Instructions for IEEE 1394 Connection At the EPSON Printer Utility Setup screen highlight your printer then click OK. Next, you will see the progress bar followed by the Windows Logo verification screen. Click on Continue Anyway option to continue. As instructed at the following EPSON Printer Utility Setup screen Power ON your printer. The IEEE 1394 card will be detected automatically.

  • Page 56

    After the driver files have been copied to you local hard disk drive, click on Finish to compete the driver installation. To install Epson Status Monitor 3 follow the instructions under section heading Installation Procedure for Epson Status Monitor 3.

  • Page 57

    Windows Logo verification screen. Click on Continue Anyway option to continue. At this point DO NOT POWER On your printer and at the EPSON Printer Utility Setup screen click on Stop searching button to continue with the installation. Next, you will see the progress bar followed by the Windows Logo verification screen.

  • Page 58

    Power ON your printer next, then you will need to redirect the port to the Type B Ethernet card’s IP address. Click on the Start button, then Control Panel followed by Printers and Other Hardware then go to Printers and Faxes. Right click on the printer icon and choose Properties from the pop-up menu.

  • Page 59

    If Windows identifies the Epson card automatically, click Finish at the Completing the Add Standard TCP/IP Printer Port Wizard. If your card is not identifies as an Epson network card automatically, click on Custom and then Settings. On the next screen select LPR, type PASSTHRU as the Queue Name, check SNMP Status Enabled and click OK. Click Next on the Add Standard TCP/IP Printer Port Wizard screen to continue with the installation, and then click Finish on the next screen.

  • Page 60

    On the next screen click on Apply and then on Close to finish the installation. Your printer driver installation has been completed and the printer is ready to print. To install Epson Status Monitor 3 follow the instructions under section heading Installation Procedure for Epson Status Monitor 3.

  • Page 61

    Installation procedure for Epson Status Monitor 3 At the EPSON Status Monitor 3 setup screen highlight your printer then click OK. Next, you will see the progress bar followed by a window indicating that EPSON Status Monitor 3 is complete.

  • Page 62

    EPSON RODUCT UPPORT ULLETIN Date: 09/06/2001 PSB No.: PSB.2001.09.002 Reference: N/A Originator: RR Authorization: Affected Product(s): Stylus Pro 7000 Series, 9000 Series and 10000 Series Large Format Printers Subject: Printer Connectivity Issue due to Incorrect Model Name Selection – Printer Reports Off-Line Issue Description: 1.

  • Page 63

    Classic and 9.1). 3. To run a Classic application, just double–click on it or a document created with the application. A) The following Epson models are supported in OS X Classic mode when using the connector type(s) described in the chart below.

  • Page 64

    IEEE 1394 Reference Table below for the location of the latest drivers for your specific EPSON printer and operating system. If the driver your need is listed as “Update on the Web” the most current driver can be found on the EPSON Internet Support Web Site at: http://support.epson.com/filelibrary.html...
