User's Manual
U300 Series
computers.toshiba-europe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSU31C-RW10AC and is the answer not in the manual?

Questions and answers

Summary of Contents for Toshiba PSU31C-RW10AC

  • Page 1 User’s Manual U300 Series computers.toshiba-europe.com...
  • Page 2 U300 Series Copyright © 2007 by TOSHIBA Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of TOSHIBA. No patent liability is assumed, with respect to the use of the information contained herein.
  • Page 3 U300 Series EU Declaration of Conformity TOSHIBA declares that this product conforms to the following Standards: Supplementary "The product complies with the requirements of Information: the Low Voltage Directive 73/23/EEC, the EMC Directive 89/336/EEC and/or the R&TTE Directive 1999/5/EC." This product is carrying the CE-Mark in accordance with the related European Directives.
  • Page 4: Optical Disc Drive Safety Instructions

    U300 Series Network Compatibility Statement This product is designed to work with, and is compatible with the following networks. It has been tested to and found to conform with the additional requirements conditional in EG 201 121. Germany ATAAB AN005, AN006, AN007, AN009, AN010 and DE03, 04, 05, 08, 09,12,14,17 Greece ATAAB AN005, AN006 and GR01, 02, 03, 04...
  • Page 5 U300 Series Panasonic DVD Super Multi UJ-852M/852B ■ The DVD Super Multi drive employs a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.
  • Page 6 U300 Series HLDS DVD Super Multi GSA-U10N ■ The DVD Super Multi drive employs a laser system. To ensure proper use of this product, please read this instruction manual carefully and retain for future reference. Should the unit ever require maintenance, contact an authorized service location.
  • Page 7 U300 Series International Precautions CAUTION: This appliance contains a laser system and is classified as a "CLASS 1 LASER PRODUCT." To use this model properly, read the instruction manual carefully and keep this manual for your future reference. In case of any trouble with this model, please contact your nearest "AUTHORIZED service station."...
  • Page 8: General Precautions

    U300 Series General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.
  • Page 9: Instruction Manual For Safety And Comfort

    U300 Series Heat injury ■ Avoid prolonged physical contact with the computer. If the computer is used for long periods, its surface can become very warm. While the temperature will not feel hot to the touch, if you maintain physical contact with the computer for a long time, for example if you rest the computer on your lap or if you keep your hands on the palm rest, your skin might suffer a low-heat injury.
  • Page 10: Table Of Contents

    U300 Series Table of Contents Introduction Chapter 1 Equipment checklist........1-1 Features.
  • Page 11 TOSHIBA Disc Creator ........4-12...
  • Page 12 TOSHIBA support ........
  • Page 13: Manual Contents

    This manual tells how to set up and begin using your TOSHIBA U300 Series computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
  • Page 14 U300 Series Chapter 5, Keyboard, describes special keyboard functions including the keypad overlay and hot keys. Chapter 6, Power and Power-Up Modes, gives details on the computer's power resources and battery save modes. Chapter 7, HW Setup explains how to configure the computer using the HW Setup program.
  • Page 15 U300 Series Display Names of windows or icons or text generated by the computer that appears on its display screen is presented in the type face you see to the left. Messages Messages are used in this manual to bring important information to your attention.
  • Page 16: Introduction

    Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA. Equipment checklist Carefully unpack your computer. Save the box and packing materials for future use.
  • Page 17: Features

    Introduction ■ TOSHIBA CD/DVD Acoustic Silencer ■ TOSHIBA SD Utilities ■ TOSHIBA Disc Creator ■ Display Driver ■ TouchPad Driver ■ Sound Driver ■ Miscellaneous drivers (depending on the model you purchased: Modem, Wireless LAN) Documentation ■ U300 Series Personal Computer User´s Manual ■...
  • Page 18 Introduction Memory Main Memory Part of the main system memory may be used by Disclaimer the graphics system for graphics performance and therefore reduce the amount of main system memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications utilized, system memory size and other factors.
  • Page 19 Introduction Disks Hard disk Disclaimer 1 Gigabyte (GB) means 10 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 2 = 1,073,741,824 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating...
  • Page 20 Introduction DVD Super Multi drive Some models are equipped with a full-size (Supporting DVD±R DVD Super Multi drive module that lets you Double Layer) record data to rewritable CD/DVDs as well as run either 12 cm (4.72") or 8 cm (3.15") CD/DVDs without using an adaptor.
  • Page 21: Pointing Device

    Introduction Pointing Device Built-In TouchPad A TouchPad and control buttons in the palm rest enable control of the on-screen pointer and scrolling of windows. Ports External Monitor Depending on the model you purchased: 15-pin, analog VGA port supports VESA DDC2B compatible functions.
  • Page 22: Special Features

    Password Power-on password protection. Two level password architecture. Special features The following features are either unique to TOSHIBA computers or are advanced features, which make the computer more convenient to use. Hot Keys Key combinations let you quickly modify the system configuration directly from the keyboard without running a system configuration program.
  • Page 23 Refer to the Using the Hard Disk Drive (HDD) Protection section in Chapter 4, Operating Basics, for more details. The TOSHIBA HDD Protection function does not guarantee that the hard disk drive will not be damaged. User’s Manual...
  • Page 24: Utilities

