7. LAN (RJ-45) port. This port allows Gigabit connection to a Local Area Network (LAN)
through a network hub. Refer to the table below for the LAN port LED indications.
LAN port LED indications
ACT/LINK LED
Status Description
OFF No link
ORANGE Linked
BLINKING Data activity
8. Line In port (light blue). This port connects the tape, CD, DVD player, or other audio
sources.
9. Line Out port (lime). This port connects to a headphone or a speaker. In 4-channel,
6-channel, and 8-channel configurations, the function of this port becomes Front
Speaker Out.
10. Microphone port (pink). This port connects a microphone.
Refer to the audio configuration table below for the function of the audio ports in the 2, 4, 6,
or 8-channel configuration.
Audio 2, 4, 6, 8-channel configuration
Port
Light Blue (Rear panel)
Lime (Rear panel)
Pink (Rear panel)
Lime (Front panel)
To configure an 8-channel audio output:
Use a chassis with HD audio module in the front panel to support an 8-channel audio
output.
11. USB 3.0 ports 1 and 2. These two 9-pin Universal Serial Bus (USB) ports are for USB
3.0/2.0 devices.
• DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows
operating system.
• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under Windows
OS environment and after the USB 3.0 driver installation.
• USB 3.0 devices can only be used as data storage only.
• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.
1-9
SPEED LED
Status Description
OFF 10 Mbps connection
ORANGE 100 Mbps connection
GREEN 1 Gbps connection
Headset 2-channel
Line In Rear Speaker Out
Line Out Front Speaker Out
Mic In
-
4-channel 6-channel
Rear Speaker Out
Front Speaker Out
Mic In Bass/Center
- -
Speed
Activity Link
LED
LED
LAN port
8-channel
Rear Speaker Out
Front Speaker Out
Bass/Center
Side Speaker Out
®
