  • Page 1 Model NA-11S1 Owner’s Manual Network Audio Player...

  • Page 2: Important Safety

    The exclamation point within an equilateral triangle is intended approved by Marantz may void your authority, granted by the FCC, to use 10. Protect the power cord from being walked on or pinched particularly at to alert the user to the presence of important operating the product.
  • Page 3 n CAUTIONS ON INSTALLATION NOTES ON USE WARNINGS • Avoid high temperatures. Allow for sufficient heat dispersion when installed in a rack. • Handle the power cord carefully. Hold the plug when unplugging the cord. • Keep the unit free from moisture, water, and dust. • Unplug the power cord when not using the unit for long periods of time.

  • Page 4: Table Of Contents

    Getting started Thank you for purchasing this Marantz product. To ensure proper operation, please read these owner’s manual carefully before using the product. After reading this manual, be sure to keep it for future reference. Contents Getting started ··································································1 Accessories Operation ······································································...

  • Page 5: Main Features

    Audiophile-grade film capacitors and electrolytic off the digital output circuit, the display, and the illumination “Marantz Remote App” compatibility capacitors lamp.

  • Page 6: Cautions On Handling

    Cautions on handling About the remote control • Before turning the power switch on Inserting the batteries NOTE Check once again that all connections are correct and that • Insert the specified batteries in the remote control. there are no problems with the connection cables. q Remove the rear cover w Set two R03/AAA batteries • Replace the batteries with new ones if the set does not...
  • Page 7 Marantz Remote App Point the remote control at the remote sensor when operating Marantz Remote App is a unique application developed for the iPhone, iPod touch and Android smart phone. This application enables you to control Marantz network devices that are connected to your home network.

  • Page 8: Preparation

    Preparation Preparation Here, we explain the connections and basic operation methods for this unit. F Connections vpage 6 F Setup vpage 11...

  • Page 9: Connections

    Connections NOTE Analog connections • Do not plug in the power cord until all connections have been completed. UNBALANCED • When making connections, also refer to the operating n BALANCED Jacks instructions of the other components. The BALANCED jacks on this unit are equipped with XLR • Be sure to connect the left and right channels properly (left Amplifier connectors that are widely used on professional equipment.

  • Page 10: Digital Connections

    Digital connections PC connection When connecting, use a commercially available optical digital cable or coaxial digital cable. By connecting a computer to the USB port on the rear panel of this unit using a commercially available USB cable, this unit Digital audio output Digital audio input can be used as a D/A converter...

  • Page 11: Connecting To A Home Network (Lan)

    Contact an ISP or a computer shop for details. We recommend using a normal type cable. To LAN port Ethernet • Marantz assumes no responsibility whatsoever for any connector communication errors or troubles resulting from customer’s network environment or connected devices.

  • Page 12: Connecting Other Equipment

    Connecting other equipment Remote control jacks connection If this unit is connected to a Marantz amp, the amp can be controlled via this unit using the RS-232C FLASHER IN Marantz Remote App or web control function (vpage  39). Also, remote control signals received by the amp can be used to control this unit.

  • Page 13: Connecting The Power Cord

    Connecting the power cord When all of the connections are completed, insert the power plug into the power outlet. To household power outlet (AC 120 V, 60 Hz) Power cord (supplied) NOTE • Insert the plugs securely. Loose connections will result in the generation of noise.

  • Page 14: Setup

    Setup Menu map Menu operation Setting items Detailed items Description Page Quick Setup Performs the network settings using a Wizard MENU Press style window. [Menu] Quick Setup – Turns on the Menu settings For details on the operations, see the separate Quick Setup mode and the Menu appears on “Getting Started”.

  • Page 15: Setting The First Setup [Quick Setup]

    Setting the first setup General Settings [General] Auto-Standby Firmware [Quick Setup] When this unit is in the stop state and there is no input signal • For details on “Quick Setup” operations, see the separate n Update and operation for 30 minutes, it automatically enters the “Getting Started”.
  • Page 16 General Settings [General] n Update on web screen n Notification When the following screen is displayed, click the Firmware can be updated using the “Web control function” “OK” ( ) button. Update (vpage 39). Updating will begin. “Web control function” (vpage  39) settings must Displays a notification message on this unit’s menu screen be completed in advance on a PC belonging to the same...
  • Page 17 • Information regarding the “Update” function and “Add New “Upgrade Notification” menu Feature” will be announced on the Marantz web site each Upgrade Status Display a list of the additional functions appears. time related plans are defined. provided by the upgrade.

