Dynex DX-DPF0712L Quick Setup Manual

Congratulations on your purchase of a
high-quality Dynex product. Your new digital
picture frame represents the state of the art in
digital picture frame design and is designed for
reliable and trouble-free performance.
Package contents
• Digital picture frame
• AC power adapter
• Remote control with battery (CR2025)
• User Guide

• Quick Setup Guide

ATTENTION: DISABLE DEMO MODE!
Your frame comes with a store demo mode
enabled by default.
To disable store mode and enable buttons:
1 Turn the frame on.
2 Remove the remote control battery tab.
3 Point the remote control at the frame and
press ENTER.
ON OFF
PRESS
Set up your frame
Setting up the frame
1 Align and insert the stand with the arrow in the
unlocked position.
2 Rotate the stand counter clockwise to Landscape (B)
or Portrait (C) position.
BACK MENU
ENTER
INFO ZOOM
Portrait
POWER
Model: DX-DPF0712L
Power: 5VDC, 1.0A (5W)
Manufactured for Dynex Products
7601 Penn Avenue South
ON OFF Richfield MN USA 55423
www.dynexproducts.com
3 Plug the AC power adapter into the frame's DC power
connector and into an AC power outlet.
RM-DXDPF0712L RM-DXDPF0712L
Side and back
BACK MENU
ENTER
INFO ZOOM
POWER
Model: DX-DPF0712L
Power: 5VDC, 1.0A (5W)
Manufactured for Dynex Products
ON OFF 7601 Penn Avenue South
Richfield MN USA 55423
www.dynexproducts.com
# DESCRIPTION
1 Memory card slot (SD/SDHC/MMC/Memory Stick/xD)
(Memory Stick Pro Duo/microSD require an adapter - not included)
2 USB port
3 DC 5 V power connector
4 Navigation / Function buttons
5 Power On/Off switch
6 Rotating stand
Quick Setup Guide |
4 Slide the power switch to the ON position. The
frame automatically turns on and starts playing a
slide show of the pictures stored in internal
memory. This slide show is called Demo mode.
5 Set up the remote control.
Remove the plastic tab that extends past the
bottom edge of the remote control. This tab
protects the battery. The remote control will not
Landspace
work until the plastic tab is removed.
For more information on using the remote
control, see your User Guide.
6 To turn off Demo mode, point the remote control
at the front of the frame and press ENTER.
Navigation / Function buttons
Landspace
Portrait
BACK BACK MENU MENU
ENTER ENTER
INFO INFO ZOOM ZOOM
DX-DPF0712L 7" Digital Photo Frame
RM-DXDPF0712L RM-DXDPF0712L
90-day limited warranty
Visit www.dynexproducts.com for details.
Contact Dynex:
# CONTROL DESCRIPTION
1 MENU / Press to display the Setup menu. Press
For customer service, call 1-800-305-2204
and hold for two seconds to enter
www.dynexproducts.com
standby mode.
2 Press to move left or display the next
picture.
© 2011 BBY Solutions, Inc., All Rights Reserved. Distributed
Press to magnify the picture.
3 ZOOM
by Best Buy Purchasing, LLC
Press to move down in a list or menu.
4
7601 Penn Avenue South, Richfield, MN USA 55423-3645
Press to display information about the
5 INFO
DYNEX is a trademark of BBY Solutions, Inc. All other
displayed picture.
products and brand names are trademarks of their
Press to move right or to display the
6
respective owners.
previous picture.
During a slideshow, stops and returns
7 BACK
back to thumbnail / file list.
Press to play or pause a slide show or to
8 ENTER/
confirm a setting in a menu (enter).
9
Press to move up in a list or menu.
Start your slide show
Viewing pictures on a memory
card or USB memory device
Insert a memory card or USB memory
device into the memory card slot or the
USB port. A slide show of pictures from
the memory card or USB memory device
automatically starts to play.
Caution: Memory cards fit into the card
slot in one direction only. Do not force a
memory card into the slot.
The card should fit snugly when inserted
correctly. Some cards require an adapter
to fit correctly. For more information on
supported memory cards, see
"Specifications" in the User Guide.
For more information about using your
digital picture frame, see your User
Guide.
ENGLISH 11-0575
