Haier LV1513 User Manual

Lcd tv/dvd player combo.
Hide thumbs

Advertisement

ELD1547 LV1513 LV1913 ALD1967
/
/
/
LCD TV/DVD Player Combo
USER MANUAL
Please read this manual carefully
before using this TV set and keep it
for future reference.

Advertisement

   Related Manuals for Haier LV1513

   Summary of Contents for Haier LV1513

  • Page 1 ELD1547 LV1513 LV1913 ALD1967 LCD TV/DVD Player Combo USER MANUAL Please read this manual carefully before using this TV set and keep it for future reference.
  • Page 2 WARNING AND CAUTION CAUTION RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.FOR ANY PROBLEM, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
  • Page 3 IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
  • Page 4 Safety Instructions PRECAUTIONS FCC WARNING-This equipment may CAUTION:USE OF CONTROLS OR generate or use radio frequency ADJUSTMENTS OR PERFORMANCE energy.Changes or modifications to this OF PROCEDURES OTHER THAN equipment may cause harmful THOSE SPECIFIED HEREIN MAY interference unless the modifications are RESULT IN HAZARDOUS RADIATION expressly approved in the instruction EXPOSURE.
  • Page 5: Table Of Contents

    CONTENT Safety Notice Items................... Front Panel Controls.................. Connection Options................... Remote Control Key Functions..............Remote Control .................. Installing Batteries.................. Connection Instructions................Grounding....................External equipment Connections.............. Antenna Connection................PC Setup..................... VCR Setup................... Cable TV Setup..................External AV Source Setup..............Basic Operating Instructions............... Turn on the LCD-TV.................
  • Page 6: Safety Notice Items

    Safety Notice Items Incorrect usage may cause fire or electric shock. To prevent this, please do as required when you are installing, using and cleaning this machine. To insure your safety and extend the life-span of LCD-TV, please read the following items carefully before using: l Please read and understand all the instructions before operation;...
  • Page 7: Front Panel Controls

    Front Panel Controls ELD1547 LV1513 LV1913 ALD1967 TV/AV MENU VOL- VOL+ CH+ POWER Control Panel Function 1. Power supply switch 2.TV/AV Selects the input signals: TV/AV/S-VIDEO/PC/COMPONENT 3. MENU Press to select the main menu 4. VOL- Volume down / Left orientation to adjust the item in the OSD...
  • Page 8: Connection Options

    Connection Options DVD insert STOP PLAY/PAUSE OPEN/CLOSE The above figure is for reference only, connections may differ depending upon the models PREV NEXT Please see the real set of the DVD position Antenna Input Connect cable or antenna signals to the TV, either direc- tly or through your Earphone port...
  • Page 9: Remote Control Key Functions

    Remote Control Key Functions When using the remote control, aim it Buttons on the remote control towards the remote sensor on the TV Standby DVD Open/close POWER TV/AV TV/DVD OPEN/CLOSE Input selection TV Sleep button SLEEP Q.VIEW MUTE INFO TV/DVD Mute Return to Previous Channel in TV mode Call Screen Infromation...
  • Page 10: Remote Control

    Remote Control Installing Batteries Remove the battery cover. Insert two size AA batteries matching the +/-polarities of the battery to the +/- marks inside the battery compartment. Precautions As strong light may interfere with the Make sure that there is no signals, change your position to obstacle between the remote operate the remote control if...
  • Page 11: Connection Instructions

    Connection Instructions Grounding Ensure that you connect the grounding / earth wire to prevent possible electric shock. If grounding methods are not possible, have a qualified electrician install a separate circuit breaker. Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes. External Equipment Connections Antenna Connection - Antenna or Cable Service with a Cable Box Connections...
  • Page 12: Pc Setup

    Connection Instructions PC Setup You can use your LCD-TV as a monitor for your personal computer using a VGA cable (not supplied). Connection and use steps: 1.Read the user guide supplied with your computer and ensure that it has a VGA connector; 2.Make sure that the power of the LCD -TV and the PC are off;...
  • Page 13: Vcr Setup

    Connection Instructions VCR Setup - To avoid picture noise (interference), leave an adequate distance between the VCR and TV Connection and use steps: 1.Read the user guide supplied with your AV devices and ensure that it has Composite or S-Video connectors; 2.Make sure that the power of the LCD-TV and the AV device are off;...
  • Page 14: Cable Tv Setup

