Installing The Database And Load Balancer With Clustering (Configurations X-N, And X-Y-N) - Lexmark C792 Administrator's Manual

Installing Lexmark Document Distributor
11
Click Finish.
12
Allow the installation to complete, and then click Done.
Installing the database and load balancer with clustering (configurations X‑N, and
X‑Y‑N)
Notes:
• Before installing LDD, the failover clusters must be set up using Microsoft Windows Server Clustering Services.
•
Make sure to set up all firewall exceptions on all physical and logical nodes in the cluster before installing LDD.
To set up firewall exceptions on a Windows Server 2008 cluster node, do the following:
1
Create a temporary directory.
2
From the install\Cluster_Config_Script of the LDD installation package, copy all the batch files (2008-cluster-*.bat)
to the temporary directory.
3
Open a command prompt window as an administrator.
a
Click Start > All Programs > Accessories.
b
Right-click Command prompt, and then click Run as administrator.
c
If the User Account Control dialog appears, then confirm that you want to start the command prompt as an
administrator, and then click Continue.
4
From the command prompt window, change the current directory to the temporary directory you created.
5
Run the batch files (2008-cluster-*.bat) by typing the batch file name, and then pressing Enter.
Note: Do not run the LDD DB firewall batch file (2008-cluster-firewall-config-DB.bat) if you are using an Oracle
database for LDD.
Installing the database
If you are installing the LDD database on a Microsoft server cluster, then install the Microsoft C++ 2005 Redistributable
package on all physical nodes/servers in the cluster. If these files are not installed, then the LDD database cluster
resource will not initiate failover to the cluster node where LDD is not installed.
Depending on the operating system installed on the cluster node (x86 or x64), run the Microsoft C++ 2005
Redistributable package, found in the packages folder of the LDD installation package (vcredist_x86*.exe or
vcredist_x64*.exe).
Note: If you are using an Oracle database, then do not install the LDD database.
Do the following on the primary node of the failover cluster that will run the database:
1
From the LDD installation package, run Setup.exe.
2
From the Lexmark Solutions installation window, click Install Enterprise System > Install Database.
3
Click Agree to accept the license agreement.
4
Specify a location on a shared cluster disk for the installation, and then click Next.
Note: The installation path cannot contain double‑byte characters.
5
Select the IP address or host name of the logical host of the cluster.
25