    Diagnostic Tool information on the computer's configuration and allows some of the built-in devices functionality to be tested. To start the TOSHIBA PC Diagnostic Tool, click Start, point to All Programs, point to TOSHIBA, and point to Utilities and click PC Diagnostic Tool.
  • Page 25 On the Password tab you can register a user password. TOSHIBA DVD Player The DVD Video Player is used to play DVD Video. It has an on-screen interface and functions. Click Start, point to All Programs, point to InterVideo WinDVD, then click InterVideo WinDVD.
  • Page 26: Options

    * The availability of DDRII depends on the model you purchased. Battery pack An additional battery pack can be purchased from your TOSHIBA dealer. Use it as a spare to increase your computer operating time. AC Adaptor If you use your computer at more than one site...
  • Page 27: Chapter 2 The Grand Tour

    The Grand Tour Chapter 2 The Grand Tour This chapter identifies the various components of your computer. Become familiar with each component before you operate the computer. Front with the display closed The following figure shows the computer's front with its display panel in the closed position.
  • Page 28: Left Side

    The Grand Tour Wireless Activity LED Indicates whether the wireless LAN or Bluetooth is active or not. (Depends on the model you purchased.) DC IN LED The DC IN LED indicates the computer is connected to the AC adaptor and it is plugged into an AC power source.
  • Page 29: Right Side

    The Grand Tour External Monitor Port This 15-pin port lets you connect an external video display. The Analog VGA port supports VESA DDC2B compatible functions. (Depends on the model you purchased.) Cooling Vents Cooling vents help prevent the CPU from overheating.
  • Page 30 The Grand Tour Express Card Slot for This slot allows you to insert an Express Card. Cardbus Card Slot An Express Card is a small, modular add-in card technology based on PCI Express and the Universal Serial Bus (USB) interface. The max. transmission rate is 2.5Gbps.
  • Page 31: Backside

    The Grand Tour Backside The following figure shows the computer's back panel. DC in 19V Jack The backside of the computer DC IN 19V Jack The AC adaptor connects to this socket. Use only the model of AC adaptor that comes with the computer.
  • Page 32: Front With The Display Open

    The Grand Tour Battery Pack The battery pack powers the computer when the AC adaptor is not connected. For detailed information on the battery pack, refer to Chapter 6, Power and Power-Up Modes. Battery Release Latch Slide and hold this latch to release the battery pack for removal.
  • Page 33 The application that is launched differs by model: Windows Media Player/TOSHIBA DVD Player. (Depends on the model purchased.) TOSHIBA Assist Press this button to launch TOSHIBA Assist Button application. If the computer’s power is off, you can press this button to turn on the computer’s power and launch the TOSHIBA Assist application automatically in one step.
  • Page 34: Fixed Optical Media Drives

    The Grand Tour Stop Button Stops playing of the CD, DVD or digital audio. (Depends on the model purchased.) Previous Button Skips backwards to the previous track, chapter or digital file. Refer to Chapter 4, Operating Basics, for details. (Depends on the model purchased.) Next Button Skips forward to the next track, chapter or digital file.
  • Page 35: Writable Discs

    The Grand Tour Writable discs This section describes the types of writable CD discs. Check the specifications of your drive for the type of discs it can write. Use TOSHIBA Disc Creator to write compact discs. Refer to Chapter 4, Operating Basics.
  • Page 36: Ac Adaptor

    Use only the AC adaptor that came with the computer or an equivalent optional adaptor. Use of the wrong adaptor could damage your computer. TOSHIBA assumes no liability for any damage in such case. ■ Use only the AC Adaptor supplied with your computer or an equivalent adaptor that is compatible.
  • Page 37: Chapter 3 Getting Started

    Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not touch the latch while holding the computer. Or you may get injured by the dropped battery by unintentional release of the latch.
  • Page 38: Connecting The Ac Adaptor

    Getting Started 4. Secure the Battery Pack Lock to ensure the battery is locked into place. Later, when you want to remove the battery you must disengage this lock first. Battery Release Latch Battery Pack Lock Securing the battery pack Refer to Removing the battery pack section in Chapter 5,...
  • Page 39 Use only the AC adaptor supplied with your computer or an equivalent adaptor that is compatible. Use of any incompatible adaptor could damage your computer. TOSHIBA assumes no liability for any damage caused by use of an incompatible adaptor. ■...
  • Page 40: Opening The Display

    Getting Started Opening the display The display panel can be rotated in a wide range of angles for optimal viewing. 1. Lift the panel up and adjust it to the best viewing angle for you. Use reasonable care when opening and closing the display panel. Opening it vigorously or slamming it shut could damage the computer.
  • Page 41: Start Up For The First Time

    Getting Started Start up for the first time When you first turn on the power, the computer's initial screen is the ® Windows XP Startup Screen Logo. Follow the on-screen directions. During setup, you can click the Back button to return to the previous screen.
  • Page 42: Starting Hibernation

    Getting Started ■ Saves data to the hard disk when the computer automatically shuts down because of a low battery. For the computer to shut down in hibernation mode, the hibernation feature must be enabled in Power Options: Hibernate tab. Otherwise, the computer will shut down in Standby mode.
  • Page 43: Standby Mode

