Intel Desktop Board D945GCCR Product Guide
Other Connectors and Headers
Figure 24 shows the location of the other connectors and headers on the desktop
board.
Figure 24. Location of the Other Connectors and Headers
50
Item
Description
A
PCI bus connector 2
B
PCI bus connector 1
C
PCI Express x1 connector
D
Chassis intrusion header
E
Diskette drive connector
