HP t5740e - Thin Client Datasheet page 2

HP t5740e Thin Client
SPECIFICATIONS
Operating system
Client software
Session brokers
Security features
Management and
deployment
Host environments
Processor
System memory
Flash memory
Graphics
Audio
Communications
Ports and connectors
Input devices
Power
Environmental
Dimensions (HxWxD)
Weight
Warranty
CarePack Services
4
Part numbers
Preinstalled with highly extensible Microsoft® Windows® Embedded Standard 2009 with support for
local applications including custom applications;
Windows Embedded Standard 7 license (COA) which gives you the right to install Windows Embed-
ded Standard 7 in the future
Preinstalled
Microsoft RDP 6.1, Citrix ICA 1 1.0 (XenApp Plugin
for Hosted Apps 1 1.0), Microsoft Internet Explorer
7, Windows Media Player 1 1, HP TeemTalk Ter-
minal Emulator 7, HP Remote Graphics Software
Receiver, HP Multimedia and USB Redirection
Enhancement Software
Preinstalled
Citrix Desktop Delivery Controller enabled through
web browser, VMware View Manager 3
Enhanced Write Filter and File-based Write Filter, Symantec Endpoint Protection, Microsoft Firewall
(available as add-on), administrator and user passwords, remote BIOS configurability to disable ports,
secure compartment with 2 USB 2.0 ports, smart card support (card reader sold separately), cable lock
slot (lock sold separately)
HP Easy Config Utility, HP Device Manager agent, HP Client Automation agent, HP ThinState for rapid
deployment, Altiris Deployment Solution
1
Citrix XenApp 5 and 6, Citrix XenDesktop 2.x, 3, and 4; Citrix Presentation Server 4.0, Windows
Server 2008 Terminal Services, Windows 2000/2003 Server families, Windows 2000/2003 Server
Terminal Services, blade PCs, blade workstations, web applications, mainframes (terminal emulation)
Intel Atom N280* 1.66 GHz
*Intel's numbering is not a measurement of higher performance.
2 GB DDR-3 SODIMM installed in single slot leaving one slot empty for upgrade (64 MB minimum
reserved for video)
4 GB primary Flash drive; optional 16 GB second Flash drive
Intel GL40 graphics; maximum resolution: 2048x1536, standard screen, 1920x1200, wide screen
Mic in/headphone out ports, internal speaker, 1/8-inch mini output, full 16-bit stereo, 44 KHz sample
rate
10/100/1000 Gigabit Ethernet (actual speeds may vary), 802.1 1 a/b/g/n Wi-Fi
Base unit: 8 USB 2.0 (2 front/4 rear/2 in secure USB compartment), 1 serial, 2 PS/2, VGA (DB15)
and DisplayPort monitor connectors; optional PCIe X4/PCI Expansion Module: 1 serial, 1 parallel
Standard keyboard and 2-button optical scroll mouse included (USB or PS/2)
65W worldwide auto-sensing 100-240 VAC 50-60Hz surge-tolerant power supply
ENERGY STAR® qualified; meets EuP Lot6 requirement
10.04 x 1.73 x 8.74 in. (255 x 44 x 222 mm) without stand; 10.39 x 1.73 x 8.74 in (266.7 x 44 x
222 mm) with stand; 10.04 x 2.91 x 8.74 in (255 x 74 x 222 mm) with optional Expansion Module
3.48 lb (1.58 kg) with stand; 4.14 lb (1.88 kg) with optional Expansion Module
Limited three-year hardware warranty
9x5 Next-Business-Day Advanced Exchange – 3 Years
9x5 Next-Business-Day On-Site Coverage – 3 Years
XL424AA, XL426AA , XL425AA, XL427AA
5
Available as download
Microsoft RDP 7.0, HP Universal Print Driver
See www.hp.com for download.
Available as download
HP Session Allocation Manager (SAM) 3.0;
Available from vendors website: VMware View
Manager 4.0, Leostream Desktop Connection
Broker, Provision Networks (Quest) broker
(sold separately)
2
5
(certain models)
3
