Thank you very much for choosing the EIZO product.
This product helps you to quickly attach or detach an EIZO LCD monitor from its arm (or
the wall mount bracket).
Please read this User's Manual carefully to familiarize yourself with safe and effective usage
procedures.
Please retain this manual for future reference.
PRECAUTIONS
To ensure personal safety and proper maintenance, please read this section.
WARNING
Attach the applicable EIZO LCD monitors only.
Not doing so may cause the monitor to drop, which may result in injury or
equipment damage.
Do not attach this product on a stand.
Doing so may cause the stand to fall or drop and result in injury or equipment
damage.
Attach this product securely to the LCD monitor.
Install the attachment securely with using the enclosed screws in this product
package. Follow the instructions on this User's Manual. Not doing so may
cause the monitor to come unattached, which may result in injury or equipment
damage.
Do not disassemble.
The spring mechanism inside of this product may result in injury or equipment
damage when disassembling.
CAUTION
Work with another person when attaching or detaching.
Not doing so may result in injury or equipment damage.
Be careful not to pinch a finger when attaching or detaching.
Before installation, visit our web site at
http://www.eizo.com to confirm the applicable EIZO
LCD monitor and the installation requirements of
this attachment.
