Page 1 Projector CP-X2514WN/CP-X3014WN/ CP-X4014WN/CP-WX3014WN User's Manual (detailed) Operating Guide WARNING ►Before using this product, please read all manuals for this product. Be sure to read ﬁrst. After reading them, store them in a safe place for future reference. About this manual Various symbols are used in this manual.
Page 2 Read this Safety Guide first. Projector User's Manual - Safety Guide Thank you for purchasing this projector. WARNING • Before using, read these user's manuals of this projector to ensure correct usage through understanding. After reading, store them in a safe place for future reference.
Page 3: Safety Precautions
Safety Precautions WARNING Never use the projector if a problem should occur. Abnormal operations such as smoke, strange odor, no image, no sound, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. can cause a fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet.
Page 4 Safety Precautions (continued) WARNING Be cautious of High temperatures of the projector. High temperatures are generated when the lamp is lit. It could result in fire or burn. Use special caution in households where children are present. Do not touch about the lens, air fans and ventilation openings during use or immediately after use, to prevent a burn.
Page 5 Safety Precautions (continued) WARNING Be careful in handling the light source lamp. The projector uses a high-pressure mercury glass lamp made of glass. The lamp can break with a loud bang, or burn out. When the bulb bursts, it is possible for shards of glass to fly into the lamp housing, and for gas containing mercury to escape from the projector’s vent holes.
Page 6 Safety Precautions (continued) CAUTION Be careful in moving the projector. Neglect could result in an injury or damage. • Do not move the projector during use. Before moving, disconnect the power cord and all external connections, and close the slide lens door or attach the lens cap.
Page 7 Safety Precautions (continued) CAUTION Remove the power cord for complete separation. • For safety purposes, disconnect the power cord if the projector is not to be used for prolonged periods of time. Disconnect the • Before cleaning, turn off and unplug the projector. Neglect could result in plug from the fire or electrical shock.
Page 8 Safety Precautions (continued) NOTE About consumables. Lamp, LCD panels, polarizors and other optical components, and air filter and cooling fans have a different lifetime in each. These parts may need to be replaced after a long usage time. • This product isn’t designed for continuous use of long time. In the case of continuous use for 6 hours or more, or use for 6 hours or more every day (even if it isn’t continuous), or repetitious use, the lifetime may be shortened, and these parts may need to be replaced even if one year has not passed since the beginning of using.
Page 9 Lamp WARNING HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
Page 10 Regulatory Notices FCC Statement Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 11: Table Of Contents
Contents Introduction ....3 SETUP menu ....42 Features ..... . 3 UTO KEYSTONE EYSTONE UTO ECO MODE...
Page 12: Introduction
Introduction Introduction Features The projector provides you with the broad use by the following features. This projector has a variety of I/O ports that supposedly cover for any business scene. The port can support various image equipment which have digital interface to get clearer pictures on a screen. If you insert a USB storage device, such as a USB memory, into the port and select the port as the input source, you can view images stored in the device.
Page 13: Part Names
Introduction Part names Projector (11) (12) (1) Lamp cover ( The lamp unit is inside. 20, 45) (2) Speaker ( (3) Filter cover ( The air ﬁlter and intake vent are inside. (4) Elevator feet (x2) ( (5) Elevator buttons (x2) ( (6) Remote sensor ( (7) Lens ( (8) Lens cover...
Page 14 Introduction Part names (continued) Control panel button ( button ( button ( 101) indicator ( 101) indicator ( 101) indicator ( 10 ~ 14) Rear panel ( port (11) port port (12) port port (13) port port (14) ports ( , port ( (15) port...
Page 15 Introduction Part names (continued) Remote control (10) button ( COMPUTER MY SOURCE/ VIDEO DOC.CAMERA button ( ASPECT AUTO SEARCH BLANK button ( (16) (12) FREEZE MAGNIFY PAGE VOLUME button ( (14) DOWN (11) button ( MY BUTTON MUTE KEYSTONE (19) (13) button ( (17)
Page 16: Setting Up
Setting up Setting up Install the projector according to the environment and manner the projector will be used in. For the case of installation in a special state such as ceiling mount, the speciﬁ ed mounting accessories ( in the ) and service may be required.
Page 17 Setting up Arrangement (continued) WARNING ► If an abnormality should occur, unplug the projector urgently. Otherwise it could cause a ﬁre or electric shock. ► If the projector falls or topples over, it could result in injury or damage to the projector and the surrounding things.
Page 18 Setting up Arrangement (continued) CAUTION ► The projector may shutdown automatically or may malfunction if its internal temperature is too high. Using a damaged projector could result in a ﬁre and an electric shock. • Do not place the projector in direct sunlight or near hot objects such as heaters. •...
Page 19: Connecting With Your Devices
Setting up Connecting with your devices Before connecting the projector to a device, consult the manual of the device to conﬁrm that the device is suitable for connecting with this projector and prepare the required accessories, such as a cable in accord with the signal of the device. Consult your dealer when the required accessory did not come with the product or the accessory is damaged.
Page 20 Setting up Connecting with your devices (continued) NOTE • Before connecting the projector to a computer, consult the computer’s manual and check the compatibility of the signal level, the synchronization methods and the display resolution output to the projector. - Some signal may need an adapter to input this projector. - Some computers have multiple screen display modes that may include some signals which are not supported by this projector.
Page 21 Setting up Connecting with your devices (continued) (optional) CAUTION ► Before connecting the projector to a network system be sure to obtain the consent of the administrator of the network. ►Do not connect the port to any network that might have the excessive voltage.
Page 22 Setting up Connecting with your devices (continued) • The port of this model is compatible with HDCP (High-band- NOTE width Digital Content Protection) and therefore capable of displaying a video signal from HDCP compatible DVD players or the like. - The supports the following signals.
Page 23 Setting up Connecting with your devices (continued) (with an ampliﬁer) NOTE • If a loud feedback noise is produced from the speaker, move the microphone away from the speaker. Microphone function • You can connect a dynamic microphone to the port with a 3.5 mm mini-plug.
Page 24: Connecting To A Power Supply
Setting up Connecting to a power supply Put the connector of the power cord into the (AC inlet) of the projector. Firmly plug the power cord’s plug into the outlet. In a couple of seconds after the power supply connection, the indicator will light up in steady orange.
Page 25: Fastening The Adapter Cover
Setting up Fastening the adapter cover Use the supplied adapter cover to prevent the USB wireless adapter from coming off easily. Loosen the screw (marked with triangle) on the bottom left of the port. Insert the tab of the cover into the hole at the upper right of the port in the direction of the arrow.
Page 26: Remote Control
Remote control Remote control Installing the batteries Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place. Holding the hook part of the battery cover, remove it.
Page 27: Changing The Frequency Of Remote Control Signal
Remote control Changing the frequency of remote control signal The accessory remote control has the two choices on signal VIDEO COMPUTER MY SOURCE/ DOC.CAMERA frequency Mode 1:NORMAL and Mode 2:HIGH. If the remote control ASPECT AUTO SEARCH BLANK does not function properly, attempt to change the signal frequency. MAGNIFY FREEZE PAGE...
Page 28: Power On/Off
Power on/off Power on/off Turning on the power button indicator Make sure that the power cord is ﬁrmly and correctly connected to the projector and the outlet. Make sure that the indicator is 101). Then remove the steady orange ( lens cover.
Page 29: Operating
Operating Operating / button Adjusting the volume Use the buttons to adjust the volume. VIDEO COMPUTER MY SOURCE/ DOC.CAMERA A dialog will appear on the screen to aid you in adjusting the ASPECT AUTO SEARCH BLANK volume. If you do not do anything, the dialog will automatically MAGNIFY FREEZE PAGE...
Page 30: Selecting An Input Signal
Operating Selecting an input signal button Press button on the projector. Each time you press the button, the projector switches its input port from the current port as below. COMPUTER IN1 COMPUTER IN2 VIDEO USB TYPE A S-VIDEO USB TYPE B COMPONENT (Y, Cb/Pb, Cr/Pr) HDMI 53), the...
Page 31: Searching An Input Signal
Operating Searching an input signal button Press button on the remote control. VIDEO COMPUTER MY SOURCE/ DOC.CAMERA The projector will start to check its input ports as below in ASPECT AUTO SEARCH BLANK order to ﬁnd any input signals. FREEZE MAGNIFY PAGE VOLUME...
