Illustrated Parts & Service Map
HP Pro 4500 MT Business PC
©
2010 Hewlett-Packard Development Company, L.P. The information con-
tained herein is subject to change without notice. HP shall not be liable for
technical or editorial errors or omissions contained herein.
Document Number 640039-001.

Key Specifications

Processor Type
Intel Core2 Quad, Core2 Duo, Pentium Dual-Core, Celeron
Dual-Core, Celeron
RAM Type
DDR3-SDRAM DIMMs, PC3-10600 (1333 MHz)
Maximum RAM Supported
8 GB (4 slots)
Expansion Slots
Graphics Adapter
Intel Graphics Media Accelerator X4500 (DX10)
Chipset
Intel Q45 Express
Drive Support
I/O Interfaces
Rear: (1) VGA, (1) DVI_D, (1) Serial (2nd serial optional), (1)
RJ-45 Ethernet, (2) PS/2, (6) USB 2.0, (3) audio; speaker, line-
in, microphone
Front: (2) USB 2.0, (1) Headphone, (1) Microphone
Operating Systems

Spare Parts

System Unit

1
Front bezel with reset button
2
Chassis
3
Access panel
4
Power supply, 300W, 85% efficiency
*
Power supply, 300W, PFC
*
Power supply, 250W, PFC
*
5.25-inch bezel blank
*
3.5-inch bezel blank
* Not shown
HP Pro 4500, MT
1st Edition November 2010.
(1) PCI Express x16
(1) PCI Express x1
(2) PCI 2.3
(2) 5.25-inch external optical drive bays
(2) 3.5-inch internal hard disk drive bays
(1) 3.5-inch media card reader
Windows 7 Home Premium & Basic
Windows 7 Professional
RedFlag Linux
FreeDOS

Cables

1
Power switch/LED cable assembly
2
Front I/O assembly
*
SATA HDD cable, 6.5 inch (165 mm) with latch
*
SATA ODD cable, 9.5-inch (240 mm)
*
DMS-59 to dual DVI adapter
*Not shown

Keyboards (not illustrated)

HP PS/2
HP USB
International English

Mass Storage Devices (not illustrated)

6X BD±RW SuperMulti drive with LightScribe
16X DVD±RW SuperMulti drive with LightScribe
16X DVD-ROM drive
1 TB hard drive
500 GB hard drive
320 GB hard drive
250 GB hard drive

Miscellaneous Parts

1
Fan sink
2
Chassis fan
*
Speaker, internal
*
Mouse, PS2, optical, black
*
Mouse, USB, laser, black
*
Mouse, USB, optical, black
*
Printer port
*
Hood sensor
*
Media card reader, 22-in-1
*
Serial/parallel port PCI adapter
*
Serial port, full height
*
Speakers, USB
*
Rear I/O cover
*Not shown
614495-001
Not spared
586372-001
575437-001
508467-001
508466-001
536306-001
583094-001
640039-001
537745-xxx
537746-xxx
-L31
Simplified Chinese
614496-001
508463-001
448670-001
614498-001
463024-001
-AA1
536540-001
581600-001
581599-001
621418-001
621421-001
621420-001
621419-001
619566-001
438741-001
463316-001
537748-001
570580-001
537749-001
497727-001
534484-001
480032-001
321722-001
530599-001
571536-001
592507-001
