Dynex DX-DPF0712L User Manual

User manual (english)
Hide thumbs Also See for DX-DPF0712L:
Table of Contents

Advertisement

Quick Links

See also: Manual , Manual Del Usuario
Digital Picture Frame
DX-DPF0712L
U S E R G U I D E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DX-DPF0712L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dynex DX-DPF0712L

Summary of Contents for Dynex DX-DPF0712L

  • Page 1 Digital Picture Frame DX-DPF0712L U S E R G U I D E...

  • Page 2: Table Of Contents

    Digital Picture Frame Contents Important safety instructions ........2 Features ..............4 Setting up your picture frame ........9 Maintaining ............24 Troubleshooting .............25 Specifications ............26 Legal notices ............27 90-day limited warranty .........29 Important safety instructions Always follow these basic safety precautions when using your digital picture frame.
  • Page 3 Important safety instructions Placement—To prevent fire or electric shock, do not expose this digital picture frame to rain or moisture. To prevent it from falling, do not place it on an unstable cart, stand, tripod, bracket, or table. Keep the unit away from strong magnets, heat sources, direct sunlight, and excessive dust.

  • Page 4: Features

    Features Features • Displays digital pictures (JPEG format) and picture slideshows without a computer • Displays pictures directly from an inserted portable memory device (not included) • Has a bright, clear TFT LCD screen • Is compatible with a wide variety of memory cards, including: •...
  • Page 5 BACK MENU ENTER INFO ZOOM Portrait POWER Model: DX-DPF0712L Power: 5VDC, 1.0A (5W) Manufactured for Dynex Products 7601 Penn Avenue South Richfield MN USA 55423 www.dynexproducts.com Description Memory card slot, supports: • Secure Digital™ (SD) • SDHC™ • MultimediaCard (MMC™) •...
  • Page 6 Features Back buttons BACK BACK MENU MENU ENTER ENTER INFO INFO ZOOM ZOOM Button Description MENU/ Press to open the menu. Press and hold for two seconds to enter standby mode. In the menu, press to move left or to display the next picture. ZOOM Press to magnify the picture.

  • Page 7: Remote Control

    Features Remote control RM-DXDPF0712L Button Description MENU Press to open the menu. SLIDESHOW Press to start a slideshow or toggle the multi-image Display mode. (up) Press to move the selection up. ENTER Press to select the highlighted option or to pause and resume the slideshow.
  • Page 8 Features Button Description (left) PREV Press to move the menu selection left, display the previous picture, or select the previous file. (down) Press to move the menu selection down. BACK Press to go back a screen. INFO Press to display information about the picture. ZOOM Press to magnify the picture.

  • Page 9: Setting Up Your Picture Frame

    Setting up your picture frame Setting up your picture frame Setting up the remote control To set up the remote control: • Remove the plastic tab that extends past the bottom edge of the remote control. This tab protects the battery. The remote control will not work until it is removed.