Page 32: Adjusting The Projector's Elevator
Operating Adjusting the projector’s elevator When the place to put the projector is slightly uneven to the left or right, use the elevator feet to place the projector horizontally. 14° Using the feet can also tilt the projector in order to project at a suitable angle to the screen, elevating the front side of the projector within 14 degrees.
Page 33: Using The Automatic Adjustment Feature
Operating Using the automatic adjustment feature button Press button on the remote control. Pressing this button performs the following. VIDEO COMPUTER MY SOURCE/ DOC.CAMERA ASPECT AUTO SEARCH BLANK The vertical position, the horizontal position and the horizontal MAGNIFY FREEZE PAGE VOLUME phase will be automatically adjusted.
Page 34: Correcting The Keystone Distortions
Operating button Correcting the keystone distortions Press button on the remote VIDEO COMPUTER MY SOURCE/ DOC.CAMERA control. A dialog will appear on the screen ASPECT AUTO SEARCH BLANK to aid you in correcting the distortion. FREEZE MAGNIFY PAGE VOLUME DOWN Use the ▲/▼...
Page 35: Using The Magnify Feature
Operating Using the magnify feature button Press the button on the remote control. VIDEO COMPUTER MY SOURCE/ The picture will be magniﬁed, and the MAGNIFY dialog DOC.CAMERA ASPECT AUTO SEARCH BLANK will appear on the screen. When the MAGNIFY FREEZE PAGE VOLUME button is pressed for the ﬁrst time after the...
Page 36: Temporarily Freezing The Screen
Operating Temporarily freezing the screen button Press the button on the remote control. VIDEO COMPUTER MY SOURCE/ The “FREEZE” indication will appear on the screen (however, DOC.CAMERA the indication will not appear when the OFF is selected for ASPECT AUTO SEARCH BLANK 49)), and the...
Page 37: Using The Menu Function
Operating Using the menu function This projector has the following menus: PICTURE, IMAGE, INPUT, SETUP, AUDIO, SCREEN, OPTION, NETWORK, SECURITY and EASY MENU. EASY MENU consists of functions often used, and the other menus are classiﬁed into each purpose and brought together as the ADVANCED MENU. Each of these menus is operated using the same methods.
Page 38 Operating Using the menu function (continued) To close the MENU, press the button again or select EXIT and press the ◄ cursor button or button. Even if you do not do anything, the dialog will automatically disappear after about 30 seconds. ●...
Page 39: Easy Menu
EASY MENU EASY MENU From the EASY MENU, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons. Then perform it according to the following table. Using the ◄/► buttons switches the mode for aspect ratio. 35).
Page 40 EASY MENU Using the ◄/► buttons turns off/on the Eco mode. 43). See the ECO MODE item in SETUP menu ( Using the ◄/► buttons switches the mode for mirror status. 43). See the MIRROR item in SETUP menu ( Performing this item resets all of the EASY MENU items except the FILTER TIME and LANGUAGE.
Page 41: Picture Menu
PICTURE menu PICTURE menu From the PICTURE menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item. Then perform it according to the following table.
Page 42 PICTURE menu Using the ▲/▼ buttons switches the color temperature mode. 1 HIGH 1 CUSTOM 2 MID 2 CUSTOM 6 CUSTOM 3 LOW 6 Hi-BRIGHT-3 3 CUSTOM 5 CUSTOM 5 Hi-BRIGHT-2 4 CUSTOM 4 Hi-BRIGHT-1 Selecting a mode whose name includes CUSTOM and then pressing the ►...
Page 43 PICTURE menu Using the ◄/► buttons adjusts the sharpness. Weak Strong • There may be some noise and/or the screen may ﬂicker for a moment when an adjustment is made. This is not a malfunction. Using the ▲/▼ cursor buttons changes the active iris control mode. PRESENTATION THEATER PRESENTATION : The active iris displays the best presentation...
Page 44: Image Menu
IMAGE menu IMAGE menu From the IMAGE menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item. Then perform it according to the following table.
Page 45 IMAGE menu Using the ◄/► buttons adjusts the vertical position. Down • Over-adjusting the vertical position may cause noise to appear on the screen. If this occurs, please reset the vertical position to the default setting. Pressing the button when the V POSITION is selected will reset the V POSITION to the default setting.
Page 46 IMAGE menu Using the ◄/► buttons adjusts the horizontal phase to eliminate ﬂicker. Right Left • This item can be selected only for a computer signal or a component video signal. This function is unavailable for a signal from the port.
Page 47: Input Menu
INPUT menu INPUT menu From the INPUT menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item. Then perform it according to the following table.
Page 48 INPUT menu The video format for port and port can be set. (1) Use the ▲/▼ buttons to select the input port. (2) Using the ◄/► buttons switches the mode for video format. AUTO NTSC SECAM N-PAL M-PAL NTSC4.43 • This item is performed only for a video signal from the port or the port.
Page 49 INPUT menu The computer input signal type for ports can be set. (1) Use the ▲/▼ buttons to select the port to be set. (2) Use the ◄/► buttons to select the computer input signal type. AUTO SYNC ON G OFF •...
Page 50 INPUT menu The resolution for the input signals can be set on this projector. (1) In the INPUT menu select the RESOLUTION using the ▲/▼ buttons and press the ► button. The RESOLUTION menu will be displayed. (2) In the RESOLUTION menu select the resolution you wish to display using the ▲/▼...
Page 51: Setup Menu
SETUP menu SETUP menu From the SETUP menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item. Then perform it according to the following table.
Page 52 SETUP menu Using the ▲/▼ buttons turns on/off the AUTO ECO MODE. • When ON is selected, the projector will always be set to Eco mode below) setting. An OSD at start-up regardless of the ECO MODE ( message “AUTO ECO MODE” will be displayed for tens of seconds when the projector starts with this function activated.
Page 53 SETUP menu Using ▲/▼ buttons switches the standby mode setting between NORMAL and SAVING. NORMAL SAVING When SAVING is selected, the power consumption in the standby mode is lowered with some functional restriction as below: • When SAVING is selected, the RS-232C communication control except to turn the projector on and the network function are disabled while the projector is in the standby mode.
Page 54: Audio Menu
AUDIO menu AUDIO menu From the AUDIO menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or the button to execute the item. Then perform it according to the following table. Using the ◄/►...
Page 55 AUDIO menu Using the ▲/▼ buttons switches the mode for the HDMI audio. Check each of the two modes provided and select the suitable one for your HDMI audio device. Using the ▲/▼ buttons switches the input level to match that of the microphone connected to the port.
Page 56: Screen Menu
SCREEN menu SCREEN menu From the SCREEN menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item. Then perform it according to the following table.
Page 57 SCREEN menu This item allows you to capture an image for use as a MyScreen image which can be used as the BLANK screen and START UP screen. Display the image you want to capture before executing the following procedure. 1.
Page 58 SCREEN menu Using the ▲/▼ buttons turns on/off the MyScreen lock function. When the ON is selected, the item MyScreen is locked. Use this function for protecting the current MyScreen. • This function cannot be selected when the ON is selected to the 75).
Page 59 SCREEN menu Each input port for this projector can have a name applied to it. (1) Use the ▲/▼ buttons on the SCREEN menu to select SOURCE NAME and press the ► or button. The SOURCE NAME menu will be displayed. (2) Use the ▲/▼...
Page 60 SCREEN menu (6) The current name will be displayed on the ﬁrst line. Use the ▲/▼/◄/► buttons and the button to select and enter characters. To erase 1 character at one time, press the button or press the ◄ and button at the same time.
Page 61 SCREEN menu The C.C. is the function that displays a transcript or dialog of the audio portion of a video, ﬁles or other presentation or other relevant sounds. It is required to have NTSC format video or 480i@60 format component video source supporting C.C.
Page 62: Option Menu
OPTION menu OPTION menu From the OPTION menu, items shown in the table below can be performed. Select an item using the ▲/▼ cursor buttons, and press the ► cursor button or button to execute the item, except for the items LAMP TIME and FILTER TIME.
Page 63 OPTION menu Using the ▲/▼ buttons adjusts the time to count down to automatically turn the projector off. Long (max. 99 minutes) Short (min. 0 minute = DISABLE) When the time is set to 0, the projector is not turned off automatically. When the time is set to 1 to 99, and when the passed time with no-signal or an unsuitable signal reaches at the set time, the projector lamp will be turned off.
Page 64 OPTION menu The lamp time is the usage time of the lamp, counted after the last resetting. It is shown in the OPTION menu. Pressing the button on the remote control or the ► button of the projector displays a dialog. To reset the lamp time, select the OK using the ►...
