  • Page 1 MULTIMEDIA PROJECTOR LC-XM1 MODEL OWNER’S MANUAL...

  • Page 2: To The Owner

    Before operating this projector, read this manual thoroughly and operate the projector properly. This projector provides many convenient features and functions. Operating the projector properly enables you to manage those features and maintains it in better condition for a considerable time. Improper operation may result in not only shortening the product-life, but also malfunctions, fire hazard, or other accidents.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS All the safety and operating instructions should be read before the product is operated. Read all of the instructions given here and retain them for later use. Unplug this projector from AC power supply before cleaning. Do not use liquid or aerosol cleaners. Use a damp cloth for cleaning.

  • Page 4: Federal Communication Commission Notice

    Federal Communication Commission Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FEATURES AND DESIGN PREPARATION NAME OF EACH PART OF THE PROJECTOR SETTING-UP THE PROJECTOR CONNECTING THE AC POWER CORD POSITIONING THE PROJECTOR ADJUSTABLE FEET MOVING THE PROJECTOR CONNECTING THE PROJECTOR TERMINALS OF THE PROJECTOR CONNECTING TO THE VIDEO EQUIPMENT CONNECTING TO THE COMPUTER BEFORE OPERATION OPERATION OF THE REMOTE CONTROL...

  • Page 6: Features And Design

    This Multimedia Projector is designed with the most advanced technology for portability, durability, and ease of use. The projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compact Design This projector is extremely compact in size and weight.

  • Page 7: Preparation

    PREPARATION NAME OF EACH PART OF THE PROJECTOR FRONT OF THE CABINET PROJECTION LENS ZOOM RING FOCUS RING SPEAKER (Monaural) LENS COVER INFRARED REMOTE RECEIVER BACK OF THE CABINET TERMINALS AND CONNECTORS BOTTOM OF THE CABINET LAMP COVER AIR INTAKE VENTS AND AIR FILTERS These Air Intake Vents should not be blocked.

  • Page 8: Setting-Up The Projector

    PREPARATION SETTING-UP THE PROJECTOR CONNECTING THE AC POWER CORD This projector uses nominal input voltages of 100-120 V or 200-240 V AC. The projector automatically selects the correct input voltage. It is designed to work with single- phase power systems having a grounded neutral conductor.

  • Page 9: Positioning The Projector

    POSITIONING THE PROJECTOR This projector is designed to project on a flat projection surface. The projector can be focused from 5.2’ (1.6m) ~ 26.3’ (8.0m). Refer to the figure below to adjust the screen size. 5.2’ (1.6m) 41” 34” 34” Screen Size (W x H) mm 690 x 518...

  • Page 10: Moving The Projector

    PREPARATION When moving the projector, replace the lens cover and retract the feet to prevent damage to the lens and cabinet. When this projector is not in use for an extended period, put it into the case (carrying bag) supplied with this projector.

  • Page 11: Connecting The Projector

    CONNECTING THE PROJECTOR TERMINALS OF THE PROJECTOR VIDEO INPUT JACKS (VIDEO/Y, Pb/Cb, Pr/Cr) Connect the composite video output from the video equipment to the VIDEO/Y jack or connect the component video outputs to the Y/VIDEO, Pb/Cb and Pr/Cr jacks. (Refer to P12.) RESET BUTTON This projector uses a micro processor to control the unit.

  • Page 12: Connecting To The Video Equipment

    CONNECTING THE PROJECTOR CONNECTING TO THE VIDEO EQUIPMENT Cables used for connection • Video Cable (RCA x 1 or RCA x 3) • S-VIDEO Cable • Audio Cable (RCA x 2- Mini Plug x 1 (stereo) or Mini Plug (stereo)) Video Source (example) Video Cassette Recorder Use any of VIDEO jack Y-Pb/Cb-Pr/Cr...

  • Page 13: Connecting To The Computer

    CONNECTING TO THE COMPUTER Cables used for connection • VGA CABLE (HDB 15 pin) • CONTROL CABLE FOR PS/2 PORT • CONTROL CABLE FOR SERIAL PORT, or ADB PORT • MAC ADAPTER (When connecting to Macintosh computer) • AUDIO CABLE (Mini Plug (stereo)) IBM-compatible computers or Macintosh computers (VGA / SVGA / XGA / SXGA) Monitor Output MAC Adapter...