    Connection Instructions Cable TV Setup - After subscribing to a cable TV service from a local provider you can watch cable TV programming. The TV cannot display TV programming unless a TV tuner device or cable TV converter box is connected to the TV. - For further information regarding cable TV service, contact your local cable TV service provider(s).
  • Page 15: Basic Operating Instructions

    Basic Operating Instructions Turn on the LCD-TV When the POWER button is pressed and the LCD-TV is turned on, the indicator light on the front of the LCD-TV POWER TV/AV TV/DVD OPEN/CLOSE SLEEP Q.VIEW MUTE INFO changes from red to green(or from dark to light). When the LCD-TV is turned off using the power button, the LCD-TV will go into standby mode and the indicator light turns red(or P.MODE...
  • Page 16: Select The Tv Channel You Want

    Basic Operating Instructions Select the TV Channel You Want You can use the number buttons on the remote control to directly select TV channels. And you can press the buttons on the remote control or on the panel to make a selection.
  • Page 17: Button

    Basic Operating Instructions - button Press to select additional channels (digital and analog) being broadcast by the same station. For example, to select digital channel “11.1”, press “11”, then press “-” and “1”; to select analog channel 13.0, press 13 first, then press - 0.(You must press - and 0 when you select analog channel.
  • Page 18: Menu Operations

    Menu Operations * In this manual, the OSD (On Screen Display) may be differ from your TV These are examples to illustrate the TV's operation. Press TV/AV to select the input source. The menu for each source may be different . 1.
  • Page 19: Video Menu Options Continued

    Menu Operations Video Menu Options continued 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference . 4. Repeat step 2 and step 3 until desired picture quality has been achieved . Function: BRIGHTNESS :Adjust the brightness of the picture .
  • Page 20: Audio Menu Options Continued

    Menu Operations Audio Menu Options continued You can adjust sound options to the levels you prefer. 2. Press CH+/CH- button to enter the audio menu and to go up and down to select the desired option . 3.Press VOL+/VOL- button to increase and decrease the level to adjust the selected option to your preference .
  • Page 21: Function Menu Options

    Menu Operations Function Menu Options 1. Press MENU button and VOL+/VOL- until the following menu appears on the screen. FUNCTION INPUT SOURCE LANGUAGE ENGLISH CC MODE NTSC CAPTION DTV CAPTION LOCK BLUE SCREEN ASPECT RATIO NORMAL TIME OSD TIMEOUT SHORT RESET 2.
  • Page 22: Function Menu Options Continued

    Menu Operations Function Menu Options Continued Note: Select CC1 for full translation of the primary language such as English in your area. Select CC2 for secondary language translation such as French or any other language that may be broadcast in your area. .DTV CAPTION (can only be available in DTV):Press CH+/- to select DTV CAPTION and VOL+ to enter .
  • Page 23 Menu Operations Function Menu Options Continued Text Opacity: Specify the opacity for the text color. Text Color: Select the text color or the opacity of the text box of caption display according to your own preference. Select a color and one of the opacity options. Edge Color: Press VOL+/VOL- to select the edge color according your own preference Edge Type: Press VOL+/VOL- to select the edge color according your own...
  • Page 24: Adjust Menu Options

    Menu Operations Function Menu Options Continued TIMER ON ON TIME MODE --:-- ON TIME --:-- Press CH+/CH- to select MODE and VOL+/VOL- to set it OFF/DAILY/ONCE. Press CH+/CH- to select ON TIME and VOL+ to enter. Press VOL+/VOL- to select the position you want to change and CH+/CH- to set.
  • Page 25: Adjust Menu Options Continued

    Menu Operations Adjust Menu Options Continued Functions: AUTO CONFIG : Automatically adjusts picture location frequency and phase parameters . PHASE : Removes any horizontal distortion and clears or sharpens the displayed characters . CLOCK : Adjust the TFT-LCD to match the PC input source clock frequency H POSITION : Picture horizontal position adjust V POSITION : Picture vertical position adjust .
  • Page 26: Channel Menu Options Continued

    Menu Operations Channel Menu Options Continued SKIP : If you want skip a channel , press VOL+/VOL- to select ON , and this channel will be skipped next time when you press CH+/CH- . You can press the digit buttons to select the channel . If you want to restore the channel , select OFF.
  • Page 27: Lock Menu Options Continued

