Table 45 provides maximum case temperatures for components on the Desktop Board
D865PERL that are sensitive to thermal changes. The operating temperature, current
load, or operating frequency could affect case temperatures. Maximum case
temperatures are important when considering proper airflow to cool the Desktop Board
D865PERL.
Table 45. Thermal Considerations for Components
Component
® ®
Intel Pentium 4 processor
®
Intel 82865PE MCH
®
Intel 82801EB ICH5 or
82801ER ICH5-R
For information about
Intel Pentium 4 processor datasheets and specification
updates
5. Change to Description of Section 1.7.3.3, Serial ATA RAID.
Addition of RAID 1 Support
Section 1.7.3.3 will change in its entirety as follows:
1.7.3.3

Serial ATA RAID

The ICH5-R supports RAID (Redundant Array of Independent Drives) level 0
and level 1 on the Serial ATA ports. RAID 0 provides the ability to support
striping. Two physical drives, of identical size, can be teamed together to create
one logical drive. As data is written or retrieved from the logical drive, both
drives operate in parallel, thus increasing the throughput. RAID 1 provides the
support of disk mirroring. Data is written simultaneously to two physical drives,
of identical size, providing fault tolerance if one of the two drives fails.
NOTE
The ICH5-R provides support for RAID O, RAID 1 and RAID boot in
Windows* XP and Windows 2000 only.
®
Intel Desktop Board D865PERL Specification Update
Maximum Case Temperature
For processor case temperature, see processor
datasheets and processor specification updates
o
99 C (under bias)
o
115 C (under bias)
Refer to
Section 1.2, page 16
