Thank you very much for choosing the EIZO product.
Please read this User's Manual carefully to familiarize yourself with safe and effective usage procedures.
Please retain this manual for future reference.
PRECAUTIONS
To ensure personal safety and proper maintenance, please read this
section and the caution statements on the unit.
WARNING
Attach the applicable EIZO LCD monitor only.
Not doing so may cause the arm or monitor to fall, which may result in injury or
equipment damage.
Attach the arm with another person.
Do not attach it alone. Doing so may result in injury or equipment damage.
Affix the arm with the enclosed fixing screw(s).
Not doing so may cause the arm or monitor to fall, which may result in injury or
equipment damage.
Affix the arm securely on the base.
Not doing so may cause the monitor to fall and result in injury or equipment damage.
Affix the arm on an appropriate base.
Do not affix the arm on such a base as shown below or on a weak base which cannot
support the monitor or arm. Affixing the arm on these bases may cause the monitor to
fall and result in injury.
Not hooking enough
Clamp the knob of the arm tightly.
If the arm becomes unstable, clamp the knob of the arm securely again.
clamping may cause the monitor to fall and result in injury or equipment damage.
Do not hang from or lean on the arm.
Doing so may cause the monitor to tumble or fall and result in injury or equipment
damage.
When moving the arm, be sure not to pinch a finger between the moving parts.
When rotating the monitor for portrait display, make a space enough between a
desk and a monitor not to pinch a finger.
Do not disassemble.
The spring mechanism inside of the stand may result in injury or equipment damage
when disassembling.
On tapered desk
On Pole
[Location of the Caution Statements]
On Wall
Loose
Advertisement
Table of Contents
Related Manuals for Eizo LA-131-D
Summary of Contents for Eizo LA-131-D
- Page 1 Thank you very much for choosing the EIZO product. Please read this User’s Manual carefully to familiarize yourself with safe and effective usage procedures. Please retain this manual for future reference. PRECAUTIONS To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit.
- Page 2 Please contact your local dealer for assistance if any of the listed items are missing or damaged. Arm Unit (Clamping Part / Arm Part / Attaching-monitor Part)- Arm Cover, 2 pcs User's Manual Sheet (Compatible Screws List) Mounting Screws, 4 pcs each (For the compatible screw and monitors, refer to the ‘Compatible Screws List’) Fixing Screws M4 x 16, 2 pcs Fixing screws are put into the different bag from the bag which the mounting screws (8 pcs) are into.
-
Page 3: Specifications
(1) Attach the Attaching-monitor Part of the unit to the monitor with specific screws (4 points). (2) Put in the arm covers to the shield plate with sliding them rightward or leftward. Attach the monitor to the Arm Part. (1) Draw the arm to one side. Connect the concave portion of the Attaching-monitor Part (below figure A) to the salient of the Arm Part (below figure B). -
Page 4: Limited Warranty
EIZO NANAO CORPORATION (“EIZO”) and EIZO authorized distributors warrant, subject to and in accordance with the terms of this warranty, to the original purchaser who purchased the product from EIZO or EIZO authorized distributors that this product shall be free from defects in material and workmanship for a...
