Thank you very much for choosing an EIZO product.
Please read this User's Manual carefully to familiarize yourself with safe and effective usage procedures.
Please retain this manual for future reference.
PRECAUTIONS
To ensure personal safety and proper maintenance, please read this
section and the caution statements on the unit.
WARNING
Do not attempt to install the unit yourself.
To install the monitor with this product, it is required the expert knowledge of building
techniques. Refer the installation to qualified personnel.
Attach the applicable EIZO LCD monitor only.
Not doing so may cause the arm or monitor to fall, which may result in injury or
equipment damage.
Affix the arm securely on the base.
Not doing so may cause the monitor to fall and result in injury or equipment damage.
Affix the arm on an appropriate base.
Do not affix the arm on such a base as shown below or on a weak base which cannot
support the monitor or arm. Affixing the arm on these bases may cause the monitor to
fall and result in injury.
Clamp the screws of the arm tightly.
If the arm becomes unstable, clamp the screws of the arm securely again. Loose clamping
may cause the monitor to fall and result in injury or equipment damage.
Do not hang from or lean on the arm.
Doing so may cause the monitor to fall and result in injury or equipment damage.
When moving the arm, be sure not to pinch a finger between the moving parts.
Do not rotate the monitor more than necessary or reverse direction.
Twisting or breaking cable may result in fire or electric shock.
Do not disassemble.
The spring mechanism inside of the stand may result in injury or equipment damage when
disassembling.
Attach the arm with another person.
Do not attach it alone. Doing so may result in injury or equipment damage.
Do not tilt
No opening
[Location of the Caution Statements]
Do not run over
Advertisement
Table of Contents
Related Manuals for Eizo LA-012-W
Summary of Contents for Eizo LA-012-W
- Page 1 Thank you very much for choosing an EIZO product. Please read this User’s Manual carefully to familiarize yourself with safe and effective usage procedures. Please retain this manual for future reference. PRECAUTIONS To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit.
- Page 2 Package Contents ________________________________ Please contact your local dealer for assistance if any of the listed items are missing or damaged. Wall Anchor Arm Cover, 2 pcs User's Manual Sheet (Compatible Screws List) Mounting Screws (M4 x 8 flat head screws), 3 pcs Mounting Screws, 4 pcs each (For the compatible screws and monitors, refer to the ‘Compatible Screws List’.) *Screws for attaching the monitor with arm to the Wall Anchor.
- Page 3 Attach the monitor attachment of the arm to the monitor. (1) Attach the arm to the monitor with specific screws (4 points). (2) Put in the arm covers to the shield plate with sliding them rightward or leftward. NOTE Use specified screws for tightening up between the arm, fitting and monitor referring to the ‘Compatible Screws List’.
-
Page 4: Specifications
How to adjust the monitor __________________________ Grip both side of the monitor, adjust the swivel angle of the screen. Slightly adjust the monitor angle. When swiveling the monitor, the screen angle may tilt. Adjust the monitor angle to be horizontal. Grip top and bottom of the monitor and adjust the tilt angle of the screen. -
Page 5: Limited Warranty
In the event of malfunction of the product during the warranty period attributable directly to defective material and/or workmanship, EIZO and EIZO’s authorized distributors will, at their option, either repair or replace the defective product. EIZO and EIZO’s authorized distributors shall have no obligation under this warranty,... - Page 6 MEMO...
