Roland R-1 Settings Manual

Customers using the EDIROL R-1
If you intend to create a music CD on the CD-2, you must set
the R-1's recording mode to "WAV 16bit" before you record.
A song recorded with
a recording mode of
"WAV 16bit"
Setting the R-1's recording mode
Here's how to set the R-1's recording mode.
1. Press the [MENU] button to enter Setup mode.
2. Turn the VALUE dial to select "Record Mode," and press the [ENTER] button.
3. Turn the VALUE dial to select "WAV 16bit," and press the [ENTER] button.
4. Press the [EXIT] button to complete the setting.
NOTE
Even though a song has been recorded using the "WAV 16bit" recording mode, it won't be
recognized by the CD-2 unless it also meets the following conditions:
• Track length must be longer than four seconds.
• Track title must not contain "~" (tilde) or double-byte characters (e.g., Japanese).
• Track (file) must be located in the root directory of the CompactFlash card.
* The CD-2 is able to display and play back a maximum of 99 tracks.
* For details on creating a music CD, see Pages 46–48 of the CD-2 owner's manual.
<<Necessary free space of CompactFlash>>
When a CompactFlash card previously used by the R-1 is inserted in the CD-2 for the first time, the CD-2 will
create a track list file from the contents that are recorded on the CompactFlash card. Once this track list file is
created, you will be able to perform operations using the CD-2, such as playing back tracks.
Creating the track list file requires 60 KB of space. If the CompactFlash card has less than 60 KB of space
available (for example, when you've used up all available space on the card as the result of using the R-1 to
record for the maximum amount of time), the CD-2 will not be able to create this track list file. In this case, the
CompactFlash card will not be recognized, and the message "CF Not Enough Mem" will appear. You'll need
to use the R-1 to delete unneeded tracks from the card in order to create at least 60 KB of free space.
Once you have used the CD-2 to perform an operation such as playing a track on the CompactFlash card, the
track list file will have been created, so, after that, it won't matter if you record for the maximum possible time
on that card using the R-1.
CompactFlash cards used by
the R-1 can also be used as
they are by the CD-2.
96-8636 5VT