    Getting Started Standby mode In standby mode the power remains on, but the CPU and all other devices are in Standby mode. ■ If the computer is not used or accessed in any way, including receipt of e-mail, for approximately 15 or 30 minutes when the AC adapter is connected, the computer will automatically enter Standby mode (Power Options default).
  • Page 44: Restarting The Computer

    Getting Started 3. Press the power button. This feature must be enabled. Refer to the Advanced tab in Power Options described in the Control Panel. When you turn the power back on, you can continue where you left when you shut down the computer. ■...
  • Page 45 2. While holding down F12 key on the keyboard, turn on your computer - when the In Touch with Tomorrow TOSHIBA logo screen appears, release the F12 key. 3. Use the left and right cursors key to select the CD-ROM icon from the menu.
  • Page 46: Chapter 4 Operating Basics

    Operating Basics Chapter 4 Operating Basics This chapter gives information on basic operations including using the TouchPad, optical media drives, sound system, modem, the wireless LAN and LAN. It also provides tips on caring for your computer. Using the TouchPad To use the TouchPad, simply touch and move your finger tip across it in the direction you want the on-screen pointer to go.
  • Page 47: Using The Web Camera (Depends On The Model Purchased)

    Operating Basics Do not press on the TouchPad too hard or press a sharp object such as a ball point pen against the TouchPad. The TouchPad could be damaged. For some functions, you can tap the TouchPad instead of pressing a control button.
  • Page 48 Operating Basics Capture Still Video Audio Images Recording Recording Function Display Window Camera resolution Effects Mute Capture Still Images Click to see a preview of the captured image; you can also e-mail the image. Video Recording Click to prepare for recording. Click again to start recording.
  • Page 49: Using The Microphone

    Operating Basics Using the microphone Your computer has a built-in microphone that can be used to record monaural sounds into your applications. It can also be used to issue voice commands to applications that support such functions. (Built-in microphone is provided with some models) Since your computer has a built-in microphone and speaker, "feedback"...
  • Page 50: Loading Discs

    Operating Basics Loading discs To load a disc, follow the steps below and refer to the figures. 1. a. When the power is on, press the eject button to open the drawer slightly. Eject Button Pressing the eject button b. Pressing the eject button will not open the drawer when the disc drive's power is off.
  • Page 51 Operating Basics 2. Grasp the drawer gently and pull until it is fully opened. Pulling the drawer open 3. Place the disc, label side up, in the drawer. Inserting a disc User’s Manual...
  • Page 52 Operating Basics When the drawer is fully opened, the edge of the computer will extend slightly over the disc tray. Therefore, you will need to turn the disc at an angle when you place it in the tray. After seating the disc, however, make sure it lies flat, as shown in the figure above.
  • Page 53: Removing Discs

    Operating Basics Removing discs To remove the disc, follow the steps below and refer to the figure. Do not press the eject button while the computer is accessing the disc drive. Wait for the optical media drive indicator to go out before you open the drawer.
  • Page 54: Writing Cd/Dvds With The Dvd Super Multi Drive Supporting Dvd±R Double Layer

    Based on TOSHIBA's limited compatibility testing, we suggest the following manufacturers of CD-R/RW and DVD-R/+R/-RW/+RW/-RAM discs. However, in no event does TOSHIBA guarantee the operation, quality or performance of any disc. Disc quality can affect write or rewrite success rates.
  • Page 55 Operating Basics DVD-RW: DVD Specifications for Recordable Disc for Version 1.1 or 1.2 Victor Company of Japan, Ltd. (JVC) MITSUBISHI KAGAKU MEDIA CO, LTD. DVD+RW: MITSUBISHI KAGAKU MEDIA CO, LTD. DVD-RAM: DVD Specifications for DVD-RAM Disc for Version2.0, 2.1 or 2.2 Hitachi Maxell Ltd.
  • Page 56: When Writing Or Rewriting

    LAN server or any other network device. ■ Writing with software other than TOSHIBA Disc Creator is not recommended. When writing or rewriting Please observe/consider the following when you write or rewrite to a CD-R/ -RW, DVD-R/-RW/-RAM or DVD+R/+RW disc.
  • Page 57: Toshiba Disc Creator

    TOSHIBA Disc Creator cannot record in packet format. ■ You might not be able to use the Disc Backup function of TOSHIBA Disc Creator to backup a DVD-R/-RW or DVD+R/+RW disc that wasmade with other software on a different DVD-R/-RW or DVD+R/ +RW recorder.
  • Page 58: Media Care

    Service Pack 2 or later to read it. Some optical media drives cannot read added data regardless of the operating system. ■ TOSHIBA Disc Creator does not support recording to DVD-RAM discs. To record to a DVD-RAM, use Explorer or other similar utility. ■...
  • Page 59: Modem

    To select a region, follow the steps below. 1. Click Start, point to All Programs, TOSHIBA, Networking, and click Modem Region Select. Do not use the Country/Region Select function in the Modem setup utility in the Control Panel if the function is available.
  • Page 60: Properties Menu

    Operating Basics Properties menu Click the icon with the secondary mouse button to display properties menu on the screen. Settings You can enable or disable the following settings: AutoRun Mode The Region Select utility starts automatically when you start up the operating system.
  • Page 61 Operating Basics Connecting To connect the modem cable, follow the steps below. ■ The modular cable that comes with the computer must be used to connect a modem. Connect the end of the modular cable with the core to the computer. ■...
  • Page 62: Wireless Communications

