Owner's Guide and Installation Manual
Advertisement
Table of Contents
Related Manuals for Hunter 28679
Summary of Contents for Hunter 28679
- Page 1 Warranty Assistance For reference, also attach your receipt or a copy of your receipt to the manual. Owner’s Guide and Installation Manual __________________________________________ Model Name __________________________________________ Model No. __________________________________________ Date Purchased __________________________________________ Where Purchased Form# 42439-01 20100615 ©2010 Hunter Fan Co.
-
Page 2: Table Of Contents
8 • Operating and Cleaning Your use a solid-state speed control with this fan. Use only Hunter speed Ceiling Fan......14 controls. -
Page 3: Preparing The Fan Site
If you want to use an existing fan site, complete the following checklist to System determine if the site is acceptable and safe for your new Hunter fan. If you cannot check off every item, prepare a new fan site as described on this page. - Page 4 ANSI/NFPA 70. If your ceiling fan, go to your fan manual and continue with Section 2 • Installing the you are unfamiliar with wiring, use a Ceiling Plate. qualified electrician. 42439-01 • 06/15/10 • Hunter Fan Company...
- Page 5 Support Brace Hunter’s patented 3-position mounting system provides you maximum installation flexibility and ease. You can install your Hunter fan in one of three ways, depending on ceiling height and your preference: Low Profile, Standard, or Angled mounting. The steps in this manual include Ceiling instructions for all three Installer’s Choice mounting methods.
-
Page 6: Getting Ready
• Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •... -
Page 7: Installing The Ceiling Plate
Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Ceiling Plate Flat Washer 3” Wood Steps 2-3 – 2-6 Screw 42439-01 • 06/15/10 • Hunter Fan Company... -
Page 8: Assembling And Hanging The Fan
Adapter 3-7. Raise the fan and align the slots in the canopy with the hooks on the ceiling plate. Low Profile Washer 3-8. Place the slots over the hooks to hang the fan. 42439-01 • 06/15/10 • Hunter Fan Company... -
Page 9: Wiring The Fan
4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42439-01 • 06/15/10 • Hunter Fan Company... -
Page 10: Installing The Canopy And Canopy
Note: Should you need to remove the trim ring, press firmly on Canopy opposite sides of the trim ring directly above the groove in the Trim hanger ball. The tabs will flex out releasing the canopy trim ring. Ring Canopy Screw 42439-01 • 06/15/10 • Hunter Fan Company... -
Page 11: Assembling The Blades
Using pliers, loosen the blade iron posts by turning them Step 6-2 counterclockwise. Once they are loosened, finish unscrewing them by hand until they are completely separated from the blade iron. Carefully remove the blade. 42439-01 • 06/15/10 • Hunter Fan Company... -
Page 12: Completing Your Installation With A Bowl Light Fixture
MAX wattage sticker affixed to the light socket(s) may result in fire hazard or improper operation. If lights do not appear to be operating properly, see the troubleshooting section. Notch Lower Switch Housing Steps 7-3 - 7-5 42439-01 • 06/15/10 • Hunter Fan Company... - Page 13 (included) to the light and fan Metal Disc pull chains using the plastic breakaway connector. (You may find the plastic breakaway connector on the end of the extra Metal Rod chain.) Glass Bowl Cover Plate Breakaway Connector Finial 42439-01 • 06/15/10 • Hunter Fan Company...
-
Page 14: Ceiling Fan
8-5. The blades on this fan have been treated with Hunter’s Dust Armor protection, making the blades less likely to attract dust and dirt. -
Page 15: Troubleshooting
If you need parts or service assistance, please call 888-830-1326 (in Canada, call 1-866-268-1936) or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 7130 Goodlett Farms Pkwy. #400 Memphis, Tennessee 38016 42439-01 • 06/15/10 • Hunter Fan Company...