Page 65 OPTION menu This item is to assign one of the following functions to on the remote control ( (1) Use the ▲/▼ buttons on the MY BUTTON menu to select a MY BUTTON - (1/2) and press the ► or button to display the MY BUTTON setup dialog.
Page 66 OPTION menu • ACTIVE IRIS: Changes the active iris mode. 30). • PICTURE MODE: Changes the PICTURE MODE ( 55). • FILTER RESET: Displays the ﬁlter time reset conﬁrmation dialogue ( • TEMPLATE: Makes the template pattern selected to the 51) appear or disappear.
Page 67 OPTION menu Adjust the settings using the ▲/▼ buttons to eliminate ghosting. Use the ▲/▼ button to set the timer for notifying by the message when to replace the ﬁlter unit 100h 200h 500h 1000h 2000h 5000h After choosing an item except OFF, the message “REMINDER *** HRS PASSED ..”...
Page 68 OPTION menu Selecting this item displays COMMUNICATION menu. In this menu, you can conﬁgure the serial communication settings of the projector using the port. • Select an item using the cursor buttons ▲/▼. Then pressing the ► button opens the submenu for the setting item you selected.
Page 69 OPTION menu Select the serial communication condition for the port. 4800bps 9600bps 19200bps 38400bps NONE EVEN • The BAUD RATE is ﬁxed to 19200bps and PARITY is ﬁxed NONE when the 59). COMMUNICATION TYPE is set to OFF ( Select the transmission method for communication by the NETWORK BRIDGE from the port.
Page 70 OPTION menu Select the time period to wait for receiving response data from other device communicating by the NETWORK BRIDGE and the HALF-DUPLEX through the port. OFF: Select this mode if it is not required to check the responses from the device that the projector sends data to.
Page 71 OPTION menu Selecting this item displays a dialog titled “INPUT_INFORMATION”. It shows the information about the current input. • The “FRAME LOCK” message on the dialog means the frame lock function is working. • The “SCART RGB” message means the ports is working as a SCART RGB input port.
Page 72: Network Menu
NETWORK menu NETWORK menu Remember that incorrect network settings on this projector may cause trouble on the network. Be sure to consult with your network administrator before connecting to an existing access point on your network. Select “NETWORK” from the main menu to access the following functions.
Page 73 NETWORK menu Use the ▲/▼ buttons to turn DHCP on/off. Select OFF when the network does not have DHCP enabled. To save the setting, press the ► button. • When the “DHCP” setting changes to “ON”, it takes a little time to obtain IP address from DHCP server.
Page 74 NETWORK menu Use the ▲/▼/◄/► buttons to enter the Year (last two digits), Month, Date, Hour and Minute. • When this item is set, the same item in the WIRED SETUP menu is overwritten with the same 69). setting ( •...
Page 75 NETWORK menu Use the ▲/▼ buttons to select the SSID to display the SSID menu. #1 DEFAULT #2 DEFAULT #3 DEFAULT #5 CUSTOM #4 DEFAULT Select one of the DEFAULT (#1~#4) and press ► button. Press the ► or button when the # 5 CUSTOM is selected.
Page 76 NETWORK menu Selecting this item displays the WIRELESS INFORMATION dialog for viewing the wireless LAN settings. Use the ▲/▼ buttons to switch the page. The ﬁrst page shows the wireless LAN settings. The second and subsequent pages display the signal information of wireless LAN connection devices.
Page 77 NETWORK menu Selecting this item displays the WIRED SETUP menu for the wired LAN. Use the ▲/▼ buttons to select an item, and the ► or button on the remote control to perform the item. Use the ▲/▼ buttons to turn DHCP on/off. Select OFF when the network does not have DHCP enabled.
Page 78 NETWORK menu Use the ▲/▼ buttons to enter the TIME DIFFERENCE. Set the same TIME DIFFERENCE as the one set on your computer. If unsure, consult your IT manager. Use the ► button to return to the menu after setting the TIME DIFFERENCE. •...
Page 79 NETWORK menu (1) Use the ▲/▼ buttons on the NETWORK menu to select the PROJECTOR NAME and press the ► button. The PROJECTOR NAME dialog will be displayed. (2) The current PROJECTOR NAME will be displayed on the ﬁrst 3 lines.
Page 80 Selecting this item displays the MY IMAGE menu. Use the application to transfer the image data. It can be downloaded from the Hitachi web site. Use the ▲/▼ buttons to select an item which is a still image by the MY IMAGE ( in the ) and the ►...
Page 81 It can be installed from the bundled application CD. You can also download the latest version and relevant information from the Hitachi website (http://www.hitachi-america.us/digitalmedia or http://www.hitachidigitalmedia.com). For details of Network Presentation and instructions to install the “LiveViewer”, refer to the manual for “LiveViewer”.
Page 82 SECURITY menu • To change from Single PC mode to Multi PC mode, press ► button to choose OK in the dialog and press button. The display mode is changed. • For details on how to switch the display mode to Multi PC mode on your computer, refer to the manual for “LiveViwer”.
Page 83: Security Menu
SECURITY menu SECURITY menu This projector is equipped with security functions. From the SECURITY menu, items shown in the table below can be performed. To use SECURITY menu: User registration is required before using the security functions. 1. Press the ► button. The ENTER PASSWORD box will be displayed. 2.
Page 84 SECURITY menu The MyScreen PASSWORD function can be used to prohibit access to the MyScreen function and prevent the currently registered MyScreen image from being overwritten. 1-1 Use the ▲/▼ buttons on the SECURITY menu to select MyScreen PASSWORD and press the ► button to display the MyScreen PASSWORD on/ off menu.
Page 85 SECURITY menu PIN LOCK is a function which prevents the projector from being used unless a registered Code is input. 1-1 Use the ▲/▼ buttons on the SECURITY menu to select PIN LOCK and press the ► button or the button to display the PIN LOCK on/off menu.
Page 86 SECURITY menu If this function is set to ON when the vertical angle of the projector or MIRROR setting at which the projector is turned on is different than the previously recorded, the TRANSITION DETECTOR ON alarm will be displayed and the projector will not display the input signal.
Page 87 SECURITY menu The MY TEXT PASSWORD function can prevent the MY TEXT from being overwritten. When the password is set for the MY TEXT; • The MY TEXT DISPLAY menu will be unavailable, which can prohibit changing the DISPLAY setting. •...
Page 88 SECURITY menu (1) Use the ▲/▼ buttons on the SECURITY menu to select the MY TEXT DISPLAY and press the ► or button to display the MY TEXT DISPLAY on/off menu. (2) Use the ▲/▼ buttons on the MY TEXT DISPLAY on/off menu to select on or off.
Page 89: Presentation Tools
Presentation tools Presentation tools The projector has the following two convenient tools that enable on-screen presentations easily and quickly: below) - PC-LESS Presentation ( - USB Display ( PC-LESS Presentation The PC-LESS Presentation reads image and audio data from the storage media inserted into the port and displays the image in the following modes.
Page 90: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) • JPEG (.jpeg, .jpg) * Progressive is not supported. • Bitmap (.bmp) * 16bit mode and compressed bitmap is not supported. • PNG (.png) * Interlace PNG is not supported. • GIF (.gif) • Movie (.avi, .mov) * Supported video format: Motion-JPEG Supported audio format: WAV (Linear PCM, Stereo 16bit), IMA-ADPCM...
Page 91: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) You can control the images on the Thumbnail screen with the remote control, control panel or Web Remote Control. The following functions can be supported while the Thumbnail is displayed. Web Remote The remote Control panel Control control ▲/▼/◄/►...
Page 92: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) You can also control the images by using the menu on the Thumbnail screen. Moves to an upper folder. SORT Allows you to sort ﬁles and folders as following. Press the ► cursor button or to return to the Thumbnail RETURN screen.
Page 93: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) NOTE • These operations are not accessible while the projector OSD is displayed. • The Thumbnail mode is able to display up to 20 ﬁles in one page. • It is not possible to change the input port by using the button when the Thumbnail screen, Slideshow, or Full Screen is displayed.
Page 94: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) Full Screen Mode The Full Screen mode shows a full display image. To display in Full Screen mode, select an image in the Thumbnail screen. Then press the button on the remote control, the button on the control panel or click [ on the Web Remote Control.
Page 95: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) A remote control icon and a progress bar are displayed when one of the cursor buttons, button or button on the remote control, control panel or Web Remote Control is pressed or clicked while a movie is playing in the Full Screen mode.
