21 F-CONTROL AUDIO FCA202 User Manual
4.3 The FCA202 as a portable laptop recording device
HPS3000
Phones Out
F-CONTROL AUDIO FCA202
XM8500
MiniMIC MIC800
XM8500
MiniMIC MIC800
Fig. 4.3: The FCA202 as a laptop audio interface
B2031A
B2031A
Bal/Unbal
Bal/Unbal
Out 1/L
Out 2/R
Unbal In 1/L
Laptop
Firewire 1
Unbal In 2/R
Audio
Firewire