    TOSHIBA strongly recommend the customer to enable the encryption function. ■ TOSHIBA is not liable for the eavesdropping of data due to the use of Wireless LAN and the damage thereof. User’s Manual 4-17...
  • Page 63: Product Support

    ® ® This Bluetooth Stack is based on Bluetooth Version 1.1/1.2/2.0+EDR specification. TOSHIBA cannot confirm compatibility between any PC ® products and/or other electronic devices that use Bluetooth other than TOSHIBA notebook computers. ® Release Notes related to the Bluetooth Stack for ®...
  • Page 64: Lan

    Operating Basics Indicator status Indication Indicator off Wireless communication switch is set to off. Automatic power down because of overheating. Power malfunction. Indicator glows Wireless communication switch is on. Wireless LAN is turned on by an application. If you used the Task Bar to disable Wireless LAN, you will need to restart the computer to re-enable it.
  • Page 65: Cleaning The Computer

    Operating Basics Connecting LAN cable To connect the LAN cable, follow the steps below. 1. Turn off the power to the computer and to all external devices connected to the computer. 2. Plug one end of the cable into the LAN jack. Press gently until you hear the latch click into place.
  • Page 66: Moving The Computer

    ■ Before moving the computer, it recommends changing the function of TOSHIBA HDD Protection. Refer to the section, Using the Hard Disk Drive (HDD) Protection, in this chapter. ■...
  • Page 67: Using The Hard Disk Drive (Hdd) Protection

    TOSHIBA HDD Protection is disabled. TOSHIBA HDD Protection Properties You can change the TOSHIBA HDD Protection settings by using the TOSHIBA HDD Protection Properties window. To open the window, click Start All Programs...
  • Page 68 Intensely shaking the computer or other subjecting it to strong impacts may cause damage to the computer. Details To open the Details window, click the Setup Detail button in the TOSHIBA HDD Protection Properties window. Detection Level Amplification When the AC adaptor is disconnected or the lid is closed, HDD Detection assumes that the computer will be carried and sets the detection level to the maximum for 10 seconds.
  • Page 69: Chapter 5 The Keyboard

    The Keyboard Chapter 5 The Keyboard The computer's keyboard layouts are compatible with a 101/102-key enhanced keyboard. By pressing some keys in combination, all the 101/ 102-key keyboard functions can be executed on the computer. The number of keys on your keyboard depends on which country/region’s keyboard layout your computer is configured with.
  • Page 70: F1 ... F12 Function Keys

    The Keyboard F1 … F12 function keys The function keys (not to be confused with Fn) are the 12 keys at the top of your keyboard. These keys function differently from other keys. F1 through F12 are called function keys because they execute programmed functions when pressed.
  • Page 71: Hot Keys

    The Keyboard Press Fn + F11 to access the integrated keypad. When activated, the keys with gray markings on the bottom edge become numeric keypad keys. Refer to the Keypad overlay section in this chapter for more information on how to operate these keys. The power on default for both settings is off. Press Fn + F12 to lock the cursor on a specific line.
  • Page 72 TOSHIBA Zooming Utility (enlarge): Increases the icon size on the desktop or the font size within one of the supported application windows. Before using Fn + 1 and Fn + 2, you must install the TOSHIBA Zooming Utility. The Utility only supports the following application windows: Microsoft Internet Explorer, Microsoft Office, Windows Media Player, Adobe Reader and the icons on the desktop.
  • Page 73: Windows® Special Keys

    The Keyboard Fn Sticky key (Depends on the model you purchased) You can use the TOSHIBA Accessibility Utility to make the Fn key sticky, that is, you can press it once, release it, and then press an "F number" key.
  • Page 74: Generating Ascii Characters

    The Keyboard The numeric keypad overlay Temporarily using normal keyboard (overlay on) While using the overlay, you can temporarily access the normal keyboard without turning off the overlay: 1. Hold Fn and press any other key. All keys will operate as if the overlay were off.
  • Page 75: Chapter 6 Power And Power-Up Modes

    Power and Power-Up Modes Chapter 6 Power and Power-Up Modes The computer's power resources include the AC adaptor and internal batteries. This chapter gives details on making the most effective use of these resources including charging and changing batteries, tips for saving battery power, and power up modes.
  • Page 76: Power Indicators

    Power and Power-Up Modes Power indicators As shown in the above table, the Battery. Power indicators on the system indicator alert you to the computer’s operating capability and battery charge status. Battery indicator Check the Battery indicator to determine the status of the battery pack. The following indicator lights indicate the battery status: Flashing orange The battery charge is low.
  • Page 77: Battery Pack

    Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not remove the battery pack while the computer is in Standby Mode.
  • Page 78: Care And Use Of The Battery Pack

    The computer's RTC battery is a lithium ion battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed of.
  • Page 79: Safety Precautions

    Power and Power-Up Modes Safety precautions Mishandling of batteries can cause death, serious injury or property damage. Carefully observe the following advisories: Danger: Indicates an imminently hazardous situation, which could result in death or serious injury, if you do not follow instructions. Warning: Indicates a potentially hazardous situation, which could result in death or serious injury, if you do not follow instructions.
  • Page 80 Never use the computer again until it has been checked by a TOSHIBA service provider. It might generate smoke or fire, or the battery pack might rupture. 3. Make sure the battery is securely installed in the computer before attempting to charge the battery pack.
  • Page 81: Charging The Batteries

