3. Insert six D size (R20) batteries into the battery
compartment. Make sure that the batteries are facing the
correct direction by verifying that the positive (+) and
negative (-) symbols in the battery compartment match up
with the same symbols on the batteries.
4. It is recommended that the batteries be removed
when it is not in use for an extended period of time.

Antenna Set-up

Positioning the XM Antenna
The antenna that comes with the SKYFi
receive XM's signal from XM's satellites and/or, depending on where you live, XM's land
based repeaters. It is recommended that the antenna be positioned near a south-facing
window or outdoors with a clear view of the southern sky in order to receive the satellite
signal. In some cases, it will be possible to receive XM's signal through standard home
walls or a roof.
To position your antenna, first set up the Audio System as described earlier in this manual.
Next, position the antenna until you receive the strongest possible satellite signal. If the
satellite signal is not available, you can optimize it for a terrestrial signal (where available).
Optimizing Antenna Position/Signal
Press the "Power" button on the SKYFi
Press the "menu" button.
Using the scroll wheel, turn the wheel until
"Antenna Aiming" is highlighted.
With "Antenna Aiming" still highlighted, press the
"enter" button found in the center of the scroll wheel.
The display will show the strength of the satellite and/
or terrestrial signals. The antenna signal strength is
indicated by the number of filled bars.
Installing the XM Antenna on the rear of the Audio System.
6
When outdoors with a view of the southern sky, or in an area of repeater coverage, or
when receiving a strong signal indoors, you can conveniently mount the antenna directly
on the back of the Audio System.
1. Remove the battery and antenna cable storage compartment cover as previously
described, wind the antenna around the two cable hooks, leaving several inches of cable
free, and replace the cover.
TM
Audio System is a high-gain antenna that can
TM
Receiver to start the Audio System.
