LT2 B847Mark II
Twin Needle Drop Feed Lock Stitcher
Twin Needle Drop Feed Lock Stitcher
with Thread Trimmer
Specifications
Application
Max. speed
Max. .stitch length
Needle bar stroke
Thread take-up stroke
Presser bar lifter
Height of
presser foot
Knee lifter
Height of feed dog
Needle
Hook
Thread trimmer
Thread wiper
Quick reverse
1
For thin materials
4,000 rpm
4 mm
33.4 mm
49.9 mm
7 mm
13 mm (With thread wiper:10 mm)
1 mm
DP 5 #9 #14
Horizontal rotary hook (vertical axis)
400
Scissors type (Solenoid)
Solenoid type
Solenoid type
2000.7
LT2 B847 Mark II 1/4
Advertisement
Table of Contents
Also See for Brother LT2-B847 MKII
Brother LT2-B845 Instruction Manual
47 pages
Brother LT2-B841 Instruction Manual
44 pages
Related Manuals for Brother LT2-B847 MKII
-
Sewing Machine Brother LT2-B842 Parts Manual
Twin needle needle feed lock stitcher with thread trimmer (74 pages)
-
Sewing Machine Brother LT2-B842 MKII Spare Parts
Hm parts list - english (2 pages)
-
Sewing Machine Brother LT2-B878 Parts Manual
Unison feed lock stitcher with large hook (64 pages)
-
Sewing Machine Brother LT2-B835 Parts Manual
Parts manual - english (31 pages)
-
Sewing Machine Brother LT2-B845 Parts Catalog
Twin needle, needle feed angular stitching machine; twin needle, drop feed angular stitching machine; (48 pages)
-
Sewing Machine Brother LT2-B845 MKII Specifications
Twin needle needle feed split needle bar lock stitcher (11 pages)
-
Sewing Machine Brother LT2-B848 MKII Specifications
Hand book - english (5 pages)
-
Sewing Machine Brother LT2-B848 Parts Manual
Parts manual - english (88 pages)
-
Sewing Machine Brother LT2-B872 MKII Specifications
Twin needle needle feed lock stitcher with large hook (and threadtrimmer) (6 pages)
-
Sewing Machine Brother LT2-B875 MKII Specifications
Twin needle needle feed split needle bar lock stitcher with large hook (and thread trimmer) (9 pages)
-
Sewing Machine Brother LT2-B875 Parts Catalog
Parts catalog (42 pages)
-
Sewing Machine Brother LT2-841 MKII Specifications
Twin needle needle feed lock stitcher (9 pages)
Summary of Contents for Brother LT2-B847 MKII
-
Page 1: Specifications
LT2 B847Mark II Twin Needle Drop Feed Lock Stitcher Twin Needle Drop Feed Lock Stitcher with Thread Trimmer Specifications Application For thin materials Max. speed 4,000 rpm Max. .stitch length 4 mm Needle bar stroke 33.4 mm Thread take-up stroke 49.9 mm Presser bar lifter 7 mm... - Page 2 B847 Mark II (For Standard) For normal *In case of using over 1 1 / 2" (38.1 mm) gauge parts, it is necessary to make special machining on the arm-bed. The specification with a maximum stitch width of 77 mm is available. Please consult your Brother representative concerning delivery date and price.
- Page 3 B847 Mark II (For Standard) For shirt fronts *The ¡ symbol is a presser foot assembly with finger guard. Needle gauge Needle clamp assy Needle plate Feed dog Presser foot assy ( 1) ( 1) ( 1) For light materials For light materials For light materials S14355 101 ¡...
- Page 4 B847 Mark II (For Thread trimmer) For normal *The thread trimming fixed knife ( part No. S07527 001) and the installation screw (part No. 148539 101) are not provided with the needle plate, so they must be ordered separately if required. *In case of using over 1 1 / 2"...
