Specifi cations - PA231W
Monitor Specifi cations
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort:
DisplayPort Connector:
DVI:
VGA:
15pin Mini D-sub:
Display Colours
Synchronization Range
Viewing Angle
Image Formation Time
Resolutions Supported (Some systems may
not support all modes listed).
Active Display Area
Landscape: Horiz.:
USB Hub
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current fl at panel technologies when displaying non-native resolutions full screen. In fl at panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
*2 1080 x 1920 resolution only.
NOTE:
Technical specifi cations are subject to change without notice.
MultiSync PA231W
Diagonal:
58.4 cm/23.0 inches
58.4 cm/23.0 inches
1920 x 1080
Digital RGB
DVI-D 24pin:
Digital RGB
Analog RGB
Sync
16,777,216
Horizontal:
31.5 kHz to 83.0 kHz, 118.4 kHz*
31.5 kHz to 83.0 kHz, 118.4 kHz*
Vertical:
50 Hz to 85 Hz
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
14 ms (Typ.)
1
640 x 480*
at 60 Hz to 85 Hz
1
720 x 350*
at 70 Hz to 85 Hz
1
720 x 400*
at 70 Hz to 85 Hz
1
800 x 600*
at 56 Hz to 85 Hz
1
832 x 624*
at 75 Hz
1
1024 x 768*
1152 x 864*
1
1152 x 870*
1
1152 x 900*
1
1280 x 960*
1
1280 x 1024*
1400 x 1050*
1440 x 900*
1
1600 x 900*
1
1680 x 1050*
1920 x 1080 at 60 Hz............................................NEC DISPLAY SOLUTIONS cites recommended
1024 x 1280*
1080 x 1920*
480P (720 x 480*
576P (720 x 576*
720P (1280 x 720*
1080P (1920 x 1080*
509.2 mm/20.0 inches
Vert.:
286.4 mm/11.3 inches
Portrait: Horiz.:
286.4 mm/11.3 inches
Vert.:
509.2 mm/20.0 inches
I/F:
USB Specifi cation Revision 2.0
Port:
Upstream 2
Downstream 3
Load Current:
Maximum 0.5A per port
AC 100-240 V ~ 50/60 Hz
0.79 - 0.33 A (with option)
Landscape:
543.6 mm (W) x 338 - 488 mm (H) x 227.6 mm (D)
21.4 inches (W) x 13.3 - 19.2 inches (H) x 9.0 inches (D)
Portrait:
322.4 mm (W) x 559.2 - 598.6 mm (H) x 227.6 mm (D)
12.7 inches (W) x 22.0 - 23.6 inches (H) x 9.0 inches (D)
150 mm / 5.9 inches (Landscape orientation)
39.4 mm / 1.6 inches (Portrait orientation)
10.2 kg (22.5 lbs)
5°C to 35°C/41°F to 95°F
Humidity:
30% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
2
(Analog)
2
(Digital)
at 60 Hz to 85 Hz
at 70 Hz to 85 Hz
at 75 Hz
at 66 Hz
at 60 Hz
1
at 60 Hz to 85 Hz
1
at 60 Hz to 75 Hz
at 60 Hz to 85 Hz
at 60 Hz
1
at 60 Hz
1
at 60 Hz
1
at 60 Hz
1
at 60 Hz)
1
at 50 Hz)
1
at 50 Hz to 60 Hz)
1
at 50 Hz to 60 Hz)
English-26
Notes
Active matrix; thin fi lm transistor (TFT) liquid crystal
display (LCD); 0.265 mm dot pitch; 270 cd/m
luminance; 1000:1 contrast ratio (typical).
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
DVI (HDCP)
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Composite sync.TTL level Positive/Negative
Sync on Green
(Video 0.7 Vp-p and Sync Negative 0.3 Vp-p)
Depends on display card used.
Automatically
Automatically
Automatically
8 ms (Gray to gray Typ)
resolution for optimal display performance.
2
white