    Menu Operations Lock Menu Options Continued LOCK CHANGE PASSWORD PARENTAL LOCK MPAA RATING PG RATING TV-14 PG CONTENTS CA ENG RATING CA FREN RATING DOWNLOAD RATING This function enables you to block certain TV channels in accordance to the requirements established by the FCC. PARENTAL LOCK: Press VOL+/VOL- button to select ON or OFF.
  • Page 28 Menu Operations Lock Menu Options Continued PARENTAL LOCK TECHNOLOGY: The "P.L. Technology" allows you to use U.S. and Canadian Movies and TV PROGRAMS Guide ratings to block certain types of TV programs and movies. To clearly understand TV program rating codes, read the following information: U.S.
  • Page 29 Menu Operations Lock Menu Options Continued To clearly understand Canadian program rating codes, read the following list: Canadian English Rating Chart This type of programming is intended for children under age 8. There is no offensive language, nudity or sexual content. C8+:These types of rated programs are generally considered acceptable for children 8 years and over.
  • Page 30: Dvd Features

    DVD Features Basic Playback Preparations Preparations Stop playback Stop playback 1. Press STOP button to go to stop mode, the TV Press the TV/DVD button on the remote control screen will show the start logo. With some discs, to enter the DVD status. such as DVD or CDs, the player can resume playback from the point where it was stopped.
  • Page 31: Advanced Playback

    DVD Features(Continued) Advanced Playback IMPORTANT NOTE: ALL DESCRIBED FUNCTIONS A FOR DVD DISCS. IF YOU PLAY OTHER DISC FORMATS THE OPERATION AND ON SCREEN DISPLAY WILL BE DIFFERENT. PROGRAM PROGRAM CAPTION SUBTITLE Press " SUBTITLE ", the screen will display "SUBTI- When playing discs, press "PROGRAM"...
  • Page 32: Special Function Playback

    Special Function Playback JPEG DISC PLAYBACK When a disc containing standard JPEG picture files is inserted into the player, a navigation menu will be displayed automatically. Use the UP and DOWN cursor buttons to select a file then press PLAY/ENTER. The slide show will commence. Press PREVIOUS or NEXT to move between pictures.
  • Page 33: Dvd System Setup

    DVD System Setup DVD System Setup General Setup Process 1.Press the SETUP button, the SETUP General Setup Page,Preference ..General Setup Page.. Page will be displayed in turn. 4 3:Ps Tv Display Angle Mark 4 3:Lb 2.Press CH+/- b to select, the Osd Lang 16 9 item, then press...
  • Page 34 DVD System Setup(Continued) DVD System Setup General Setup Page ..General Setup Page.. Tv Display ANGLE MARK: Users can select a particular Angle Mark Osd Lang camera angle when playing a DVD which offers Caption multiple angles. Screen Saver Off This item allows you to set Angle Mark ON or OFF. ..General Setup Page..
  • Page 35 DVD System Setup(Continued) DVD System Setup Preference Page The Preference Page is only available when there is no disc in the player. SETUP PARENTAL: The parental control function works in ..Preference Page.. conjunction with the 1 Kid Saf Parental different censorship classes Password 3 Pg 4 Pg 13...
  • Page 36 DVD System Setup(Continued) DVD System Setup DEFAULT: Resets all settings SETUP ..Preference Page.. (except password and parental lock status) for this DVD player Parental back to the manufacturers Password Reset original settings. Press ENTER Default to perform the reset. PLAY/ENTER Note: Some functions may not be available depending on the type of disc.
  • Page 37: Playable Discs

    Playable Discs The following discs can be played: You cannot play discs other than those listed above. You cannot play non-standardized discs, even if they may be labelled as above. The performance of CD-R or CD-RW disc depends on the way the disc was burned. In a few cases, their performance may not be consistant or may not even operate at all.
  • Page 38: Disc Protection And Dvd Characteristics

    Disc Protection and DVD Characteristics...
  • Page 39: Troubleshooting Guide

    Troubleshooting Guide To assist in location possible faults use help guide below Troubleshooting Verify if the television is properly plugged in. No picture, no sound Verify if the television is properly supplied with power. Verify that electricity is available. Verify if correct signals are input. Blank screen Press TV/AV button to change signal input to TV input.
  • Page 40: Specifications

    Specifications Specifications of the television that you have just purchased may vary from the information in this table due to technical innovations. Model ELD1547 LV1513 LV1913 ALD1967 Picture, sound NTSC, ATSC, Cliar QAM system Audio output 1.5W+1.5W AV input PC input S-VIDEO input PC audio input...
  • Page 41: Warranty Terms

    Warranty terms...
  • Page 42 V0.2 0090508051C...