  • Page 18: Setting The Network [Network]

    Setting the network [Network] • For details on “Quick Setup” operations, see the separate n Network connecting “Getting Started”. ENTER to select “Network” – (when “DHCP” settings is “Off”) • If you cancelled “Quick Setup” menu or changed the ENTER “Settings” – “DHCP (On)”, then press network environment, perform “Menu”...
  • Page 19 Setting the network [Network] n Proxy settings to select “Proxy (Address)” or “Proxy Configure these settings to connect to the internet via a ENTER (Name)”, then press proxy server. “Select Type” menu appears. MENU Press to select “Address” or “Name”, then press Turns on the Menu settings mode ENTER and the Menu appears on the...
  • Page 20 “Network” – ENTER “Network Control”, then press “Friendly Name” menu appears. ENTER “Network Control” menu appears. to select the friendly name (Marantz ENTER NA-11S1), then press ENTER to select “On”, then press Edit a friendly name. Network is on during standby. Main unit operable with a network compatible controller.

  • Page 21: Setting The Audio [Audio]

    Setting the audio [Audio] This unit is equipped with a sound quality adjusting function DC Filter Digital Out (Setting for the digital output) which allows users to enjoy the desired playback sound quality. • This setting remains effective even if the power is turned off. This filter is effective in preventing excessive speaker vibration MENU Press...
  • Page 22 Setting the audio [Audio] Phase (analog output phase switching) Switches the output signal phase for balanced outputs. The unit’s balanced output conforms to USA system. This setting must be set to “Inverted” in order to execute balanced outputs to a European system amplifier with a different (inverted) phase.

  • Page 23: Operation

    Operation Operation Here, we explain functions and operations that let you make better use of this unit. F Preparation vpage 21 F Operations possible during playback vpage 21 F Network audio playback vpage 23 F Favorite function vpage 31 F iPod playback vpage 32 F USB memory device playback vpage 34 F AirPlay function vpage 36...

  • Page 24: Operation

    Operation This section provides information on playback operation Operations possible during playback procedures. Preparation Selecting the input source n Selecting the input source using the remote control Turning the power on n Selecting the input source using the main unit Press the input source select button Press (on/standby).
  • Page 25 Operations possible during playback Setting the sleep timer Switching the display’s brightness Switching the filter characteristics Use this function to automatically switch the power to the 2 filter characteristic types can be selected for DSD source, DIMMER Press standby mode after a specific amount of time (minutes). and for PCM source.

  • Page 26: Network Audio Playback

    Network audio playback Follow this procedure to play Internet radio stations or music n Searching stations by keyword files stored on a computer. (Alphabetic strings) • There are many Internet radio stations on the Internet, and n About the Internet Radio function (vpage 48) the quality of the programs they broadcast as well as the bit Press to select “Search by...
  • Page 27 “Allow”. select “Choose media streaming options”. Click “OK” to finish. Select “Allowed” in the drop-down list for “Marantz NA-11S1”. Select “Allowed” in the drop-down list for “Media Sharing media stored on a NAS device programs on this PC and remote connections...”.
  • Page 28 Network audio playback n Music server operation Playing files stored on a PC and NAS • Connections to the required system and specific settings Operation buttons Function Use this procedure to play music files or playlists. must be made in order to play music files (vpage 8). Registration to the Favorite list FAVORITES ADD • Before starting, you must launch the computer’s server...
  • Page 29 Network audio playback Listening to Pandora ® internet radio n Creating a new station Input “Email address” and “Password”. You can create up to 100 radio stations. Pandora is only available in the U.S. • For character input, see page 42. to select “New Station”, Prepare for playback.
  • Page 30 Network audio playback n Giving Feedback and Managing Stations n Sign out n Pandora operation You can personalize your stations by providing feedback. Disassociate this unit from your Pandora account. Operation buttons Function Cursor operation Press while a track is playing. uio p While the Pandora top menu is The Pandora menu screen is displayed.
  • Page 31 Network audio playback n SiriusXM operation Listening to SiriusXM Internet Radio ENTER Select “Sign in”, and then press Operation buttons Function The top menu of SiriusXM is displayed. Over 130 channels of the SiriusXM programming you love, Cursor operation uio p including commercial-free music plus sports, talk, news and ENTER to select the genre, then press...
  • Page 32 Introduce your Marantz to a whole new world of music. With Searches for tracks, artists and albums by Spotify, you can enjoy instant access to millions of songs.
  • Page 33 Network audio playback n Switching the display INFO During playback, Press The display switches between artist name and album title each time the button is pressed. n Spotify operation Operation buttons Function HOME Move Top Menu Cursor operation uio p Enter ENTER Display switches...