    Power and Power-Up Modes Note 1. Never remove the battery pack while the Wake-up on LAN function is enabled. Data will be lost. Before you remove a battery pack, disable the Wake-up on LAN function. 2. After the battery pack is charged, avoid leaving the AC adaptor connected and the computer turned off for more than a few hours at a time.
  • Page 82: Battery Charging Notice

    Power and Power-Up Modes Battery charging notice The battery may not charge right away under the following conditions: ■ The battery is extremely hot or cold. If the battery is extremely hot, it might not charge at all. To ensure the battery charges to its full capacity, charge the battery at room temperature of 10°C to 30°C (50°...
  • Page 83: Maximizing Battery Operating Time

    Power and Power-Up Modes Maximizing battery operating time A battery’s usefulness depends on how long it can supply power on a single charge. How long the charge lasts in a battery depends on: ■ CPU processing speed (Depends on the model you purchased). ■...
  • Page 84: Replacing The Battery Pack

    Power and Power-Up Modes Extending battery life To maximize the life of your battery pack: ■ At least once a month, disconnect the computer from a power source and operate it on battery power until the battery pack fully discharges. Before doing so, follow the steps below.
  • Page 85: Removing The Battery Pack

    Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by TOSHIBA as replacements. ■ Do not touch the latch while holding the computer. Or you may get injured by the dropped battery by unintentional release of the latch.
  • Page 86: Starting The Computer By Password

    Power and Power-Up Modes 3. Insert the battery pack. 4. Ensure the battery pack lock is moved into its locked position. Battery pack Battery Pack Lock Securing the battery pack Starting the computer by password To start up the computer with the user password, follow these steps: 1.
  • Page 87: Panel Power Off/On

    Power and Power-Up Modes Hot keys You can use hot keys Fn + F3 to enter Standby Mode and Fn + F4 to enter Hibernation Mode. Refer to Chapter 5, The Keyboard of your online manual for details. Panel power off/on You can set up your computer so that power turns off automatically when you close the display panel.
  • Page 88: Chapter 7 Hw Setup

    HW Setup Chapter 7 HW Setup This chapter explains how to use TOSHIBA HW Setup program to configure your computer. TOSHIBA HW Setup lets you configure settings for General, Password, Display, Boot Priority, Keyboard, LAN, and USB. Accessing HW Setup To run HW Setup, click Start, click Control Panel, click Printers and Other Hardware and select TOSHIBA HW Setup.
  • Page 89: Boot Priority

    HW Setup Password This tab allows you to set or reset the user password for power on. User Password Lets you register a new password or un-register an existing password. Not Registered Un-registers an existing password Registered Register a new password by following the on screen instructions Owner String This blank field is used to display a message when the password field is...
  • Page 90 HW Setup Keyboard Wake-up on Keyboard When this feature is enabled and the computer is in Standby Mode, you can turn on the computer by pressing any key. It is effective only for the internal keyboard and only when the computer is in Standby Mode. Enabled Enables the Wake-up on Keyboard function.
  • Page 91: Chapter 8 Optional Devices

    Optional Devices Chapter 8 Optional Devices Optional devices can expand the computer's capabilities and its versatility. This chapter describes connection or installation of the following devices, which are available from your TOSHIBA dealer: Cards/memory ■ Express Card ■ SD (Secure Digital)/MMC (Multi Media Card)/MS (Memory Stick)/MS Pro (Memory Stick Pro)/xD (xD-Picture Card) cards ■...
  • Page 92: Removing Express Card

    Optional Devices To install an Express Card, follow the steps below. 1. Insert the Express Card. 2. Press gently to ensure a firm connection. ® Windows hot-install feature lets you insert Express Card while the computer’s power is on. Express Card Inserting the Express Card After inserting the card, refer to the card’s documentation and check the ®...
  • Page 93: Sd/Mmc/Ms/Ms Pro/Xd Memory Cards

    Optional Devices 4. Grasp the extended Card, and remove it. Express Card Eject button Removing the Express Card SD/MMC/MS/MS Pro/xD Memory cards The computer is equipped with a multiple digital media card slot that can accommodate SD/MMC/MS/MS Pro/xD memory cards. These memory cards let you easily transfer data from devices, such as digital cameras and Personal Digital Assistants, which use flash-memory.
  • Page 94: Installing A Memory Card

    Optional Devices ® Do not format a memory card with Windows as it might result in that card not being able to be used with some peripheral devices. Memory Stick Duo/PRO Duo and the Memory Stick adaptor are not compatible with the Multiple Digital Media Card Slot. Do not insert Memory Stick Duo/PRO Duo into the slot.
  • Page 95: Removing A Memory Card

    Optional Devices Removing a memory card To remove a memory card, follow the steps below: 1. Click the Safely Remove Hardware icon on the Taskbar. 2. Select a device, then click the Stop button. A confirmation dialog may appear, depending on how the device is registered with the system; if so, confirm that you want to remove the device.
  • Page 96: Memory Expansion