Page 96: Slideshow Mode, Playlist
Presentation tools PC-LESS Presentation (continued) Slideshow mode The Slideshow mode displays images in full screen and switches the images at 83). intervals set in INTERVAL on the Thumbnail screen menu ( You can start this function from the Slideshow menu. To display the Slideshow menu, select the SLIDESHOW button in the Thumbnail mode and press the button on the remote control, button on the control panel, or click...
Page 97 Presentation tools PC-LESS Presentation (continued) You can play the Slideshow at your desired conﬁguration. Conﬁgure the Slideshow items in the Thumbnail. 1) RETURN : Returns to the thumbnail mode. 2) PLAY : Play the Slideshow. 3) START : Set the beginning number of the Slideshow.
Page 98: Pc-Less Presentation
Presentation tools PC-LESS Presentation (continued) Playlist The Playlist is a DOS format text ﬁle, which decides the order of displayed still image ﬁles in the Thumbnail or Slideshow. The playlist ﬁle name is “playlist.txt” and it can be edited on a computer. It is created in the folder that contains the selected image ﬁles when the PC-LESS Presentation is started or the Slideshow is conﬁgured.
Page 99: Usb Display
Presentation tools USB Display 11). The projector can display images transferred from a computer via an USB cable ( • : One of the following. (32 bit version only) ® Windows XP Home Edition /Professional Edition ® Windows Vista Home Basic /Home Premium /Business /Ultimate /Enterprise ®...
Page 100: Usb Display
Presentation tools USB Display (continued) This application will appear in the Windows notiﬁcation area once it starts. You can quit the application from your computer by selecting “Quit” on the menu. NOTE • The “LiveViewer” (refer to the ) and this application cannot be used at the same time.
Page 101: Usb Display
Presentation tools USB Display (continued) Right-Click menu The menu shown in the right will be displayed when you right-click the application icon in the Windows notiﬁcation area. Display : The Floating menu is displayed, and the icon disappears from the Windows notiﬁcation area.
Page 102: Options Window
Presentation tools USB Display (continued) Options window If you select the Option button on the Floating menu, the Options window is displayed. Optimize Performance The “LiveViewer Lite for USB” captures screenshots in JPEG data and sends them to the projector. The “LiveViewer Lite for USB” has two options that have different compression rate of JPEG data.
Page 103: Maintenance
Maintenance Maintenance Replacing the lamp A lamp has ﬁnite product life. Using the lamp for long periods of time could cause the pictures darker or the color tone poor. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them. Preparation of a new lamp and early replacement are recommended.
Page 104: Lamp Warning
Maintenance Replacing the lamp (continued) Lamp warning WARNING ►The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
Page 105: Cleaning And Replacing The Air Filter
Maintenance Cleaning and replacing the air ﬁlter The air ﬁlter unit of this projector consists of a ﬁlter cover, two kinds of ﬁlters, and a ﬁlter frame. The new double large ﬁlters system is expected to function longer. However, please check and clean it periodically to keep ventilation needed for normal operation of the projector.
Page 106 Maintenance Cleaning and replacing the air ﬁlter (continued) Turn the projector on and reset the ﬁlter time using the FILTER TIME item in the EASY MENU. (1) Press the button to display a menu. (2) Point at the FILTER TIME using the ▼/▲ button, then press the ► button. A dialog will appear.
Page 107: Other Care
Maintenance Other care In order to ensure the safe use of your projector, please have it cleaned and inspected by your dealer about once every year. If the lens is ﬂawed, soiled or fogged, it could cause deterioration of display quality.
Page 108: Troubleshooting
Troubleshooting Troubleshooting If an abnormal operation should occur, stop using the projector immediately. WARNING ►Never use the projector if abnormal operations such as smoke, Troubleshooting strange odor, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. should occur. In such cases, immediately disconnect the power plug from the power outlet.
Page 109 Troubleshooting Related messages (continued) Please turn the power off, and allow the projector to cool down at least 20 minutes. After having conﬁrmed the following items, please turn the power ON again. • Is there blockage of the air passage aperture? •...
Page 110: Regarding The Indicator Lamps
Troubleshooting Regarding the indicator lamps When operation of the indicators differs from usual, check and cope with it according to the following table. Lighting Turned Turned Please refer to the section “Power on/off”. Blinking Turned Turned Green Please wait. Lighting Turned Turned Ordinary operations may be performed.
Page 111 Troubleshooting Regarding the indicator lamps (continued) Please turn the power off, and allow the projector to cool down at least 20 minutes. After the projector has sufﬁciently cooled down, please make conﬁrmation of Blinking the following items, and then turn the power on again. Turned Lighting •...
Page 112: Resetting All Settings
Troubleshooting Resetting all settings When it is hard to correct some wrong settings, the FACTORY RESET function of 62) can reset all settings (except settings such SERVICE item in OPTION menu ( as LANGUAGE, LAMP TIME, FILTER TIME, FILTER MESSAGE, SECURITY and NETWORK) to the factory default.
Page 113 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) 10 ~ 14 Correctly connect the audio cables. Restore the sound pressing button on the remote control. 20, 45, Adjust the volume to a higher level using the menu function or the remote control.
Page 114 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Use the REMOVE USB function ﬁrst, remove the USB No pictures are storage device, and then insert it into the port again. displayed. 12, 83 Before removing the USB storage device, be sure to use (continued) the REMOVE USB function on the thumbnail screen, which appears when the...
Page 115 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Set ECO MODE to NORMAL, and set AUTO ECO Some kind MODE to OFF, in the SETUP menu. of image degradation Adjust OVER SCAN in the IMAGE menu smaller. such as ﬂickering or stripes appear...
Page 116 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) NETWORK BRIDGE Select NETWORK BRIDGE for COMMUNICATION TYPE function does item in the OPTION - SERVICE - COMMUNICATION not work menu. Select NORMAL for STANDBY MODE item in the SETUP menu.
Page 117: Speciﬁcations
Speciﬁcations Speciﬁcations Please see the in the which is a book. End User License Agreement for the Projector Software • Software in the projector consists of the plural number of independent software modules and there exist our copyright or/and third party copyrights for each of such software modules.
Page 118 Projector CP-X2514WN/CP-X3014WN/ CP-X4014WN/CP-WX3014WN User's Manual (detailed) Network Guide Thank you for purchasing this product. This manual is intended to explain only the network function. For proper use of this product, please refer to this manual and the other manuals for this product. WARNING ►Before using this product, be sure to read all manuals for this product.
Page 119 Contents Contents Caution ..................4 1. Connection to the network ............5 1.1 System requirements ................. 5 1.1.1 Required equipment preparation ..................5 1.1.2 Hardware and software requirement for computer ............5 1.2 Quick connection..................6 1.3 Manual network connection setting - Wired LAN -........7 1.3.1 Equipments connection ....................
Page 120 Contents 6. Network Bridge Function ............52 6.1 Connecting devices .................. 52 6.2 Communication setup ................53 6.3 Communication port ................. 53 6.4 Transmission method ................54 6.4.1 HALF-DUPLEX ......................54 6.4.2 FULL-DUPLEX ....................... 55 7. Other Functions ..............56 7.1 E-mail Alerts .....................
Page 121: Caution
Caution Caution To use the wireless network function of this projector, the designated USB wireless adapter that is sold as an option is required. For precautions according to the standards and laws, refer to the documents that come with the adapter. [Restriction on plugging and unplugging the USB wireless adapter] Before you insert or pull out the USB wireless adapter from the projector, turn off the power of the projector and pull out the power cord’s plug from the outlet.
Page 122: Connection To The Network
1. Connection to the network 1. Connection to the network 1.1 System requirements 1.1.1 Required equipment preparation The following equipments are required to connect the projector to your computer through the network. ■ Common The projector: 1 unit, Computer : minimum 1 set ■...
Page 123: Quick Connection
SETUP menu in the Operating Guide) • You can get the latest version of the applications for the network functions of the projector and the latest information for this product from the Hitachi website (http:// www.hitachi-america.us/digitalmedia or http://www.hitachidigitalmedia.com). 1.2 Quick connection The “LiveViewer”...
Page 124: Manual Network Connection Setting - Wired Lan
1. Connection to the network 1.3 Manual network connection setting - Wired LAN - This section explains how to set it up manually. 1.3.1 Equipments connection Connect the projector and computer with a LAN cable. * Before connecting with an existing network, contact the network administrator. Next, check the following computer settings.
