Fig. 5.1: Unbalanced jack cable with ¼" TS jack plugs
If your other equipment has balanced inputs, use a balanced
switched cable with two stereo jack plugs at the balanced
outputs of the FCA202. These cables provide a high level of
security against interference signals such as noise interference
from power cables, and they should be used for all long
cable routes.
