Workstation features

For complete and current information on supported accessories and components for your workstation,
see http://partsurfer.hp.com.

HP Z420 Workstation components

HP Z420 Workstation front panel

Figure 2-1
Table 2-1
1
2
3
4
6 Chapter 2 Workstation features
Front panel components
Component descriptions
Optical drive
Power button
Hard drive activity light
USB 2.0 port (black)
5 USB 3.0 ports (2, blue)
6 Headphone connector
7 Microphone connector
8 IEEE–1394a FireWire connector
