2.4.6

CPU Power Management

The sub-items in this menu allow you to set the CPU ratio and features.
CPU Ratio [Auto]
Allows you to manually adjust the maximum non-turbo CPU ratio. Use <+> and <-> keys or
the numeric keypad to adjust the value. The valid value ranges vary according to your CPU
model.
Enhanced Intel SpeedStep Technology [Enabled]
Allows you to enable or disable the Enhanced Intel
[Disabled]
[Enabled]
Turbo Mode [Enabled]
This item appears only when you set the previous item to [Enabled].
[Enabled]
[Disabled]
The following three items appear only when you set both the Enhanced Intel SpeedStep
Technology and Turbo Mode items to [Enabled].
Long duration power limit [Auto]
Use the <+> and <-> keys to adjust the value.
Long duration maintained [Auto]
Use the <+> and <-> keys to adjust the value.
Short duration power limit [Auto]
Use the <+> and <-> keys to adjust the value.
Primary Plane Current Limit [Auto]
Use the <+> and <-> keys to adjust the value.
Secondary Plane Current Limit [Auto]
Use the <+> and <-> keys to adjust the value.
2.4.7

Offset Mode Sign [+]

[+]
[–]
CPU Voltage [Auto]
Allows you to set the CPU voltage. The values range from -0.635V to +0.635V with a 0.005V
interval.
2-14
Disables this function.
The operating system dynamically adjusts the processor voltage and
core frequency which may result in decreased average consumption and
decreased average heat production.
Allows processor cores to run faster than marked frequency in specific
conditions.
Disables this function.
To offset the voltage by a positive value.
To offset the voltage by a negative value.
SpeedStep Technology (EIST).
®
ASUS P8H67-I Series
