Power Connector
AC Power Connector Location
FIGURE 6
Power
Connector
Electrical Requirements
AC Site Requirements
Overcurrent protection devices are required for each cabinet where the disk system is
installed. They must be positioned between the power source and the disk system.
These protective devices must not trip when exposed to an inrush current of 30 amps
lasting 5 ms.
Note
These protection devices must meet all applicable electrical safety
requirements and be approved for the intended purpose.
I
AC Power Requirements
TABLE 3
Electrical Element
Voltage
Frequency
Input Current
Maximum Surge Current
HP StorageWorks Disk System 2100 / 2110
AC
Requirements
100-240 VAC
50-60 Hz
< 1 amp
30 amps peak
11
