Thank you very much for choosing the EIZO product.
Please read this User's Manual carefully to familiarize yourself with safe and effective usage procedures.
Please retain this manual for future reference.
PRECAUTIONS
To ensure personal safety and proper maintenance, please read this
section and the caution statements on the unit.
WARNING
Attach the applicable EIZO LCD monitors only.
Not doing so may cause the stand or monitor to drop, which may result in injury or
equipment damage.
Attach the two monitors.
Attaching a monitor only may cause the stand to fall and result in injury or equipment
damage.
Attach the LCD monitor securely to the stand.
Install the monitor securely with using the enclosed screws in the stand package. Follow the
instructions on the user's manual. Not doing so may cause the monitor to come unattached,
which may result in injury or equipment damage.
Do not disassemble.
The spring mechanism inside of the stand may result in injury or equipment damage when
disassembling.
CAUTION
Carry the stand with holding the arm of the stand
below figures.
Not doing so may result in the equipment damage.
Work with another person when attaching and adjusting height position.
Not doing so may result in injury or equipment damage.
Be careful not to pinch a finger when adjusting height and horizontal position.
When rotating the monitor for portrait display, make a space enough between a desk
and a monitor not to pinch a finger.
Do not adjust the height or the angle with gripping the i·Sound, optional speaker (if
applicable).
Adjusting the height or the angle with gripping the i·Sound is dangerous. It may result in
injury or equipment damage.
Before installation, visit our web site at
http://www.eizo.com to confirm the applicable EIZO
LCD monitor and the installation requirements of
this stand.
from underneath
Before attaching
[Location of the Caution Statements (Bottom)]
as shown in the
Carry with another
person after attaching.
Advertisement
Table of Contents
Related Manuals for Eizo LS-HM1-D
Summary of Contents for Eizo LS-HM1-D
- Page 1 LCD monitor and the installation requirements of this stand. Thank you very much for choosing the EIZO product. Please read this User’s Manual carefully to familiarize yourself with safe and effective usage procedures. Please retain this manual for future reference.
- Page 2 Package Contents ________________________________ Please contact your local dealer for assistance if any of the listed items are missing or damaged. Stand Stand Mouting Cover, 4 pcs Stoppers for height adjustment (attached to the stand, detachable), 5 pcs User’s Manual Sheet (Compatible Screws List) Mounting Screws, 8 pcs each (For the compatible screws and monitors, refer to the ‘Compatible Screws List’.) Note before Use __________________________________...
- Page 3 How to adjust ____________________________________ Height Adjustment Horizontal Position Adjustment Adjust the height with using the stoppers. Grip the top and bottom sides of the monitor firmly (Six stage height adjustable) and slide it with lifting the bottom side of the Attach or remove the stopper from the bottom one monitor to the front.
- Page 4 In the event of malfunction during the warranty period attributable directly to faulty material and/or workmanship, EIZO and EIZO’s authorized distributors will, at their option, either repair or replace the faulty product with the same or similar model. EIZO and EIZO’s authorized distributors shall have no obligation...