  • Page 34: Favorite Function

    Favorite function This section provides information on the Favorite function. Calling stations or files from the favorites Deleting stations or files from the favorite • The Favorite function allows you to register your favorite list list broadcast stations and files in the Favorite List in advance so that you can call and listen to the stations or files right away, FAVORITES CALL FAVORITES CALL...

  • Page 35: Ipod Playback

    • 1st generation iPod nano and iPod video do not have Direct source using the unit buttons, see mode support. “Selecting the input source using the • Marantz will accept no responsibility whatsoever for any loss main unit” (vpage 21). of iPod data. • Depending on the type of iPod and the software version,...
  • Page 36 iPod playback n Switching the display Supported iPod models INFO During playback, press • iPod classic INFO • The display switches each time is pressed (Remote mode only). Artist name Album name • iPod nano n Playing repeatedly (Repeat playback) (vpage 34) (Remote mode only) n Playing random order (Random playback) (vpage 34) • iPod touch...

  • Page 37: Usb Memory Device Playback

    Playing files stored on USB memory • Each time you press REPEAT , the • Marantz does not guarantee that all USB memory devices repeat mode is toggled as shown devices will operate or receive power. When using a portable USB below.
  • Page 38 USB memory device playback n USB operation n Switching the display Operation buttons Function INFO During playback, press Cursor operation INFO • The display switches each time ENTER or p Enter / Playback is pressed. Display the menu or return to the previous menu Character search SEARCH...

  • Page 39: Airplay Function

    This Computer this unit from the list. is displayed on the iPhone, iPod touch or iPad Marantz NA-11S1 screen. AirPlay Device Tap the AirPlay icon Set “Network Control” (vpage ...
  • Page 40 Perform iTunes playback operations with the remote control unit of this unit • Input source will be switched to You can use your Marantz remote control to play and pause “AirPlay” when AirPlay playback is iTunes, as well as skip to next and previous tracks.

  • Page 41: Remote Play Function

    The following devices are used for Remote Play. As on your smart phone to perform operations on DMS and • The default friendly name of this unit is “Marantz specified in the DLNA standard, these devices are called this unit (DMR) with your smart phone The applicable NA-11S1”.

  • Page 42: Web Control Function

    “Bonjour” and directly access the unit’s web control click this or else the screen will not be updated. screen from the overview section. t Click to operate the Marantz amp connected by Remote connector cable (vpage 9). y Click “v” to set the sleep timer function.
  • Page 43 Web control function Operate. GNetwork SettingH NETWORK NETWORK FIRMWARE Friendly Name Marantz NA-11S1 Set Default Top Menu Settings DHCP IP Address 192.168.000.001 Subnet Mask 255.255.255.000 Gateway 000.000.000.000 000.000.000.000 Primary DNS 000.000.000.000 Secondary DNS Proxy Address Or Name Address Name Address 000.000.000.000...

  • Page 44: Using As A D/A Converter

    DIGITAL IN Press to change the input the Marantz website, and installed in the computer. source to “Coaxial” or “Optical”. However, drivers do not need to be installed for Mac OS. NOTE The input digital audio signal is displayed as shown.

  • Page 45: Other Functions

    Other functions Example: For changing characters from “POPS” to “ROCK” Using the number buttons Inputting characters q Place the cursor at “P”. POPS On this unit, the names displayed for “Friendly Name” and Display the screen for inputting CLEAR w Press search, screens can be changed as desired.
  • Page 46 Other functions Using the cursor buttons Auto power on function Press Display the screen for inputting The unit’s power turns on automatically, characters. the previously selected source is played back. Use o p to set the cursor to the character you want to change. Use ui to change the character.

  • Page 47: Information

    Information Information Here, we list various information related to this unit. Please refer to this information as needed. F Part names and functions vpage 45 F Other information vpage 47 F Explanation terms vpage 50 F Troubleshooting vpage 52 F Specifications vpage 56 F Index vpage 57...

  • Page 48: Part Names And Functions

    Part names and functions For buttons not explained here, see the page indicated in parentheses ( ). Front panel Rear panel Q5 Q4 DIMMER button ································· (22) Illumination lamp ······························ (22) ANALOG OUT connectors External/Internal switch USB port ······································· (32, 34) Cursor buttons (uio p) (UNBALANCED/BALANCED) ··············...

  • Page 49: Remote Control

    AMP power button ( Attenuator button (ATT) INPUT buttons ( VOLUME buttons ( • The supplied remote control can operate Marantz amplifiers. • When using it, also refer to the operating instructions of the other devices. NOTE The remote control may not operate some...