Page 125 1. Connection to the network 1.3 Manual network connection setting - Wired LAN - (continued) 5) Right-click "Local Area Connection" to open the menu, and select "Properties". 6) Select "Internet Protocol Version 4 (TCP/IPv4)" and click [Properties]. 7) Select "Use the following IP address" and conﬁgure the IP address, Subnet mask and Default gateway for the computer accordingly.
Page 126 1. Connection to the network 1.3 Manual network connection setting - Wired LAN - (continued) [About IP address] ■ Setting manually The Network address portion of the IP address setting on your computer must be the same as the setting on the projector. Also, the entire IP address on the computer must not overlap with that of the other devices on the same network, including the projector.
Page 127: Internet Option" Setting
1. Connection to the network 1.3 Manual network connection setting - Wired LAN - (continued) 1.3.3 “Internet Option” setting 1) Click “Internet Options” in “Network and Sharing Center” window to open “Internet Properties” window. 2) Click “Connections” tab and then click [LAN settings] button to open “Local Area Network (LAN) Settings”.
Page 128: Manual Network Connection Setting - Wireless Lan
1. Connection to the network 1.4 Manual network connection setting - Wireless LAN - Using the designated USB wireless adapter (option) on the projector enables the projector and computer to communicate in both the Ad-Hoc and Infrastructure modes. This section is intended to explain how to set up wireless LAN connection manually.
Page 129: Wireless Lan Connection Set Up
1. Connection to the network 1.4 Manual network connection setting - Wireless LAN - (continued) 1.4.2 Wireless LAN connection set up ® Using wireless LAN utility for Windows 7 standard. Wireless LAN initial settings for the projector is as follows. Connection Control : Ad-Hoc SSID...
Page 130 1. Connection to the network 1.4 Manual network connection setting - Wireless LAN - (continued) 4) Select "Use the following IP address" and conﬁgure the IP address, Subnet mask and Default gateway for the computer accordingly. After setting is complete, click [OK] to close the window. [About IP address] The Network address portion of the IP address setting on your computer must be the same as the setting on the projector.
Page 131 1. Connection to the network 1.4 Manual network connection setting - Wireless LAN - (continued) 5) Right-click "Wireless Network Connection" to open the menu, and select "Connect / Disconnect". 6) From the connectable wireless networks, select the SSID of the projector (set to "wireless"...
Page 132: Network Presentation
To use Network Presentation, an exclusive application, "LiveViewer", is required. It can be installed from the bundled application CD. You can also download the latest version and relevant information from the Hitachi website (http://www. hitachi-america.us/digitalmedia or http://www.hitachidigitalmedia.com). For details of Network Presentation and instructions to install the "LiveViewer", refer to the manual for "LiveViewer".
Page 133: Web Control
3. Web Control 3. Web Control You can adjust or control the projector via a network from a web browser on a computer that is connected to the same network. ® NOTE • Internet Explorer 6.0 or later is required. ®...
Page 134: Projector Web Control
3. Web Control 3.1 Projector Web Control 3.1.1 Logon To use the Projector Web Control function, you need to logon with your user name and password. Below are the factory default settings for user name and password. Logon window User name Password Administrator <blank>...
Page 135: Network Information
3. Web Control 3.1 Projector Web Control (continued) 3.1.2 Network Information Displays the projector’s current network conﬁguration settings. Item Description Displays information common to both wireless and wired Common Information LAN. Projector Name Displays the projector name settings. Wireless Information Displays the current settings of wireless LAN.
Page 136: Network Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.3 Network Settings Displays and conﬁgures network settings. Item Description Common Setup Conﬁgures the settings common to wireless and wired LAN. Conﬁgures the name of the projector. The length of the Projector Name can be up to 64 alphanumeric characters.
Page 137 3. Web Control 3.1 Projector Web Control - Network Settings (continued) Item Description Wireless Setup Conﬁgures the wireless LAN settings. Mode Select “AD-HOC” or “Infrastructure”. IP Conﬁguration Conﬁgures network settings. DHCP ON Enables DHCP. DHCP OFF Disables DHCP. IP Address Conﬁgures the IP address when DHCP is disabled.
Page 138 3. Web Control 3.1 Projector Web Control - Network Settings (continued) Item Description Wired Setup Conﬁgures the wired LAN settings. IP Conﬁguration Conﬁgures network settings. DHCP ON Enables DHCP. DHCP OFF Disables DHCP. IP Address Conﬁgures the IP address when DHCP is disabled. Subnet Mask Conﬁgures the subnet mask when DHCP is disabled.
Page 139: Port Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.4 Port Settings Displays and conﬁgures communication port settings. Item Description Network Control Port1 Conﬁgures command control port 1 (Port:23). (Port:23) Port open Click the [Enable] check box to use port 23. Click the [Enable] check box when authentication is required Authentication for this port.
Page 140 3. Web Control 3.1 Projector Web Control - Port Settings (continued) Item Description SNMP Port Conﬁgures the SNMP port. Port open Click the [Enable] check box to use SNMP. Conﬁgures the destination of the SNMP Trap in IP format. • The address allows not only IP address but also domain Trap address name if the valid DNS server is setup in the Network Settings.
Page 141: Mail Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.5 Mail Settings Displays and conﬁgures e-mail addressing settings. Item Description Click the [Enable] check box to use the e-mail function. Send Mail Conﬁgure the conditions for sending e-mail under the Alert Settings.
Page 142: Alert Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.6 Alert Settings Displays and conﬁgures failure & alert settings. Item Description Cover Error The lamp cover has not been properly ﬁxed. Fan Error The cooling fan is not operating. The lamp does not light, and there is a possibility that interior Lamp Error portion has become heated.
Page 143 3. Web Control 3.1 Projector Web Control - Alert Settings (continued) The Alert Items are shown below. Item Description Conﬁgures the time to alert. Alarm Time (Only Lamp Time Alarm and Filter Time Alarm.) SNMP Trap Click the [Enable] check box to enable SNMP Trap alerts. Click the [Enable] check box to enable e-mail alerts.
Page 144: Schedule Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.7 Schedule Settings Displays and conﬁgures schedule settings. Item Description Daily Conﬁgures the daily schedule. Sunday Conﬁgures the Sunday schedule. Monday Conﬁgures the Monday schedule. Tuesday Conﬁgures the Tuesday schedule. Wednesday Conﬁgures the Wednesday schedule. Thursday Conﬁgures the Thursday schedule.
Page 145 3. Web Control 3.1 Projector Web Control - Schedule Settings (continued) The schedule settings are shown below. Item Description Schedule Click the [Enable] check box to enable the schedule. Conﬁgures the month and date. Date (Month/Day) This item appears only when Speciﬁc date (No. 1-5) is selected.
Page 146 3. Web Control 3.1 Projector Web Control - Schedule Settings (continued) NOTE • After the projector is moved, check the date and time set for the projector before conﬁguring the schedules. • The internal clock’s time may not remain accurate. Using SNTP is recommended to maintain accurate time.
Page 147: Date/Time Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.8 Date/Time Settings Displays and conﬁgures the date and time settings. Item Description Current Date Conﬁgures the current date in year/month/day format. Current Time Conﬁgures the current time in hour:minute:second format. Click the [ON] check box to enable daylight savings time and Daylight Savings Time set the following items.
Page 148 3. Web Control 3.1 Projector Web Control - Date/Time Settings (continued) Item Description Conﬁgures the time difference. Set the same time difference Time difference as the one set on your computer. If unsure, consult your IT manager. Click the [ON] check box to retrieve Date and Time SNTP information from the SNTP server and set the following items.
Page 149: Security Settings
3. Web Control 3.1 Projector Web Control (continued) 3.1.9 Security Settings Displays and conﬁgures passwords and other security settings. Item Description User Account Conﬁgures the user name and password. Conﬁgures the user name. User name The length of the text can be up to 32 alphanumeric characters.
Page 150: Projector Control
3. Web Control 3.1 Projector Web Control (continued) 3.1.10 Projector Control The items shown in the table below can be performed using the Projector Control menu. Select an item with the mouse. Most of the items have a submenu. Refer to the table below for details.
Page 151 3. Web Control 3.1 Projector Web Control - Projector Control (continued) Item Description PICTURE BRIGHTNESS Adjusts the brightness setting. CONTRAST Adjusts the contrast setting. GAMMA Selects the gamma setting. COLOR TEMP Selects the color temperature setting. COLOR Adjusts the color setting. TINT Adjusts the tint setting.
