Audio Subsystem

The onboard audio subsystem consists of the following:
®
• Intel ICH7
• Realtek ALC888VC audio codec
• Back panel audio connectors (see Figure 19)
• Front panel audio header supporting both Intel High Definition Audio and AC '97
Audio (see Figure 18, A)
The audio subsystem supports the following features:
• A signal-to-noise (S/N) ratio of 95 dB
• Independent 5.1 audio playback from the back panel connectors and stereo
playback from the Intel High Definition Audio front panel header
Table 3 lists the supported functions for the front panel and back panel audio jacks.
Table 3. Audio Jack Retasking Support
Jack Mic
Green No
Pink Yes
Blue No
Green No
Pink Yes

Legacy Input/Output (I/O) Controller

The Winbond 83627DHG-P legacy I/O controller provides the following functions:
• One serial port interface via an onboard header
• One parallel port
• Serial IRQ interface compatible with serialized IRQ support for PCI systems
• Intelligent power management, including a programmable wake up event interface
• PCI power management support
Line out Headphones
Front Panel
Yes Yes
No No
Back Panel
No No
Yes Yes
No No
Desktop Board Features
Rear
Line in
Surround
No No
No No
Yes Yes
No No
No No
Center/
Subwoofer
No
No
No
No
Yes
15