  • Page 50: Other Information

    Other information iPod USB memory device Playing back music files recorded on a USB memory device. GCompatible formatsH Sampling Important information Bit rate Bit length Extension frequency • Only USB memory devices conforming to mass storage class and 32/44.1/ 48 – 192 –...

  • Page 51: Network Audio

    The allowable number of files may differ according to the • Your favorite radio stations can be registered by Media Audio) USB memory device capacity and the file size. accessing an exclusive Marantz Internet radio URL from MP3 (MPEG-1 a Web browser on a computer. Audio Layer-3) • The function is managed for individual users, so you must...
  • Page 52 .m4a 24 bit Audio Codec) 96 kHz Introduce your Marantz to a whole new world of music. With Spotify, you can enjoy instant access to millions of songs. z Copyright [2012] [D&M Holdings. Inc.] A Spotify Premium subscription is required.

  • Page 53: Explanation Terms

    Explanation terms AirPlay FLAC iTunes vTuner AirPlay sends (plays) contents recorded FLAC stands for Free lossless Audio Codec, iTunes is the name of the multimedia player This is a free online content server for Internet in iTunes or on an iPhone/iPod touch to a and is a lossless free audio file format.
  • Page 54 Windows Media Player Ver. 11 or later This is a media player distributed free of charge by Microsoft Corporation. It can be used to play playlists created with Windows Media Player Ver. 11 or later as well as files in such formats as WMA, DRM WMA, MP3 and WAV.

  • Page 55: Troubleshooting

    • A USB memory device that • This is not a malfunction. the set’s rear panel and the produced when the set cannot recognize is Marantz does not guarantee connection of the power power switched connected. that all USB memory devices plug to the power outlet.
  • Page 56 Symptom Cause Countermeasure Page Symptom Cause Countermeasure Page Files on a USB • USB memory device is in a • Set the format to FAT16 or Music stored on • DLNA server function is • If – memory device format other than FAT16 or FAT32.
  • Page 57 GPandora ® H Symptom Cause Countermeasure Page Symptom Cause Countermeasure Page For some • Station is congested or not • Wait a while before trying – radio stations, currently broadcasting. again. Cannot login to • Login information is incorrect. • Check if the “Email address” Pandora.
  • Page 58 GRemote controlH GAirPlayH Symptom Cause Countermeasure Page Symptom Cause Countermeasure Page The AirPlay • This unit and the computer • Connect the computer or Set does not • Batteries are worn. • Replace with new batteries. icon is not or iPhone/iPod touch are iPhone/iPod touch to the work properly • You are operating outside of • Operate within the specified...

  • Page 59: Resetting The Microprocessor

    Resetting the microprocessor Specifications Perform this procedure if the display is abnormal or if operations cannot be performed. When the microprocessor is reset, all the settings are reset to their default values and all previously stored custom settings will be have to be manually restored. n Audio performance • Analog output ENTER...
  • Page 60 Index Accessories ·························································· 1 EXTERNAL ··························································· 9 Network ····························································· 15 Sampling frequency ······························· 47, 49, 50 AirPlay ·························································· 36, 50 DHCP ······························································· 15 Secondary DNS ·················································· 15 ALAC ······················································ 47, 48, 50 Friendly Name·················································· 17 Selecting the input source ································· 21 App Store ·················································...
  • Page 61 License CONNECTION WITH THE SOFTWARE OR THE USE OR c. You may otherwise modify Your copy of this Work applicable export laws. You agree to comply with all OTHER DEALINGS IN THE SOFTWARE. (excluding the Articles) in any way to create a Derivative such laws and regulations that may apply to the Work This section describes software license Work, provided that You insert a prominent notice in...
  • Page 62 n Mersenne Twister whatsoever in connection with the Work and shall not ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, • Neither the name of the Xiph.org Foundation nor the be liable to You or any party on any legal theory for any STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE names of its contributors may be used to endorse or http://www.math.sci.hiroshima-u.ac.jp/~m-mat/MT/...
  • Page 63 GPL/LGPL software source distribution. that is used in the product. Marantz provides the source code based on the GPL and Jean-loup Gailly jloup@gzip.org, Mark Adler madler@ LPGL licenses at the actual cost upon your request to our alumni.caltech.edu...
  • Page 64 Dimensions Unit : in. (mm) 17 21/64 (440.0) 2 41/64 (67.0) 2 23/32 2 23/32 11 57/64 (302.0) (69.0) (69.0) Weight : 32 lbs 3 oz (14.6 kg)
  • Page 65 D&M Holdings Inc. 3520 10255 00AM...
