Eizo ET Arm Series Product Manual

Product Manual
Dimensions and color of the product are subjec to change.
Please, read this manual before using this product.
Please, put the manual at the place within your sight after reading the manual.
The guarantee is included at the back side.
Please, definitely observe the items with the following
instructions because they are for preventing unexpected
danger or losses in advance by using the product safely and
accurately.
Please, use the product properly according to the
Cautions
contents of the manual.
In case a user fails to keep warnings for safety, our after-sale service is not available.
※
Cautions for Safety
Please, be sure to follow the contents of this
manual.
if not , it may be the cause of injuries or breakdowns.
In case screw-loosening or looseness come
upon arm while using, tighten the screw again.
If used in a state where screws are loose, it could be a
cause of injuries or breakdowns by the fall of the
monitor.
Don't disassemble or make over arm.
At a time when repairs are needed, please contact
EIZO SUPPORT.
Don't give any strength or impact to the
product after installing it.
It could cause the damage to the product and impair
its smooth running.
Install the product at a stable wallside which
can stand up under the weight of the product
and monitor.
Please, be cautious because there is a risk of being
damaged.
Product Composition & Speci cations
Main Body of the Product Fixing Bracket on the wall
Moni t or-fi x i n g Bol t Modulating wrench
4 x12mm (4pcs) 4mm (1pcs)
4 x16mm (4pcs)
Cautions for Safety
Don't cling to or lean on the arm or monitor.
It could be the cause of injuries or breakdowns by the
fall of the monitor.
Be careful not to drop the product.
There could be a problem in its motion, so be careful.
Please, definitely use the designated bolts and
tools when installing the product.
In case of using the undesignated bolts or tools, there
might be a fear of a failure in the product or safety
problems.
Please, be careful not to give a shock to the
product when moving it.
I t mi g ht be al s o t h e cause of a product f a i l u re.
Please, use the product properly according to the
Cautions
contents of the manual.
In case a user fails to keep warnings for safety, our after-sale service is not available.
※
Knob Bolt (2pcs)
Anchor Bol t Manual
for fi x i n g
Drawing for wallside
(4pcs)