Page 152 3. Web Control 3.1 Projector Web Control - Projector Control (continued) Item Description SETUP AUTO KEYSTONE Performs the automatic keystone distortion setting. EXECUTE KEYSTONE V Adjusts the vertical keystone distortion setting. AUTO ECO MODE Turns on/off the automatic eco mode function. ECO MODE Selects the eco mode.
Page 153 3. Web Control 3.1 Projector Web Control - Projector Control (continued) Item Description AUDIO VOLUME Adjusts the volume setting. SPEAKER Turns the built-in speaker on/off. AUDIO SOURCE - Assigns the AUDIO SOURCE - COMPUTER IN1 input port. COMPUTER IN1 AUDIO SOURCE - Assigns the AUDIO SOURCE - COMPUTER IN2 input port.
Page 154 3. Web Control 3.1 Projector Web Control - Projector Control (continued) Item Description OPTION AUTO SEARCH Turns the automatic signal search function on/off. Turns the automatic keystone distortion correction function AUTO KEYSTONE on/off. DIRECT POWER ON Turns the direct power on function on/off. Conﬁgures the timer to shut off the projector when no signal AUTO POWER OFF is detected.
Page 155 3. Web Control 3.1 Projector Web Control - Projector Control (continued) The items shown in the table below can be performed using the Projector Control menu. Click the [Quit Presenter Mode]. Item Description SERVICE Quit Presenter Mode Quit compulsorily from the Presenter mode.
Page 156: Remote Control
3. Web Control 3.1 Projector Web Control (continued) 3.1.11 Remote Control You can use your Web browser to control the projector. The functions on the bundled remote control are assigned to Web Remote Control screen. • Do not attempt to control the projector with the projector’s remote control and via your Web browser at the same time.
Page 157: Projector Status
3. Web Control 3.1 Projector Web Control (continued) 3.1.12 Projector Status Displays the settings and status of the projector. Item Description Error Status Displays the current error status Lamp Time Displays the usage time for the current lamp. Filter Time Displays the usage time for the current ﬁlter.
Page 158: Network Restart
3. Web Control 3.1 Projector Web Control (continued) 3.1.13 Network Restart Restarts the projector’s network connection. Item Description Restarts the projector’s network connection in order to Restart activate new conﬁguration settings. NOTE • Restarting requires you to re-log on in order to further control or conﬁgure the projector via a web browser.
Page 159: Crestron E-Control
3. Web Control ® 3.2 Crestron e-Control The Main window as shown above is displayed at ﬁrst. However, if you have enabled User 46), a Password on the Tools window ( dialog prompting you to enter the password as shown on the right will be displayed, and no operation is enabled until you have entered the password.
Page 160: Main Window
3. Web Control ® 3.2 Crestron e-Control (continued) 3.2.1 Main window You can operate the basic controls of the projector on this screen. NOTE • If the projector is in the standby mode, only the Power button can be operated. 1 Click a button and operate as follows.
Page 161 3. Web Control ® 3.2 Crestron e-Control - Main window (continued) 3 Click a button and operate as follows. To show the hidden buttons, click the ◄ / ► icons at the left and right ends. Button Description Freeze Turns Freeze on/off. Contrast Adjusts the contrast setting.
Page 162: Tools Window
3. Web Control ® 3.2 Crestron e-Control (continued) 3.2.2 Tools window ® Conﬁgures the settings between the projector and Crestron control system. Click the [Exit] button to return to the Main window. NOTE • If two-byte characters are used, the input text or numbers cannot be set correctly.
Page 163 3. Web Control ® 3.2 Crestron e-Control - Tools window (continued) 3 Projector (continued) Conﬁgures the network settings of the projector. Item Description DHCP Enables DHCP. IP Address Conﬁgures the IP address when DHCP is disabled. Subnet Mask Conﬁgures the subnet mask when DHCP is disabled. Default Gateway Conﬁgures the default gateway when DHCP is disabled.
Page 164: Info Window
3. Web Control ® 3.2 Crestron e-Control (continued) 3.2.3 Info window Displays the settings and status of the projector. Click the [Exit] button to return to the Main window. 1 Projector Information Item Description Projector Name Displays the projector name settings. Location Displays the the location name of the projector.
Page 165: Help Desk Window
3. Web Control ® 3.2 Crestron e-Control (continued) 3.2.4 Help Desk window ® Sends/receives messages to/from the administrator for Crestron RoomView Express. Button Description Send Sends a message. Check the received message.
Page 166: Emergency Alert
3. Web Control ® 3.2 Crestron e-Control (continued) 3.2.5 Emergency Alert ® When the administrator for Crestron RoomView Express sends out an alert message, it will be displayed on the screen. You can reply to the alert message via a chat format. Input a message in the box below the alert message, and click the [Send] button.
Page 167: My Image Function
MY IMAGE transmission requires an exclusive application for your computer. Use the application to transfer the image data. It can be downloaded from the Hitachi web site (http://www.hitachi-america.us/ digitalmedia or http://www.hitachidigitalmedia.com). For information on the necessary settings and operations for the computer and projector, refer to the manual for the application.
Page 168: Messeger Function
Messenger function requires an exclusive application for your computer. To edit, transfer and display the text data, use the application. You can download it from the Hitachi web site (http://www.hitachi-america.us/digitalmedia or http:// www.hitachidigitalmedia.com). For information on the necessary settings and operations for the computer and projector, refer to the manual for the application.
Page 169: Network Bridge Function
6. Network Bridge Function 6. Network Bridge Function This projector is equipped with the NETWORK BRIDGE function to perform mutual conversion of a network protocol and a serial interface. By making use of the NETWORK BRIDGE function, a computer that is connected to the projector via wireless or wired LAN is able to control an external device via RS-232C communication using the projector as a network terminal.
Page 170: Communication Setup
6. Network Bridge Function 6.2 Communication setup To conﬁgure the setup of the communication using NETWORK BRIDGE for the projector, use items in the COMMUNICATION menu. Open the menu of the projector and select the OPTION - SERVICE - COMMUNICATION menu. OPTION menu >...
Page 171: Transmission Method
6. Network Bridge Function 6.4 Transmission method The transmission method can be selected from the menus, only when the NETWORK BRIDGE is selected for the COMMUNICATION TYPE. OPTION menu > SERVICE > COMMUNICATION in the Operating Guide) HALF-DUPLEX FULL-DUPLEX 6.4.1 HALF-DUPLEX This method lets the projector make two way communication, but only one direction, either transmitting or receiving data, is allowed at a time.
Page 172: Full-Duplex
6. Network Bridge Function 6.4 Transmission method (continued) NOTE • With using the HALF-DUPLEX method, the projector can send out 254 byte data as maximum at once. • If it is not required to monitor the response data from an external device and the RESPONSE LIMIT TIME is set to OFF, the projector can receive the data from the computer and send it out to an external device continuously.
Page 173: Other Functions
7. Other Functions 7. Other Functions 7.1 E-mail Alerts The projector can automatically send an alert message to the speciﬁed e-mail addresses when the projector detects a certain condition that is requiring maintenance or detected an error. NOTE • Up to ﬁve e-mail addresses can be speciﬁed. •...
Page 174 7. Other Functions 7.1 E-mail Alerts (continued) 5) Click the [Alert Settings] on the main menu to conﬁgure the E-mail Alerts settings. 6) Select and conﬁgure each alert item. Refer to item 3.1.6 Alert Setting ( for further information. 7) Click the [Apply] button to save the settings. Failure/Warning e-mails are formatted as follows: Subject line : <Mail title>...
Page 175: Projector Management Using Snmp
7. Other Functions 7.2 Projector Management using SNMP The SNMP (Simple Network Management Protocol) enables to manage the projector information, which is a failure or warning status, from the computer on the network. The SNMP management software will be required on the computer to use this function.
Page 176: Event Scheduling
7. Other Functions 7.3 Event Scheduling The scheduling function enables to setup scheduled events including power on / power off. It enables to be “self-management” projector. NOTE • You can schedule the following control events: Power, Input Source, My Image, Messenger, Slideshow. ( •...
Page 177 7. Other Functions 7.3 Event Scheduling(continued) Schedule Settings ( Schedule settings can be conﬁgured from a web browser. Example: If the IP address of the projector is set to 192.168.1.10: 1) Enter “http://192.168.1.10/” into the address bar of the web browser, and select Projector Web Control from the selection window.
Page 178 7. Other Functions 7.3 Event Scheduling(continued) Date/Time Settings ( The Date/Time setting can be adjusted via a web browser. Example: If the IP address of the projector is set to 192.168.1.10: 1) Enter “http://192.168.1.10/” into the address bar of the web browser, and select Projector Web Control from the selection window.
