HP ProLiant BL280c - G6 Server Introduction Manual page 18

In the left pane, click Servers and select a server blade. If the "Make all bays same as 1" option is
6.
selected (default), the Power Advisor will populate all blade slots of the enclosure with the selected
blade (in this example, the BL460c G6 blade) as shown in Figure 17.
Figure 17. Populating a c7000 enclosure with BL460c G6 server blades
Highlight the blade in slot 1 and click Config. The configuration screen for the BL460c G6
7.
appears as shown in Figure 18.
Figure 18. Initial BL460c G6 blade configuration screen
Configure the blade for processor type and quantity, memory amount, hard drive(s), and
mezzanine card(s). Also, set the Utilization slider control at the projected level. When finished,
click Save.
18