    RAM. This section describes how to install and remove a memory module. ■ Use only memory modules approved by TOSHIBA. ■ Do not try to install or remove a memory module under the following conditions. You can damage the computer and the module. Also, data will be lost.
  • Page 97 Optional Devices Memory Module Cover Removing the memory module cover 6. Lift one side of the insulator sheet and fit the module's connectors into the computer's connectors at about a 45 degree angle. Press the module carefully to ensure a firm connection. Do not touch the connectors on the memory module or on the computer.
  • Page 98: Removing A Memory Module

    Optional Devices 9. Replace the battery pack as described in Chapter 6, Power and Power- Modes. 10. Turn the power on and make sure the added memory is recognized. Open System in the Control Panel and click the General tab. Points to note about memory module error If you install a memory module that is not compatible with the computer, the Power indicator will flash (on for 0.5 seconds, off for 0.5 seconds) in the...
  • Page 99: Additional Battery Pack

    Optional Devices Latches Removing the memory module 6. Seat the cover and secure it with screws and replace the battery pack. Additional battery pack You can increase the portability of the computer with additional battery packs. If you’re away from an AC power source and your battery runs low, you can replace it with a freshly charged battery.
  • Page 100: External Monitor

    Optional Devices External monitor An external analog monitor can be connected to the external monitor port on the computer. The computer supports several video modes. Refer to Appendix B, Display Controller and Modes. To connect a monitor, follow the steps below. 1.
  • Page 101: Troubleshooting

    Troubleshooting Chapter 9 Troubleshooting TOSHIBA designed the computer for durability. However, should problems occur, following the procedures in this chapter can help to determine the cause. All readers should become familiar with this chapter. Knowing what might go wrong can help prevent problems from occurring.
  • Page 102: Analyzing The Problem

    Troubleshooting ■ Inspect all connecting cables for loose wires and all connectors for loose pins. ■ Check that your CD/DVD/CD-RW is correctly inserted. Make notes of your observations and keep them in a permanent error log. This will help you describe your problems to your dealer. If a problem recurs, the log will help you identify the problem faster.
  • Page 103: Hardware And System Checklist

    This message remains on the screen for a few seconds. If the self test is successful, the computer tries to load the operating system, depending on how the Boot Priority is set in the TOSHIBA HW Setup program. If any of the following conditions are present, the self test failed: ■...
  • Page 104: Overheating Power Down

    Troubleshooting Power When the computer is not plugged into an AC outlet, the battery pack is the primary power source. However, your computer has a number of other power resources, including an intelligent power supply and a Real Time Clock battery. These resources are interrelated and any one could affect apparent power problems.
  • Page 105: Disposing Of Pc And Pc Batteries

    Troubleshooting Battery If you suspect a problem with the battery, check the Battery indicator. For information on indicator and battery operation refer to Chapter 6, Power and Power-Up Modes. Problem Procedure Battery doesn't power The battery may be discharged. Connect the AC the computer adaptor to charge the battery.
  • Page 106: Real Time Clock

    Troubleshooting ■ Please be kind to our shared environment. Check with your local government authority for details regarding where to recycle old batteries or how to dispose of them properly. This product contains mercury. Disposal of this material may be regulated due to environmental considerations.
  • Page 107: Lcd Panel

    Troubleshooting Keyboard Keyboard problems can be caused by your setup configuration. For more information refer to Chapter 5, Keyboard. Problem Procedure Some letter keys Check that the numeric keypad overlay is not produce numbers selected. Press Fn + F11 and try typing again. Output to screen is Make sure the software you are using is not garbled...
  • Page 108 Troubleshooting DVD Super Multi drive (Supporting DVD±R Double Layer) For more information, refer to Chapter 4, Operating Basics. Problem Procedure You cannot access a Make sure the drive's drawer is securely closed. CD/DVD in the drive Press gently until it clicks into place. Open the drawer and make sure the CD/DVD is properly seated.
  • Page 109 Troubleshooting Pointing device If you are using a USB mouse, also refer to the USB section in this chapter and to your mouse documentation. TouchPad Problem Procedure On-screen pointer does The system might be busy. If the pointer is not respond to Pad shaped as an hourglass, wait for it to return to its operation normal shape and try again to move it.
  • Page 110: Usb Mouse

    Troubleshooting USB mouse Problem Procedure On-screen pointer does The system might be busy. If the pointer is not respond to mouse shaped as an hourglass, wait for it to resume its operation normal shape and try again to move it. Make sure the mouse is properly connected to the USB port.
  • Page 111: Sound System

    Troubleshooting Memory expansion Refer also to Chapter 8, Optional Devices, for information on installing memory modules. Problem Procedure The computer hangs up Make sure the memory module installed in the expansion slot is compatible with the computer. If an incompatible module has been installed, follow the steps below.
  • Page 112 Troubleshooting Problem Procedure Display error occurs Check that the cable connecting the external monitor to the computer is attached firmly. If problems persist, contact your dealer. Modem Problem Procedure Communication Make sure the computer's internal modem software can’t initialize settings are correct. Refer to Phone and Modem modem Properties in the Control Panel.
  • Page 113 Troubleshooting Problem Procedure Cannot access LAN Check for a firm cable connection between the LAN jack and the LAN hub. If problems persist, consult your LAN administrator. Wireless LAN If the following procedures do not restore LAN access, consult your LAN administrator.
  • Page 114: Toshiba Support

    Troubleshooting TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system, it is important to investigate other sources of assistance first.
  • Page 115: Specifications