Page 179: Command Control Via The Network
7. Other Functions 7.4 Command Control via the Network You can conﬁgure and control the projector via the network using RS-232C commands. Communication Port The following two ports are assigned for the command control. TCP #23 (Network Control Port1 (Port: 23)) TCP #9715 (Network Control Port2 (Port: 9715)) NOTE •...
Page 180 7. Other Functions 7.4 Command Control via the Network (continued) When the authentication setting is enabled, the following settings are required. 7) Click the [Security Settings] on the main menu. 8) Click the [Network Control] and enter the desired authentication password. * See NOTE.
Page 181 7. Other Functions 7.4 Command Control via the Network (continued) Command Format Command formats differ among the different communication ports. ● TCP #23 You can use the RS-232C commands without any changes. The reply data format is the same as the RS-232C commands. ( RS-232C Communication in the Operating Guide - Technical) However, the following reply will be sent back in the event of authentication...
Page 182 7. Other Functions 7.4 Command Control via the Network (continued) Reply Data format The connection ID (the data is same as the connection ID data on the sending data format) is attached to the RS-232C commands reply data. <ACK reply> Connection Reply 0x06...
Page 183 7. Other Functions 7.4 Command Control via the Network (continued) Automatic Connection Break The TCP connection will be automatically disconnected after there is no communication for 30 seconds after being established. Authentication The projector does not accept commands without authentication success when authentication is enabled.
Page 184: Crestron Roomview
7. Other Functions ® 7.5 Crestron RoomView ® Crestron RoomView is a multi-user resource management program provided by Crestron Electronics, Inc. It is an application for managing and controlling the projector and other AV devices collectively. ® ® For details of Crestron RoomView , refer to the Crestron website.
Page 185: Troubleshooting
8. Troubleshooting 8. Troubleshooting Reference Problem Likely Cause Things to Check Page Number • Bring the computer and projector closer together. Weak radio signal • Radio waves won’t go – through concrete and metal (steel doors, etc.) If there is a wireless conﬁguration utility loaded Cannot communicate due on your computer, check its...
Page 186: Speciﬁcations
9. Speciﬁcations 9. Speciﬁcations Item Specifications Control software Dedicated computer application and Web browser Corresponding TCP/IP, DHCP client and HTTP server protocol Wireless LAN (IEEE802.11b/g/n) Network (Ad-Hoc and Infrastructure modes) Wired LAN(100Base-TX/10Base-T) WEP (64/128bit), WPA-PSK (TKIP/AES), Security WPA2-PSK (TKIP/AES), SSID ®...
Page 187: Warranty And After-Sales Service
10. Warranty and after-sales service 10. Warranty and after-sales service If a problem occurs with the equipment, please read 8. Troubleshooting ( section ﬁrst and review all suggested check points. After that, please contact your dealer or service company, if you still have the problem. They will tell you what warranty condition is applied.
Page 188 Projector CP-X2514WN/CP-X3014WN/ CP-X4014WN/CP-WX3014WN User's Manual (detailed) Operating Guide – Technical Example of computer signal Resolution (H x V) H. frequency (kHz) V. frequency (Hz) Rating Signal mode 720 x 400 37.9 85.0 VESA TEXT 640 x 480 31.5 59.9 VESA VGA (60Hz) 640 x 480 37.9...
Page 189 Initial set signals Initial set signals The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, adjust the items V POSITION and H POSITION in the IMAGE menu. Back porch (B) Front porch (D) Back porch (b)
Page 190 Connection to the ports Connection to the ports NOTICE ►Use the cables with straight plugs, not L-shaped ones, as the input ports of the projector are recessed. ►Only the signal that is input from the COMPUTER IN1 or IN2 can be output from the MONITOR OUT port.
Page 191 Connection to the ports (continued) COMPONENT Cb/Pb Cr/Pr RCA jack x3 • System: 480i@60, 480p@60, 576i@50, 720p@50/60, 1080i@50/60, 1080p@50/60 Port Signal Component video Y, 1.0±0.1Vp-p with composite sync, 75Ω terminator Cb/Pb Component video Cb/Pb, 0.7±0.1Vp-p, 75Ω terminator Cr/Pr Component video Cr/Pr, 0.7±0.1Vp-p, 75Ω terminator S-VIDEO Mini DIN 4pin jack •...
Page 192 Connection to the ports (continued) HDMI • Type :Digital audio/video connector • Audio signal : Linear PCM (Sampling rate; 32/44.1/48 kHz) Signal Signal Signal T.M.D.S. Data2 + T.M.D.S. Data0 Shield 15 SCL T.M.D.S. Data2 Shield T.M.D.S. Data0 - 16 SDA T.M.D.S.
Page 193 Connection to the ports (continued) USB TYPE A USB TYPE B USB A type jack USB B type jack Signal Signal - Data - Data + Data + Data Ground Ground CONTROL D-sub 9pin plug • About the details of RS-232C communication, please refer to the following page.
Page 194 Connection to the ports (continued) To input SCART RGB signal; SCART connector (jack) SCART cable (plug) RCA plugs To input SCART RGB signal to the projector, use a SCART to RCA cable. Connect the plugs refer to above ex.. For more reference, please consult your dealer.
Page 195 RS-232C Communication RS-232C Communication When the projector connects to the computer by RS-232C communication, the projector can be controlled with RS-232C commands from the computer. For details of RS-232C commands, refer to RS-232C Communication / Network 17). command table ( Connection Turn off the projector and the computer.
Page 196 RS-232C Communication (continued) Communicaion settings 1. Protocol 19200bps,8N1 2. Command format ("h" shows hexadecimal) Byte Number Command Header Data Header Data Setting Action Type code size ﬂag code Packet Action <SET>Change setting to desired value [(cL)(cH)] (aL) (aH) 01h 00h (bL) (bH) (cL) (cH) by [(eL)(eH)].
Page 197 RS-232C Communication (continued) 3. Response code / Error code ("h" shows hexadecimal) (1) ACK reply : 06h When the projector receives the Set, Increment, Decrement or Execute command correctly, the projector changes the setting data for the speciﬁed item by [Type], and it returns the code. (2) NAK reply : 15h When the projector cannot understand the received command, the projector returns the error code.
Page 198 Command Control via the Network Command Control via the Network When the projector connects network, the projector can be controlled with RS- 232C commands from the computer with web browser. For details of RS-232C commands, refer to RS-232C Communication / Network 17).
Page 199 Command Control via the Network (continued) Communicaion Port The following two ports are assigned for the command control. TCP #23 TCP #9715 Conﬁgure the following items form a web browser when command control is used. Port Settings Click the [Enable] check box to open [Network Port open Control Port1 (Port: 23)] to use TCP #23.
Page 200: Command Control Settings
Command Control via the Network (continued) Command control settings [TCP #23] 1. Command format Same as RS-232C communication, refer to RS-232C Communicaton command format. 2. Response code / Error code ("h" shows hexadecimal) Four of the response / error code used for TCP#23 are the same as RS-232C Communication (1)~(4).
Page 201 Command Control via the Network (continued) 2. Response code / Error code ("h" shows hexadecimal) The connection ID is attached for the TCP#23's response / error codes are used. The connection ID is same as the sending command format. (××h : connection ID) (1) ACK reply : 06h + ××h (2) NAK reoly : 15h + ××h (3) Error reply : 1Ch + 0000h + ××h...
Page 202 Network Bridge Communication Network Bridge Communication This projector is equipped with NETWORK BRIDGE function. When the projector connects to the computer by wired or wireles LAN communicaton, an external device that is connected with this projector by RS- 232C communication can be controlled from the computer as a network terminal. For details, see the 6.
Page 203: Communication Settings
Network Bridge Communication (continued) Communication settings For communication setting, use the OPTION - SERVICE - COMMUNICATION menu. ( OPTION menu - SERVICE - COMMUNICATION in the Operating Guide) Item Condition BAUD RATE 4800bps / 9600bps / 19200bps / 38400bps Data length 8 bit (ﬁxed) PARITY NONE/ODD/EVEN...
Page 204 RS-232C Communication / Network command table RS-232C Communication / Network command table Command Data Names Operation Type Header Action Type Setting code Turn off BE EF 06 00 2A D3 01 00 00 60 00 00 Turn on BE EF 06 00 BA D2 01 00...
