Lexmark T420 Parts Breakdown

Lexmark T420 Parts Breakdown

Parts list
Hide thumbs Also See for T420:

Advertisement

Quick Links

Download this manual See also: Service Manual, Reference Manual
Lexmark T420(n)
4048-00x
Extracted From Service Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the T420 and is the answer not in the manual?

Questions and answers

Related Manuals for Lexmark T420

Summary of Contents for Lexmark T420

  • Page 1 Lexmark T420(n) 4048-00x Extracted From Service Manual...
  • Page 2 1-800-553-9727. In other countries, contact your point of purchase. Lexmark, Lexmark with diamond design, MarkNet, MarkVision, Optra, and Prebate are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. Optra Forms and PictureGrade are trademarks of Lexmark International, Inc.

  • Page 3: How To Use This Parts Catalog

    4048–00x 7. Parts Catalog How to Use This Parts Catalog • SIMILAR ASSEMBLIES: If two assemblies contain a majority of identical parts, they are shown on the same list. Common parts are shown by one index number. Parts peculiar to one or the other of the assemblies are listed separately and identified by description.

  • Page 4: Assembly 1: Covers

    4048–00x Assembly 1: Covers Service Manual...
  • Page 5 4048–00x Assembly 1: Covers Asm- Part Units Description Index Numbers 1–1 56P0608 Cover Assembly, Rear 56P0607 Door Assembly, Rear Exit 56P0680 Flap, Paper Holder 56P0603 Cover Assembly, Duct 56P0604 Cover Assembly, Top 56P0605 Cover Assembly, Right 56P0601 Cover Assembly, Front, with Display (without logo) 56P0602 Cover Assembly, Front with Display...
  • Page 6 4048–00x Assembly 2: Multipurpose Feeder (MPF) Service Manual...

  • Page 7: Multipurpose Feeder (Mpf)

    4048–00x Multipurpose Assembly 2: Feeder (MPF) Asm- Part Units Description Index Numbers 2–1 56P0612 Housing Assembly, Upper (MPF) 56P0611 Housing Assembly, Lower (MPF) 56P0615 Cap, MPF Paper Feed Cover 56P0613 Assembly, Roller (MPF) 56P0614 Gear, MPF Paper Pick Parts Catalog...
  • Page 8 4048–00x Assembly 3: Charging Service Manual...
  • Page 9 4048–00x Assembly 3: Charging Asm- Part Units Description Index Numbers 3–1 56P0640 Roll, Charge 56P0668 Parts Pack, (Screws and E–Rings) 56P0669 Hinge, Pivot (quantity 2) 56P0642 Guide Assembly, Right 56P0643 Assembly, Transfer Roll 56P0644 Bearings, Transfer Roll 56P0641 Guide Assembly, Left Parts Catalog...
  • Page 10 4048–00x Assembly 4: Electronics and Cables Service Manual...
  • Page 11 4048–00x Assembly 4: Electronics and Cables Asm- Part Units Description Index Numbers 4–1 56P0626 Power Supply, 110 V 56P0627 Power Supply, 220 V 2, 7, 8, 9 56P0663 Cable Assembly, Main Harness Locations: 2. HVPS 7. Fan 8. LVPS Power 9.
  • Page 12 4048–00x Assembly 4 (cont.): Electronics and Cables 7-10 Service Manual...
  • Page 13 4048–00x Assembly 4 (cont.): Electronics and Cables Asm- Part Units Description Index Numbers 4–1 56P0624 Cable Assembly, Cover Switch 56P0621 Cable Assembly, Operator Panel 56P0625 Switch, Interlock Cover 4 and 5 Sensor and Cable Included with P/N 56P0611 (lower MPF housing) 6 and 8 56P0616 Solenoid, Paper Feed...
  • Page 14 4048–00x Assembly 4 (cont.): Electronics and Cables This page left intentionally blank. 7-12 Service Manual...
  • Page 15 4048–00x Assembly 4 (cont.): Electronics and Cables Asm- Part Units Description Index Numbers 70G0478 Power Cord, Bolivia, Canada, Caribbean Countries, Columbia, Costa Rica, Dominican Republic, Equador, El Salvador, Guatemala, Honduras, Japan, Mexico, Nicaragua, Peru, Panama, Puerto Rico, Saudi Arabia, Taiwan, The Virgin Islands, Venezuela, US, AP–LV 1339528...
  • Page 16 4048–00x Assembly 5: Paper Feed 7-14 Service Manual...
  • Page 17 4048–00x Assembly 5: Paper Feed Asm- Part Units Description Index Numbers 6–1 56P0677 Flags, Stack Control 56P0651 Assembly, Duplex 56P0645 Sensor, Photo 56P0618 Spring, D–Roll 56P0656 Roll, Paper Feed 56P0655 Bracket, Paper Sensor 56P0657 Assembly, Paper Feed 56P0654 Plate Assembly 56P0634 Gear, Paper Feed 56P0693...
  • Page 18 4048–00x Assembly 6: Frame 7-16 Service Manual...
  • Page 19 4048–00x Assembly 6: Frame Asm- Part Units Description Index Numbers 7–1 56P0606 Duct, Air 56P0623 Assembly, Printhead 56P0629 Assembly, Cartridge Contacts (quantity 5) 56P0662 Feet, Base 56P0661 Damper, Tray 56P0668 Parts Pack, (Screws and E–Rings) 56P0609 Assembly, Tray 1 56P0667 Latch, Door (Qty.
  • Page 20 4048–00x Assembly 7: Fuser 7-18 Service Manual...
  • Page 21 4048–00x Assembly 7: Fuser Asm- Part Units Description Index Numbers 8–1 56P0648 Assembly, Fuser (110 V) 56P0671 Assembly, Fuser (220 V) 56P0673 Fuser Assembly, Paper Guide 56P0676 Spring, Fuser Exit 56P0646 Lamp, Fuser (110 V) 56P0647 Lamp, Fuser (220 V) 7-19 Parts Catalog...
  • Page 22 4048–00x Assembly 8: Sensors 7-20 Service Manual...
  • Page 23 4048–00x Assembly 8: Sensors and Locations Asm- Part Units Description Index Numbers 9 1–5, 8 56P0645 Sensor, Photo Locations: 1. Paper Path Exit Flag 2. Paper Path below Cartridge 3. Paper Path Duplex 4. Paper Path MPF 5. Paper Path below Cartridge 8.
  • Page 24 4048–00x Assembly 9: Options 7-22 Service Manual...
  • Page 25 4048–00x Assembly 9: Options Asm- Part Units Description Index Numbers 10–1 56P0674 Drawer Assembly, 250–Sheet 56P0609 Tray, 250–Sheet 56P0675 Drawer Assembly, 500–Sheet 56P0678 Tray, 500–Sheet 56P0694 DIMM, 4MB SDRAM 56P0695 DIMM, 8MB SDRAM 56P0696 DIMM 16MB SDRAM 56P0697 DIMM, 32MB SDRAM 56P0698 DIMM, 64MB SDRAM 56P0699...
  • Page 26 4048–00x Assembly 9: Options Asm- Part Units Description Index Numbers 1038693 Cable, Serial (50 ft) 7370971 Kit, field relocation 7-24 Service Manual...