    Specifications Appendix A Specifications This appendix summarizes the computer's technical specifications. Physical Dimensions Weight 1.99 Kg * Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected. Size 310 (w) × 227 (d) × max. 34.0/min. 27.6 (h) millimetres (not including parts that extend beyond the main body).
  • Page 116 Specifications Built-in Modem Network control unit (NCU) Type of NCU Type of line Telephone line (analog only) Type of dialling Pulse Tone Control command AT commands EIA-578 commands Monitor function Computer's speaker Communication specifications Communication Data: Full duplex System Fax: Half duplex Communication Data protocol...
  • Page 117: Display Controller And Modes

    Display Controller and Modes Appendix B Display Controller and Modes Display controller The display controller interprets software commands into hardware commands that turn particular picture elements (pels) on or off. The controller is an advanced Video Graphics Array (VGA) that provides Graphics Array (XGA) support for the internal LCD and external monitors.
  • Page 118 Display Controller and Modes Video Type Resolution Character LCD colors CRT colors Scanning mode matrix frequency (pels) Vertical (Hz) 0, 1 40 × 25 8 × 8 16 of 256K 16 of 256K Text Characters 2, 3 80 × 25 8 ×...
  • Page 119 Display Controller and Modes Resolution LCD colors CRT colors Vertical frequency (Hz) 800 × 600 256K/256K 256K/256K 1024 × 768 256K/256K 256K/256K 1280 × 800 256K/256K 256K/256K 1280 × 1024 256K/256K 1600 × 1200 256K/256K 1920 × 1440 256K/256K 2048 × 1536 256K/256K Some modes are not supported at LCD+CRT simultaneous mode and LCD+CRT Multi Monitor mode.
  • Page 120 Display Controller and Modes LCD colors CRT colors Vertical Resolution frequency (Hz) 800 × 600 16M/16M 16M/16M 1024 × 768 16M/16M 16M/16M 1280 × 800 16M/16M 16M/16M 1280 × 1024 16M/16M 1600 × 1200 16M/16M 1920 × 1440 16M/16M 2048 × 1536 16M/16M Some modes are not supported at LCD+CRT simultaneous mode and LCD+CRT Multi Monitor mode.
  • Page 121: Display Settings

    Display Controller and Modes Display Settings 1. You cannot move from the Settings tab of Display Properties to the multi-monitor when you are using the display of the computer and an external CRT display at the same time. ■ The Settings tab is displayed in the following steps; ■...
  • Page 122 Display Controller and Modes ■ With external monitor connected, choose the options under Multiple Display, then select OK. ® Display Properties (Multiple Monitors) and Intel Express Series Properties 2. In some cases DVD video playback images may not be displayed when the display of the computer and a CRT display are used at the same.
  • Page 123: Wireless Lan

    Wireless LAN Appendix C Wireless LAN Card Specifications Form Factor Mini PCI TypeIII ■ Compatibility IEEE 802.11 Standard for Wireless LANs. ■ Wi-Fi (Wireless Fidelity) certified by the Wi-Fi Alliance. The "Wi-Fi CERTIFIED" logo is a certification mark of the Wi-Fi Alliance. ®...
  • Page 124 Subject to the radio regulations that apply in the countries/regions, your Wireless LAN card may support a different set of 2.4 GHz channels. Consult your Authorized Wireless LAN or TOSHIBA Sales office for information about the radio regulations that apply in the countries/regions.
  • Page 125 Wireless LAN When installing Wireless LAN cards, the channel configuration is managed as follows: ■ For wireless clients that operate in a Wireless LAN Infrastructure, the Wireless LAN card will automatically start operation at the channel identified by the Wireless LAN Access Point. When roaming between different access points the station can dynamically switch to another channel if required.
  • Page 126: Ac Power Cord And Connectors

    AC Power Cord and Connectors Appendix D AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Length: Minimum 1.7 meters...
  • Page 127 AC Power Cord and Connectors The following illustrations show the plug shapes for the U.S.A. and Canada, the United Kingdom, Australia and Europe. USA and Canada United Kingdom UL approved BS approved CSA approved Australia Europe AS approved Approved by the appropriate agency User’s Manual...
  • Page 128: Legal Footnotes

    Legal Footnotes Appendix E Legal Footnotes This chapter states the Legal Footnotes information applicable to TOSHIBA computers. In the text in this manual, *XX is used to show which Legal Footnotes description is related to TOSHIBA computers. Description(s) related to this computer are marked with a blue *XX in this manual.
  • Page 129: Battery Life

    Published battery life numbers are achieved on select models and configurations tested by TOSHIBA at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power.
  • Page 130: Copy Protection

    Legal Footnotes Hard Disk Drive (HDD) Capacity 1 Gigabyte (GB) means 10 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 2 = 1,073,741,824 bytes, and therefore shows less storage capacity.
  • Page 131: If Your Computer Is Stolen

    What is your address, phone, and fax number? To register the theft on paper, please follow these procedures: ■ Fill in the TOSHIBA Theft Registration form (or a copy of it) below. ■ Attach a copy of your receipt showing where your computer was purchased.
  • Page 132: Toshiba Theft Registration