  • Page 10: Setting Up Your Picture Frame

    Rotate the stand counter-clockwise to the landscape (position B) or portrait (position C). Landscape BACK MENU ENTER INFO ZOOM Portrait POWER Model: DX-DPF0712L Power: 5VDC, 1.0A (5W) Manufactured for Dynex Products 7601 Penn Avenue South Richfield MN USA 55423 www.dynexproducts.com...
  • Page 11 Setting up your picture frame Plug the AC power adapter into the frame’s DC power connector and into an AC power outlet. Slide the power switch to the ON position. The frame automatically starts playing a slideshow of the pictures stored in internal memory.
  • Page 12 Using your frame Using your frame You can use your digital picture frame to: • Play a slideshow of pictures • Adjust a picture’s view • Change display settings Playing slideshows To play an instant slideshow from a portable memory device: Insert a memory card into the memory card slot or a USB device into the USB port.
  • Page 13 Using your frame To manually play a slideshow from an inserted portable memory device or from internal memory: Insert a memory card into the memory card slot or the USB device into the USB port. A slideshow of pictures from the portable memory device automatically starts to play.
  • Page 14 Using your frame Copying pictures to internal memory You can copy a single picture, multiple pictures, or all pictures from an inserted portable memory device to the frame’s internal memory. Notes: • Using the frame alone, you cannot copy pictures from the internal memory to portable memory device, and you cannot copy pictures from one portable memory device to another.
  • Page 15 Using your frame Press or highlight the portable memory device you want to copy from, then press ENTER/ . The Thumbnail screen opens. Press or to highlight each picture you want to copy, then press (SELECT) to mark it. A check mark appears in the upper-right corner of each marked thumbnail.
  • Page 16 Using your frame Deleting pictures from internal memory Note: You cannot delete pictures from an inserted portable memory device. Because you cannot copy pictures back from the frame to a portable memory device, the frame should not be considered your primary picture storage method.
  • Page 17 Using your frame Press or to highlight each picture you want to delete, then press (SELECT) to mark it. A check mark appears in the upper-right corner of each marked thumbnail. Mark as many pictures as you want to delete. Press (DEL/COPY), then press to select...
  • Page 18 Using your frame Customizing slideshows You can set up a slideshow using either all of the pictures or selected pictures. To set up a slideshow of selected pictures: Note: A slideshow of selected pictures can only be set up by using the remote control.
  • Page 19 Using your frame Press or to highlight the picture you want to include in the slideshow, then press (SELECT) to mark it. A check mark appears in the upper-right corner of each marked thumbnail. Mark as many pictures as you want to add to the slideshow. Press (DEL/COPY), then press to select Play...
  • Page 20 Using your frame To rotate a picture automatically based on EXIF orientation: Note: EXIF (Exchangeable Image File) data is information stored by a digital camera as it records a picture. The camera detects and stores the orientation of the camera is in when a picture is captured. •...
  • Page 21 Using your frame Setting viewing options You can change all of the viewing options in the menu using the buttons on the top of the frame or on the remote control. You can display the menu at any time by pressing MENU. Only the available setup options are displayed for each menu.

  • Page 22: Menu Options

    Using your frame Menu options The following table lists and describes menu options: Menu Settings Description option Slideshow Slideshow interval Sets the interval between each picture Settings • 5 Seconds transition in a slideshow. • 10 Seconds • 30 Seconds •...
  • Page 23 Using your frame Menu Settings Description option Slideshow Slideshow shuffle Displays pictures in a different Settings • On (random) order than they appear on (continued) • Off the portable memory device. Panorama Scroll When Panorama Scroll is enabled, • On pictures that were taken in panorama •...

  • Page 24: Maintaining

    Maintaining Menu Settings Description option Sort image mode File name A-Z Lets you sort files in the order you File name Z-A select. Date, oldest to newest Date, newest to oldest Factory Settings Demo Mode On/Off Displays pictures from internal memory for demo purposes.

  • Page 25: Troubleshooting

    Troubleshooting Troubleshooting Problem Solution The frame will not turn The power adapter is not securely connected to the picture frame, or the power switch is not on. Check power adapter connections, then switch the power on. A portable memory • Make sure that the portable memory device is one of the device is inserted in the supported formats and that the files on the device are frame, but you can’t...

  • Page 26: Specifications

    Specifications Specifications Screen size 7" (178 mm) Screen format Widescreen Memory card formats • Secure Digital™ (SD) • SDHC™ • MultimediaCard (MMC™) ® • Memory Stick • Memory Stick PRO Duo™ (requires an adapter - not included) • xD™ • microSD™ (requires an adapter - not included) File formats Standard JPEG USB (type A) port...

  • Page 27: Legal Notices

    Legal notices Legal notices FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 28: Legal Notices

    Legal notices...

  • Page 29: 90-Day Limited Warranty

    Products and parts replaced under this warranty become the property of Dynex and are not returned to you. If service of Products and parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 30 • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Dynex to service the Product • Products sold as is or with all faults •...
  • Page 31 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
  • Page 32 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. © 2011 BBY Solutions, Inc. All rights reserved. DYNEX is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
