Hunter 28672 Parts Manual

Hardware
(Drawn to Scale)
x 2
x 4
Flat Washer
x 2
x 4 Canopy Screw
Mounting
x 4
Isolator
Screw, Blade
x 11
Iron Armature
Screw, Blade
x 16
Assembly
Blade
x 16
Grommet
Balancing
x 1
Kit
Screw, Switch
x 3
Housing Assembly
Wire
x 4
Connector
Screw,
x 3
Machine, 6-32
3" Wood Screw
Hanger
1.5" Wood Screw Bracket
Assembly
Blade
Assembly
Switch
Housing
Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model #
Parts List
Asm. Dwg. #
Finish Northern Sienna
Item Name Qnty
* Hanging System Kit 1
Hanger Ball / Downrod Assembly 1
Ceiling Plate
Canopy
Canopy Trim Ring
Canopy Screw
Wood Screw 1.5"
Wood Screw 3"
Flat Washer
Mounting Isolator
Switch Housing Assembly 1
Switch Housing Cover 1
Switch Housing Plug Button 1
Light Kit Assembly 1
Blade Iron Set 1
Blade Set 1
Screw, Blade Iron Armature 11
Hardware Kit 1
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1
Pull Chain Pendant 1
Pull Chain Pendant 1
Pull Chain 1
Pull Chain 1
Cap, Finial 1
Finial 1
Dummy Terminal, Male 1
Dummy Terminal, Female 1
Globe/Shade 1
Hunter Fan Company • 7130 Goodlett Farms Pkwy. #400 • Memphis, TN 38016 • www.hunterfan.com • 98000-02-034 05-20-2010 •
28672
99920-01
Part #
98026-93
87942-03
99919-93
73853-01
73854-01
98547-01
98718-05
G0253-95
63755-05
99920-00-860
65666-03
G0090-01
G0091-01
63756-18
63756-58
67401-02
66747-01
08198-01
08200-01
89649-01
2010
©
