User Instructions
Revised 5/02
Elation Professional
®
4295 Charter Street
Los Angeles Ca. 90058
www.elationlighting.com
DMX Branch 419™
Introduction:
To optimize the performance of this product, please
read these operating instructions carefully to familiarize yourself with
the basic operations of this unit. The DMX Branch 419™ is a 4-way
DMX signal distributor by Elation Professional
user to split and boost a DMX signal anywhere in a DMX signal path,
a function that is typically not recommended without the use of device
similar to this one. The unit has been durably constructed in a rack
mount chassis for convenient rackmount storage.
Unpacking:
Thank you for purchasing the DMX Branch 419™ by
Elation Professional
. Every DMX Branch 419™ has been thoroughly
®
tested and has been shipped in perfect operating condition. Carefully
check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your
unit for damage and be sure all accessories necessary to operate the
unit have arrived intact. In the event damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Please do not return this unit to your dealer with-
out first contacting customer support at the number listed below.
Customer Support:
Elation Professional
port line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.elationlighting.com for any com-
ments or suggestions. For service related issue please contact Elation
Professional
. Service Hours are Monday through Friday 9:00 a.m. to
®
5:00 p.m. Pacific Standard Time.
Voice:
(323) 582-3322
Fax:
(323) 582-3108
E-mail:
support@elationlighting.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty.
Please do not discard the shipping carton in the trash. Please recycle
when ever possible.
Elation Professional
www.elationlighting.com - DMX Branch 419™ User Manual Page 2
©
® -
Introduction
. This unit allows the
®
