Tools
VOLUME
Controls the volume of the speakers or headphones.
To mute the speaker output, touch the "RESET/ECO MODE" key.
SOUND INPUT (HDMI, DisplayPort inputs only)
This function selects AUDIO INPUT, HDMI or DISPLAYPORT.
VIDEO LEVEL (HDMI input only)
NORMAL: Disables the expanded feature.
EXPAND: Expands image contrast and increases details in the dark and bright areas.
OVER SCAN (HDMI input only)
Some video formats may require different scanning modes in order to best display the image.
ON: Image size is larger than what can be displayed. The image edge will appear cropped. Approximately 95% of the
image will be shown on the screen.
OFF: Image size stays within the display area. The whole image is displayed on the screen.
VIDEO DETECT
Selects the method of video detection when more than one video inputs are connected.
FIRST: When current video input signal is not present, then the monitor searches for a video signal from the other
video input port. If the video signal is present in the other port, then the monitor switches the video source input port
to the new found video source automatically. The monitor will not look for other video signals while the current video
source is present.
NONE: The monitor will not search the other video input port unless it is turned on.
EXPANSION MODE
Sets the zoom method.
FULL: The image is expanded to full screen, regardless of the resolution.
ASPECT: The image is expanded without changing the aspect ratio.

OFF TIMER

Monitor will automatically power down when you have selected a pre-determined amount of time.
Before powering off, a message will appear on the screen asking if you want to delay the turn off time by 60 minutes.
Touch any OSD key to delay the power-down time.
LED BRIGHTNESS
You can adjust the blue LED brightness.
DDC/CI
This function allows the DDC/CI function ON or OFF.
FACTORY PRESET
Selecting FACTORY PRESET allows you to reset all OSD control settings back to the factory settings. Individual
settings can be reset by touching the ECO (RESET) Key.

MENU Tools

LANGUAGE
Selects the language used by the OSD.
OSD TURN OFF
The OSD control menu will stay on as long as it is in use. You can select how long the monitor waits after the last touch
of a key to shut off the OSD control menu. The preset choices are 10-120 seconds by 5-second increments.
OSD LOCK OUT
This control completely locks out the access to all OSD control functions except for BRIGHTNESS, CONTRAST and
VOLUME.
To activate the OSD Lock Out function, enter the OSD menu, select OSD LOCK OUT, then press "SELECT" and
RIGHT simultaneously. To deactivate, press "SELECT" and LEFT simultaneously.
English-14