  • Page 14: Before Operation

    BEFORE OPERATION OPERATION OF THE REMOTE CONTROL Left Side ALL-OFF SWITCH When using the Remote Control Unit, turn this switch to “ON.” And turn it to “ALL OFF” when it is not used. Point the remote control toward the projector (the Remote Receiver) whenever pressing the buttons.

  • Page 15: Remote Control Batteries Installation

    KEYSTONE BUTTON Used to correct the KEYSTONE keystone distortion. (P20, 28, 30) MUTE MUTE BUTTON MENU Used to mute sound.(P21) NO SHOW BUTTON Used to turn the picture NO SHOW into black image. (P21) AUTO IMAGE AUTO IMAGE BUTTON Use to operate AUTO IMAGE function.

  • Page 16: Top Controls And Indicators

    BEFORE OPERATION TOP CONTROLS AND INDICATORS MENU BUTTON Used to open or close the MENU operation. (P17, 18) POWER ON–OFF BUTTON Used to turn the projector on or off. (P19) ON – OFF NORMAL NORMAL BUTTON Used to reset to normal picture adjustment preset by factory.

  • Page 17: Operating On-Screen Menu

    OPERATING ON-SCREEN MENU HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector through the ON- SCREEN MENU. Refer to the following pages to operate each adjustment in the ON-SCREEN MENU. 1 MOVING THE POINTER Move the pointer (see the NOTE below) by pressing POINT button(s) on the TOP CONTROL or the REMOTE CONTROL.

  • Page 18: Menu Bar

    BEFORE OPERATION MENU BAR IN COMPUTER MODE MODE MENU AUTO IMAGE MENU Used to select Used to adjust Fine the Computer sync, Total dots, input mode. and Picture Position (Refer to P22) automatically. (Refer to P27) SYSTEM MENU Used to select a computer system.

  • Page 19: Basic Operation

    BASIC OPERATION TURNING ON / OFF THE PROJECTOR TURNING ON THE PROJECTOR Complete the peripheral connections (with Computer, VCR, etc.) before turning on the projector. (Refer to "CONNECTING TO THE PROJECTOR" on Pages 11~13 for connecting that equipment.) Connect the projector's AC Power Cord into a wall outlet. The LAMP indicator lights RED, and the READY indicator lights GREEN.

  • Page 20: Adjusting The Image

    BASIC OPERATION ZOOM ADJUSTMENT Turn the ZOOM RING to adjust the projected picture size. Turn the ring to “WIDE” direction to make the image larger, and turn to “TELE” direction to make the image smaller. FOCUS ADJUSTMENT Turn the FOCUS RING to adjust the projected picture focus. If the picture has keystone distortion, correct image with KEYSTONE adjustment.

  • Page 21: No Show Function

    Press the NO SHOW button on the Remote Control Unit to black out the image. This function is cancelled when the NO SHOW button is pressed again or any other function button is pressed. PICTURE FREEZE FUNCTION Press the FREEZE button on the Remote Control Unit to freeze the picture on-screen. This function is cancelled when the FREEZE button is pressed again or any other function button is pressed.

  • Page 22: Computer Mode

    COMPUTER MODE SELECTING COMPUTER MODE DIRECT OPERATION Select COMPUTER mode by pressing the MODE button on the Top Control or the COMPUTER button on the Remote Control Unit. MENU OPERATION Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select Computer and press the SELECT button.

  • Page 23: Compatible Computer Specifications

    COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept the signal from all computers with the V, H-Frequency below mentioned and less than 140 MHz of Dot Clock. H-Freq. ON-SCREEN RESOLUTION (kHz) DISPLAY VGA 1 640 x 480 31.47 VGA 2 720 x 400 31.47 VGA 3...

  • Page 24: Pc Adjustment

    COMPUTER MODE This Projector can automatically tune to the display signals from most personal computers currently distributed. However, some computers employ special signal formats which are different from the standard ones and may not be tuned by the Multi-Scan system of this projector. If this happens, the projector cannot reproduce a proper image and the image may be recognized as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture.
  • Page 25 Total lines The number of the total vertical lines. Adjust the number to match the image of your personal computer. Total dots The number of the total dots in one horizontal period. Adjust the number to match the image of your personal computer. Horizontal / Vertical Adjustment of the horizontal or vertical picture position.

  • Page 26: Picture Image Adjustment

    COMPUTER MODE PICTURE IMAGE ADJUSTMENTS ADJUST PICTURE IMAGE MANUALLY Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select IMAGE and press the SELECT button. Another dialog box PICTURE IMAGE ADJUSTMENT Menu will appear. Press the POINT DOWN button and a red-arrow icon will appear.

  • Page 27: Auto Image Function

    The Auto Image function is provided to automatically adjust Fine sync, Total dots, and Picture Position for most computers. Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select AUTO IMAGE and press the SELECT button. Another dialog box AUTO IMAGE Menu will appear.

  • Page 28: Picture Screen Adjustment

    COMPUTER MODE PICTURE SCREEN ADJUSTMENT This projector has a picture screen resize function, which enables you to display the desirable image size. Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select SCREEN and press the SELECT button.

  • Page 29: Video Mode

    VIDEO MODE DIRECT OPERATION Select VIDEO mode by pressing the MODE button on the Top Control or the VIDEO button on the Remote Control Unit. MENU OPERATION Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select Video and press the SELECT button.

  • Page 30: Selecting Color System

    VIDEO MODE SELECTING COLOR SYSTEM Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select SYSTEM and press the SELECT button. Another dialog box VIDEO SYSTEM Menu will appear. Press the POINT DOWN button and a red-arrow icon will appear.

  • Page 31: Picture Image Adjustment

    PICTURE IMAGE ADJUSTMENT ADJUSTING THE PICTURE IMAGE Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select IMAGE and press the SELECT button. Another dialog box PICTURE IMAGE ADJUSTMENT Menu will appear. Press the POINT DOWN button and a red-arrow icon will appear.

  • Page 32: Setting

    SETTING Press the MENU button and the ON-SCREEN MENU will appear. Press the POINT LEFT/RIGHT buttons to select SETTING and press the SELECT button. Another dialog box SETTING Menu will appear. Press the POINT DOWN button and a red-arrow icon will appear.

  • Page 33: Selecting Language

    Power management This function turns the Projection Lamp off when the projector detects signal interruption and the projector is not used for a certain period in order to reduce power consumption and maintain the Lamp- life. (This projector is shipped with this function ON.) Power Management function operates to turn the Projection Lamp off when the input signal is interrupted and the projector is not operated over 5 minutes.

  • Page 34: Appendix

    APPENDIX OPERATING WIRELESS MOUSE The Wireless Remote Control Unit is not only able to operate the projector but also usable as a wireless mouse for most Personal Computers. The POINT buttons and the two CLICK buttons are used for the wireless mouse operation.

  • Page 35: Maintenance

    TEMPERATURE WARNING INDICATOR The TEMPERATURE WARNING Indicator flashes red when the internal temperature of the projector exceeds the normal temperature. The Indicator stops flashing when the temperature of the projector returns to normal. When the TEMPERATURE WARNING Indicator continues to flash, check the items listed below. The Ventilation slots of the projector may be blocked.

  • Page 36: Lamp Replacement

    SELECT button. The message "Lamp replace monitor Reset?" is displayed. Select [Yes] to reset the Timer. Do not reset the Lamp Replacement Monitor Timer, except after the lamp is replaced. LAMP REPLACEMENT LAMP ASSEMBLY : LC-XM1 (Service Parts No. 610 289 8422) LAMP COVER HANDLE...

  • Page 37: Troubleshooting

    TROUBLESHOOTING Before calling your dealer or service center for assistance, check the matters below once again. 1. Make sure you have connected the projector to your equipment as described in the section "CONNECTING THE PROJECTOR" on pages 11 ~ 13. 2.
  • Page 38 APPENDIX Problem: Remote Control Unit does not work. Wireless Mouse function does not work. WARNING : High voltages are used to operate this projector. Do not attempt to open the cabinet. If the problem still persists after following all operating instructions, contact the sales dealer where you purchased the projector or the service center.

  • Page 39: Technical Specifications

    TECHNICAL SPECIFICATIONS Projector Type Dimensions (W x H x D) Net Weight LCD Panel System Panel Resolution Number of Pixels Color System High Definition TV Signals Scanning Frequency Projection Image size (Diagonal) Horizontal Resolution Projection Lens Throw Distance Projection Lamp AV Input Jacks AV Audio Input Jack Computer Input Jack...