Page 205 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 89 D2 02 00 03 20 00 00 BRIGHTNESS Increment BE EF 06 00 EF D2 04 00 03 20 00 00 Decrement BE EF...
Page 206 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code User Gamma Execute BE EF 06 00 68 C3 06 00 54 70 00 00 Point 5 Reset BE EF 06 00 C4 FE 02 00 95 30 00 00...
Page 207 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code COLOR TEMP OFFSET R Execute BE EF 06 00 40 C5 06 00 4A 70 00 00 Reset BE EF 06 00 40 F5 02 00 B6 30 00 00...
Page 208 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 91 70 02 00 09 22 00 00 OVER SCAN Increment BE EF 06 00 F7 70 04 00 09 22 00 00 Decrement...
Page 209 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code AUTO BE EF 06 00 A2 70 01 00 11 22 0A 00 NTSC BE EF 06 00 C2 74 01 00 11 22 04 00 BE EF 06 00...
Page 210 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code NORMAL BE EF 06 00 D6 D2 01 00 01 60 00 00 STANDBY SAVING BE EF 06 00 46 D3 01 00 01 60 01 00 MODE...
Page 211 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 75 CD 02 00 62 20 00 00 VOLUME - Increment BE EF 06 00 13 CD 04 00 62 20 00 00 S-VIDEO...
Page 212 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code AUDIO IN1 BE EF 06 00 E6 DC 01 00 36 20 01 00 AUDIO IN2 BE EF 06 00 16 DC 01 00 36 20 02 00 AUDIO...
Page 213 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 02 F1 01 00 A1 20 00 00 MIC LEVEL HIGH BE EF 06 00 92 F0 01 00 A1 20 01 00 BE EF...
Page 214 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code MENU POSITION V Execute BE EF 06 00 A8 C7 06 00 44 70 00 00 Reset MyScreen BE EF 06 00 FB CA 01 00 00 30 20 00...
Page 215 RS-232C Communication / Network command table (continued) RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 EA D1 01 00 0F 20 00 00 AUTO BE EF 06 00 7A D0 01 00 0F 20...
Page 216 RS-232C Communication / Network command table (continued) RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code COMPUTER IN1 BE EF 06 00 C6 32 01 00 01 36 00 00 COMPUTER IN2 BE EF 06 00 06 30...
Page 217 RS-232C Communication / Network command table (continued) Command Data Names Operation Type Header Action Type Setting code BE EF 06 00 3A C3 01 00 00 35 00 00 IMAGE-1 BE EF 06 00 AA C2 01 00 00 35 01 00 IMAGE-2 BE EF...
Page 218 PJLink command PJLink command Commands Control Description Parameter or Response 0 = Standby POWR Power Contorol 1 = Power On 0 = Standby POWR ? Power Status inquiry 1 = Power On 2 = Cool Down 11 = COMPUTER IN 1 12 = COMPUTER IN 2 21 = COMPONENT 22 = S-VIDEO...
Page 219 Input Source List inquiry 11 12 21 22 23 31 41 51 52 Responds with the name set in "PROJECTOR NAME ? Projector Name inquiry NAME" of "NETWORK" Manufucturer's Name INF1 ? HITACHI inquiry CP-X2514WN CP-X3014WN INF2 ? Model Name inquiry CP-X4014WN CP-WX3014WN...
Page 220 Projector CP-X2514WN/CP-X3014WN/ CP-X4014WN/CP-WX3014WN User's Manual (concise) Thank you for purchasing this projector. Please read through this manual before using this product, in order to use safely and utilize well the product. WARNING ►Before using this product, be sure to read all manuals for this product.
Page 221: First Of All
First of all Entries and graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.
Page 222: Regulatory Notices
CP-WX3014WN Responsible Party Hitachi America, Ltd. Address 900 Hitachi way, Chula Vista, CA 91914-3556 U.S.A. Telephone Number +1 -800-225-1741 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.This equipment has...
Page 223: About Waste Electrical And Electronic Equipment
Regulatory notices (continued) About Waste Electrical and Electronic Equipment The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available.
Page 224: Preparing For The Remote Control
Preparing for the remote control Please insert the batteries into the remote control before using it. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.
Page 225: Arrangement
Arrangement Refer to tables at the back of this manual as well as the following to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. Screen size Projection distance (from the projector's end) : Screen height WARNING ►Install the projector where you can access the power outlet...
Page 226: Connecting With Your Devices
Connecting with your devices Before connecting the projector to a device, consult the manual of the device to conﬁrm that the device is suitable for connecting with this projector and prepare the required accessories, such as a cable in accord with the signal of the device. Consult your dealer when the required accessory did not come with the product or the accessory is damaged.
Page 227: Fastening The Adapter Cover
Fastening the adapter cover Use the supplied adapter cover to prevent the USB wireless adapter from coming off easily. Loosen the screw (marked with triangle) on the bottom left of the port. Insert the tab of the cover into the hole at the upper right of the port in the direction of the arrow.
Page 228: Turning On The Power
Turning on the power Make sure that the power cord is ﬁrmly and correctly connected to the projector and the outlet. button Make sure that the indicator is indicator steady orange. Then remove the lens cover. Press the button on the projector or the remote control.
Page 229: Adjusting The Projector's Elevator
Adjusting the projector’s elevator When the place to put the projector is slightly uneven to the left or right, use the elevator feet to place the projector horizontally. Using the feet can also tilt the projector 14° in order to project at a suitable angle to the screen, elevating the front side of the projector within 14 degrees.
Page 230: Displaying The Picture
Displaying the picture Activate your signal source. Turn the VIDEO COMPUTER MY SOURCE/ DOC.CAMERA signal source on, and make it send the ASPECT AUTO SEARCH BLANK MAGNIFY FREEZE PAGE VOLUME button signal to the projector. DOWN button Use the buttons MY BUTTON KEYSTONE MUTE...
Page 231: Turning Off The Power
Turning off the power Press the button on the button projector or the remote control. indicator The message “Power off?” will appear on the screen for about 5 seconds. Press the button again while the message appears. The projector lamp will go off, and the indicator will begin blinking in orange.
Page 232: Replacing The Lamp
Replacing the lamp A lamp has ﬁnite product life. Using the lamp for long periods of time could cause the pictures darker or the color tone poor. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them. Preparation of a new lamp and early replacement are recommended.
Page 233 Replacing the lamp (continued) WARNING ►The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
Page 234: Cleaning And Replacing The Air Filter
Cleaning and replacing the air ﬁlter Please check and clean the air ﬁlter periodically. When the indicators or a message prompts you to clean the air ﬁlter, comply with it as soon as possible. The air ﬁlter has two kinds of ﬁlters inside. Replace the ﬁlters when they are damaged or too soiled. To prepare the new ﬁlters, make contact with your dealer and tell the following type number.
Page 235: Using The Cd Manual
Using the CD manual The other manuals for this product are written into the included CD-ROM titled “User’s Manual (detailed)”. Before using the CD-ROM, please read the following to ensure the proper use. System requirements The system for using the CD-ROM requires the following. ®...
Page 236: Speciﬁcations
Speciﬁcations Product name Liquid crystal projector Liquid Crystal 786,432 pixels (1024 horizontal x 768 vertical) Panel 1,024,000 pixels (1280 horizontal x 800 vertical) Lamp 210 W UHP Speaker 16 W mono (8 W x 2) Power supply/ AC 100-120 V: 3.4 A, AC 220-240 V: 1.8 A Rated current Power AC 100-120 V: 330 W, AC 220-240 V: 310 W...
Page 237: Troubleshooting - Warranty And After-Service
Troubleshooting - Warranty and after-service If an abnormal operation (such as smoke, strange odor or excessive sound) should occur, stop using the projector immediately. Otherwise if a problem occurs with the projector, ﬁrst refer to “Troubleshooting” , and run through the suggested checks.
Page 238 Screen size Projection distance Projector top (from the projector's end) : Screen height Projector bottom CP-X2514WN, CP-X3014WN, CP-X4014WN (1024 x 768) (±10%) 4 : 3 16 : 9 Screen Projection Screen Projection Screen height Screen height size distance size distance a min.
Page 239 Computer Computer External device Access point wireless adapter (optional) storage device...
Page 240 VCR/DVD/Blu-ray Disc player Speakers Monitor (with an ampliﬁer) Microphone...
Page 241 317mm...
Page 242 • The information in this manual is subject to change without notice. • The manufacturer assumes no responsibility for any errors that may appear in this manual. • The reproduction, transfer or copy of all or any part of this document is not permitted without express written consent. •...