    If your computer is stolen TOSHIBA Theft Registration Send to: TOSHIBA Europe GmbH Technical Service and Support Leibnizstr. 2 93055 Regensburg Germany Fax number: +49 (0) 941 7807 921 Country stolen: Machine type: (e.g. U300 Series) Model number: (e.g. PSA50 YXT) Serial number: (e.g.
  • Page 133: Glossary

    U300 Series Glossary The terms in this glossary cover topics related to this manual. Alternate naming is included for reference. Abbreviations AC: alternating current AGP: accelerated graphics port ANSI: American National Standards Institute APM: advanced power manager ASCII: American Standard Code for Information Interchange BIOS: basic input output system CD-ROM: Compact Disc-Read Only Memory CD-RW: Compact Disc-Read/Write...
  • Page 134 U300 Series ® MS-DOS: Microsoft disk Operating System OCR: optical character recognition (reader) PCB: printed circuit board PCI: peripheral component interconnect RAM: random access memory RGB: red, green, and blue ROM: read only memory RTC: real time clock SCSI: small computer system interface SIO: serial input/output SXGA+: super extended graphics array plus TFT: thin-film transistor...
  • Page 135 U300 Series ASCII: American Standard Code for Information Interchange. ASCII code is a set of 256 binary codes that represent the most commonly used letters, numbers, and symbols. async: Short for asynchronous. asynchronous: Lacking regular time relationship. As applied to computer communications, asynchronous refers to the method of transmitting data that does not require a steady stream of bits to be transmitted at regular time intervals.
  • Page 136 U300 Series cache memory: High speed memory which stores data that increases processor speed and data transfer rate. When the CPU reads data from main memory, it stores a copy of this data in cache memory. The next time the CPU needs that same data, it looks for it in the cache memory rather than the main memory, which saves time.
  • Page 137 U300 Series computer program: A set of instructions written for a computer that enable it to achieve a desired result. computer system: A combination of hardware, software, firmware, and peripheral components assembled to process data into useful information. configuration: The specific components in your system (such as the terminal, printer, and disk drives) and the settings that define how your system works.
  • Page 138 U300 Series disk drive: The device that randomly accesses information on a disk and copies it to the computer's memory. It also writes data from memory to the disk. To accomplish these tasks, the unit physically rotates the disk at high speed past a read-write head. disk storage: Storing data on magnetic disk.
  • Page 139 The computer's feature in which certain keys in combination with the extended function key, Fn, can be used to set system parameters, such as speaker volume. HW Setup: A TOSHIBA utility that lets you set the parameters for various hardware components. User’s Manual...
  • Page 140 U300 Series icon: A small graphic image displayed on the screen or in the indicator ® panel. In Windows , an icon represents an object that the user can manipulate. i.LINK (IEEE1394): This port enables high-speed data transfer directly from external devices such as digital video cameras. input: The data or instructions you provide to a computer, communication device or other peripheral device from the keyboard or external or internal storage devices.
  • Page 141 U300 Series level 2 cache: See cache. Light Emitting Diode (LED): A semiconductor device that emits light when a current is applied. Liquid Crystal Display (LCD): Liquid crystal sealed between two sheets of glass coated with transparent conducting material. The viewing side coating is etched into character forming segments with leads that extend to the edge of the glass.
  • Page 142 U300 Series nonvolatile memory: Memory, usually read-only (ROM), that is capable of permanently storing information. Turning the computer's power off does not alter data stored in nonvolatile memory. numeric keypad overlay: A feature that allows you to use certain keys on the keyboard to perform numeric entry, or to control cursor and page movement.
  • Page 143 A Class A device is sufficient for office use. Class B provides a more stringent classification for home equipment use. TOSHIBA portable computers comply with Class B computing device regulations. Random Access Memory (RAM): High speed memory within the computer circuitry that can be read or written to.
  • Page 144 TFT display: A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology with thin film transistor (TFT) to drive each cell. TouchPad: A pointing device integrated into the TOSHIBA computer palm rest. TTL: Transistor-transistor logic. A logic circuit design that uses switching transistors for gates and storage.
  • Page 145: Index

    U300 Series Index AC adaptor, 1-3 Equipment checklist, 1-1 additional, 1-11 connecting, 3-2 ASCII characters, 5-6 Floppy disk using, 4-4 Fn + Esc (sound mute), 5-3 Battery Fn + F1 (instant security), 5-3 charging, 6-7 Fn + F2 (power save mode), 5-3 extending battery life, 6-10 Fn + F3 (Standby Mode), 5-3 indicator, 6-1...
  • Page 146 Modem, 1-7, 4-14 Real Time Clock, 9-6 connecting, 4-16 Self test, 9-3 disconnecting, 4-16 Sound system, 9-11 properties menu, 4-15 Support from TOSHIBA, 9-14 region selection, 4-14 System start-up, 9-3 Monitor, external, 1-6, 8-10 USB, 9-10 Wireless LAN, 9-13 Processor, 1-2...
  • Page 147 5-3 Standby setting, 3-7 Standby Mode, 1-9 setting, 3-5 System automatic, 1-8 TOSHIBA ConfigFree, 1-10 TOSHIBA Disc Creator, 1-10 TOSHIBA Theft Registration, F-2 Touch Pad, 1-6 location, 2-6 using, 4-1 USB, 1-6 Video modes, B-1 Video RAM, 1-3...

This manual is also suitable for:
